HEPA 360° AIR SCRUBBER
Operating Manual
SAFETY INSTRUCTIONS ...................................... 2
INTRODUCTION ..................................................... 3
How the HEPA 360º Filtration System Works ........... 3
OPERATING INSTRUCTIONS
Main Features and Controls ...................................... 4
Preparing the Air Scrubber for Use............................ 5
Positioning the Air Scrubber .................................... 6
Operating the Air Scrubber ....................................... 7
Determining Mode of Operation .............................. 9
MODEL #512000
Serial #_______________________________________________________
CARE AND CLEANING
Changing the Pre-Filter .......................................... 10
Changing the HEPA Filter ....................................... 11
AFTER USING THE AIR SCRUBBER .................. 12
TROUBLESHOOTING .......................................... 13
SPECIFICATIONS AND ITEM NUMBERS ........... 14
WARRANTY .......................................................... 15
(Please Record the Serial Number Here)
© 2014 ITW Renovation & Remodeling, a Division of Illinois Tool Works Inc.
Advertisement
Table of Contents
Summary of Contents for BuildClean 512000
-
Page 1: Table Of Contents
Positioning the Air Scrubber ........6 Operating the Air Scrubber ........7 WARRANTY ............15 Determining Mode of Operation ......9 MODEL #512000 Serial #_______________________________________________________ (Please Record the Serial Number Here) © 2014 ITW Renovation & Remodeling, a Division of Illinois Tool Works Inc. -
Page 2: Safety Instructions
Safety Instructions The following safety instructions have been included in this manual to provide you with basic information necessary for safe operation of the BuildClean HEPA 360° Air Scrubber. WARNING WARNING DO NOT ATTEMPT TO OPERATE THE AIR 1. Do not stand on unit. -
Page 3: Introduction
Introduction This manual is intended to acquaint you with the BuildClean HEPA 360° Air Scrubber. The BuildClean HEPA 360° Air Scrubber is a self-contained, fully portable air filtration machine for professional residential remodeling projects. It uses a fan to draw in dirty air from the space, pass it through a 360-degree, two-stage filtration system to remove dust and particulates, and return clean air into the room. -
Page 4: Main Features And Controls
Air Exhaust Vent Main Power Switch (located at rear of unit) Durable Plastic Housing: The BuildClean HEPA Auto Dust Sensor: Allows the Air Scrubber to run in 360° Air Scrubber has a durable plastic housing built “AUTO” mode. While in AUTO mode, the Auto Dust especially for the rigors of construction work. -
Page 5: Preparing The Air Scrubber For Use
Save the box and packing material. If you need to If the air scrubber or its parts have been ship the BuildClean HEPA 360° air scrubber to a job damaged or if there are any other concerns, site or return the product, using the original box and call BuildClean at (855) 595-2860. -
Page 6: Positioning The Air Scrubber
BuildClean HEPA 360° Air Scrubber just outside the work space. This way, the unit will capture any particles that escape the barrier in the home. -
Page 7: Operating The Air Scrubber
Switch located on the back of the unit. Fire and Electric Shock Hazard Unit must be electrically grounded. The BuildClean HEPA 360° Air Scrubber is equipped with a short three-prong powercord that must be used with a UL approved 15 Amp, 125 Volt, 1875 ®... - Page 8 Operating the Air Scrubber Determining Operating Speed Power Status Display The BuildClean HEPA 360° Air Scrubber is equipped Unit Status – Green light when unit to produce a maximum air flow of 600 cubic feet per has been turned on at the Main minute (CFM).
-
Page 9: Determining Mode Of Operation
Determining Mode Of Operation The BuildClean HEPA 360° Air Scrubber has been designed to run in either air recirculation mode or in negative pressure mode. Before preparing your unit for operation, first determine the best mode of operation for your purposes: Recirculation Mode: In this mode, the air scrubber is placed within the room without any ducting. -
Page 10: Changing The Pre-Filter
Changing the Pre-Filter WARNING The air scrubber should be turned OFF at the Main Power Switch before unplugging the unit. WARNING Risk of dust dispersion – Use personal safety equipment. Unhealthy dust can be spread when removing the pre-filter. Wear protective glasses and a breathing mask. -
Page 11: Changing The Hepa Filter
5. Using a Phillips head screwdriver, screw in the retaining screw. Filter Maintenance The BuildClean HEPA 360° Air Scrubber is equipped with stop-light style LED display lights that indicate the status of the pre-filter and HEPA filter. When the display lights flash red, filter maintenance is needed... -
Page 12: After Using The Air Scrubber
After Using the Air Scrubber Turn the fan off by turning the knob to the OFF Inspect the HEPA filter and replace if needed. position. See the section on Changing the Air Filters for detailed instructions. Turn the unit off by moving the Main Power Switch to the OFF position. -
Page 13: Troubleshooting
Troubleshooting The BuildClean HEPA 360° Air Scrubber is designed and manufactured for severe environments and tasks, but the user must note that the machine components must be protected from knocks and blows. Filters and sealing connections are carefully chosen to serve the operator. Therefore, the machine must be handled with care if it is to work correctly for many years. -
Page 14: Specifications And Item Numbers
BuildClean HEPA 360° Air Scrubber Specifications Voltage 112 VAC (1 phase) Max Power Output 395 W (full speed) Max Air Flow 600 CFM 3-speed Pre-Filter Classification MERV 10 Pre-Filter Size 12" tall x 24.75" flat HEPA FilterClassification HEPA HEPA Filter Size 9.5"... -
Page 15: Warranty
Do not attempt to repair the HEPA 360° Air Scrubber without the consent of the manufacturer. If you attempt to repair the BuildClean HEPA 360° Air Scrubber for any reason without the consent of the manufacturer, the warranty will be null and void. - Page 16 A Division of Illinois Tool Works, Inc. 955 National Parkway, Suite 95500 Schaumburg, IL 60173-5172 855 - 595 - 2860 www.BuildClean.com Assembled in the U.S.A. U.S. Patent Pending BuildClean is a trademark of Illinois Tool Works, Inc. LITERATURE PACKET # 512136 OPERATIONS MANUAL # 512137-2...
