- Page 1 User manual PG219 Rev 00 Editi 25 03 16 Pressotherapy model I-PRESS 4...
- Page 2 I.A.C.E.R. Srl Via S. Pertini 24/A – 30030 Martellago (VE) ITALY Tel. 041.5401356 • Fax 041.5402684 e-mail: iacer@iacer.it - www.itechmedicaldivision.com...
-
Page 3: Table Of Contents
Summary Summary Pressotherapy Machine body and accessories Accessories size Configurations Specifications Technical Specifications Purpose Labels Working instructions Troubleshooting Warnings Cleaning Maintenance, carriage and storage Disposal Assistance Spare parts Warranty EMC Tables IACER SRL Page 3 MNPG219-00 25/03/16... -
Page 4: Pressotherapy
Pressotherapy Compressive limbs therapy is able to promote a right venous circulation by decreasing muscle tension caused by stress or chronic and acute pains: thanks to its pump action it favorites venous return by increasing tissues blood circulation and finally their physiological renewal. Compressive limbs therapy can solve blood stagnation problem in damaged sanguine vessels or in body zones not correctly bedewed. -
Page 5: Machine Body And Accessories
Machine body and accessories ON/OFF AIR DISCHARGE OUTPUT PRESSURE TIMER ADJUSTEMENT ELECTRIC CABLE EXTENSIONS FOR LEGGINGS LEGGINGS (11) ARMBAND (10) 1 DERIVATION CONNECTION TUBE (12) ABDOMINAL BAND PRESSURE PLANTARS 2 DERIVATIONS CONNECTION TUBE FOR LEGGINGS (13) SPECIAL SPLITTER FOR SIMULTANEOUS THERAPY ON BOTH LEGS AND ABDOMINAL BAND IACER SRL Page 5... -
Page 6: Accessories Size
Accessories size Legging: • Length around 76 cm (from upper side to heel) • Thigh circumference around 65 • Ankle circumference around 38 cm Armband: • Max. length around 86 cm • Biceps circumference around 50 cm • Wrist circumference around 36 cm Abdominal band: •... -
Page 7: Configurations
(11), 1 derivation connection tube (10). Extensions for wide legs (7) and special connector for simultaneous therapy on both legs and abdominal band (13) are available as accessories. Single accessories are available as optional to complete I-PRESS 4 content and potentiality. IACER SRL Page 7... -
Page 8: Specifications
Specifications I-PRESS 4 has the following specifications: • Class IIa equipment (Directive 93/42/EEC, annexed IX, rule 9); • Class II, applied part type BF (Classif. CEI EN 60601-1); • CE0476 certificate; • Equipment not protected against liquids penetration; • Equipment and accessories not subjected to sterilization;... -
Page 9: Labels
Labels Compressible Limb Therapy System Model I-PRESS 4 Voltage AC220~240V Frequency 50/60Hz Maximum output Maximum 50VA 300mmHg±10% power pressure I.A.C.E.R srl Via Sandro Pertini 24/A 30030 Martellago (VE), Italy Warning Product subject to WEEE regulations concerning separate waste collection of electronic equipment... - Page 10 Attention, consult operating instructions Instructions for use Device with IP21 level protection Not protected against liquids entrance, keep dry. Relative humidity for product storage Temperature range for product storage Pushing prohibited Sitting prohibited Stepping prohibited IACER SRL Page 10 MNPG219-00 25/03/16...
-
Page 11: Working Instructions
Working instructions 1) Connect cable to the domestic plug 220-240 VAC, then turn ON (1) the ON/OFF switch (1); 2) Wear the applicators a) Leggings use Wear the leggings (or single legging) and close the zip up to the end, then close the retaining Velcro straps; in case of wide circumferences legs, connect the extensions available as accessories;... - Page 12 iv) After connecting the tubes to the relatives leggings, connect the tubes to the air discharge output (5). b) Abdominal band use CONNECTION PLUGS Wear the band and connect the tubes to the band plugs, paying attention to connect the longer tube to the higher position connector on abdominal band;...
- Page 13 ii) Wear the leggings (or single legging) and close the zip up to the end, then close the retaining Velcro straps; in case of wide circumferences legs, connect the extensions available as accessories; iii) Insert the pressure plantars under the feet (available only with double leggings);...
- Page 14 3) Therapy time (selector (2) on machine body) a) Therapy time can be adjusted from 0 to 30 minutes: pump motor of main body will start operating; b) The air will fill up in applicator chambers in 2 minutes. Attention: The time selector cannot be moved counterclockwise during the treatment.
-
Page 15: Troubleshooting
ATTENTION: with I-PRESS 4 double leggings version, always connect both leggings to the connection tube even if you use only one legging during the treatment. IACER SRL... -
Page 16: Warnings
Warnings The following warnings guarantee user safety and prevention against damages and/or lesions. Please read it carefully before using I-PRESS 4. IACER SRL Page 16 MNPG219-00 25/03/16... - Page 17 IACER SRL Page 17 MNPG219-00 25/03/16...
- Page 18 IACER SRL Page 18 MNPG219-00 25/03/16...
-
Page 19: Cleaning
Carriage precautions It doesn’t need any particular carriage precautions: however we recommend to put away I-PRESS 4 and its accessories in their own box after every treatment. Storage precautions I-PRESS 4 is protected till following environmental conditions. -
Page 20: Disposal
Disposal The equipment is subjected to WEEE regulations (see the symbol on the label) concerning separate waste collection: when disposing this product, please use the designed areas for disposing electronic waste or contact the manufacturer. Assistance Every intervention on device must be performed by manufacturer. For any assistance intervention contact the national distributor or: I.A.C.E.R. -
Page 21: Emc Tables
– FOR ALL THE EQUIPMENT AND THE SYSTEMS I-PRESS S 4 is intended for use in the electromagnetic environment specified below. The customer or the user of the I-PRESS 4 should assure that it is used in such an environment. - Page 22 Electrical fast ± 2kV for power ± 2kV per power Mains power quality transient/burst supply lines supply lines should be at that of IEC 61000-4-4 a typical commercial hospital environment. ±1kV ±1kV Impulses Mains power quality differential differential EN 61000-4-5 should be at that of mode mode...
- Page 23 FOR ALL THE EQUIPMENT AND THE SYSTEMS SUPPORTING I-PRESS 4 is intended for use in the electromagnetic environment specified below. The customer or the user of I-PRESS 4 should assure that is used in such environment Immunity test Test level EN...
- Page 24 (2) These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. I-PRESS 4. All rights reserved. I-PRESS 4 and logos are owned by I.A.C.E.R Srl and are registered.
