STARVILLE SF-1000 User Manual

Hide thumbs Also See for SF-1000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
SF-1000
fog machine
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-1000 and is the answer not in the manual?

Questions and answers

Related Manuals for STARVILLE SF-1000

Summary of Contents for STARVILLE SF-1000

  • Page 1 SF-1000 fog machine user manual...
  • Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 09.01.2013...

  • Page 3: Table Of Contents

    Table of contents Table of contents General notes............................... 4 Safety instructions............................. 8 Features............................... 14 Installation..............................15 Connections and operating elements................... 16 Operation..............................22 Technical specifications........................25 Troubleshooting............................26 Cleaning............................... 27 Protecting the environment......................29 SF-1000...

  • Page 4: General Notes

    General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to other users, be sure that they also receive this manual.
  • Page 5 NOTICE! This combination of symbol and signal word indicates a possible dangerous situation that can result in material and environmental damage if it is not avoided. SF-1000...
  • Page 6 General notes Warning signs Type of danger Warning – high-voltage. Warning – flammable substances. Warning – hot surface. Warning – suspended load. Warning – harmful or irritating substances. fog machine...
  • Page 7 General notes Warning signs Type of danger Warning – danger zone. SF-1000...

  • Page 8: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used to produce artificial fog by vaporising fog fluid. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
  • Page 9 Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician. SF-1000...
  • Page 10 Safety instructions WARNING! Risk of burns from flammable liquids The use of flammable liquids in this device may cause severe burns and damage to property. Always use approved fog fluids. Never fill flammable liquids into the tank of the device. WARNING! Risk of burns The generated fog at the fog nozzle is hot and can cause burns.
  • Page 11 Fog fluid does contain glycols complying with the regulations for foodstuffs. However, it may be harmful if swallowed. Do not induce vomiting. Seek medical advice immediately. Keep fog fluid in a safe place. If the fog fluid comes into contact with eyes rinse thoroughly with water. SF-1000...
  • Page 12 Safety instructions CAUTION! Possible respiratory problems The device can be operated safely only with the approved fog fluid. The use of other fluids can release toxic gases. Claims for damages caused by the use of non- approved fluids shall be excluded. Do not create fog in closed or poorly ventilated areas.
  • Page 13 Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. SF-1000...

  • Page 14: Features

    Features Features This fog machine is suitable for use in clubs, bars, discotheques and on stages. Special features of the device: Remote control included Suitable for mobile use Large fog fluid container fog machine...

  • Page 15: Installation

    You can install the device on the wall, the ceiling or on the floor. The device must not be posi‐ tioned with more than 15° inclination during operation. The unit requires 20 cm clearance on the sides and above. SF-1000...

  • Page 16: Connections And Operating Elements

    Connections and operating elements Connections and operating elements Front panel fog machine...
  • Page 17 Connections and operating elements 1 Fog nozzle. 2 Fluid container with screw-cap. 3 Carrying handle. 4 Fog fluid feed line from fluid container to vaporiser. 5 Tommy screws to adjust the bracket. 6 Bracket for hanging. SF-1000...
  • Page 18 Connections and operating elements Rear panel fog machine...
  • Page 19 7 This LED indicates that the unit is warming up. 8 Connection for the remote control. 9 Main switch to turn the device on or off 10 POWER INPUT IEC chassis connector with fuse holder for operating voltage supply. SF-1000...
  • Page 20 Connections and operating elements Remote control fog machine...
  • Page 21 18 Push button TIMER Use this switch to turn the Timer function on or off. In this mode, the amount of fog set by the VOLUME control is output within the time intervals that you have set with the INTERVAL control. SF-1000...

  • Page 22: Operation

    Operation Operation Filling the unit NOTICE! Possible damages caused by unsuitable fog fluid Fog liquids not approved by the manufacturer may permanently damage the unit. Only use the fog fluids listed on www.thomann.de and follow their instructions for use. First, make sure the unit is switched off. Open the screw-cap of the container and fill in the fog fluid.
  • Page 23 As soon as the required operating temperature is reached, the green LED on the remote con‐ trol lights up. The unit is now operational. SF-1000...
  • Page 24 Operation Operating modes The device supports the following operating modes which can be selected with the remote control: Manual operation with maximum amount of fog Press the MANUAL button. This mode takes precedence over all others. That means that you don't have to turn off the timer function and continuous operation before you press the button.

  • Page 25: Technical Specifications

    Fog output approx. 280 m /min Fluid container capacity 1.5 l Warm-up time approx. 5 min Fuse 3.15 A / 250 V, fast-acting Dimensions (W × D × H) 220 mm × 440 mm × 230 mm Weight 8 kg SF-1000...

  • Page 26: Troubleshooting

    Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Symptom Remedy The unit does not work Check the mains connection and the main fuse. The unit does not eject any fog 1.

  • Page 27: Cleaning

    Make sure that the device is turned off, disconnected from the mains and completely cooled down. Place the unit in a well ventilated place. If there's still fog fluid present in the device, pour it out and fill the fog machine cleaner into the fluid container SF-1000...
  • Page 28 Cleaning Connect the device to the mains and turn it on with the main switch. The red lights on the device and on the remote control light up and thereby indicate that the unit heats As soon as the required temperature is reached, the green LED on the remote control lights up.

  • Page 29: Protecting The Environment

    Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. SF-1000...
  • Page 30 Notes fog machine...
  • Page 32 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
