Movement Caliber
VD53
· The measurement time indicated by the stopwatch hands move independently of the
center hands.
INFO
· Chrono 1/10 sec : The stopwatch 1/10 second hand moves for a first minute. After one
minute, it indicates the measurement time when it is stopped.
Display Elements
Minutes Hand
Hour Hand
Stopwatch
Minutes Hand
(Move in second
increments)
Second Hand
Stopwatch
Minutes Hand
(Move in second
increments)
24-Hour Hand
(Indicates the time on
a 24-Hour basis)
Date Window
Movement Caliber : VD53
Presentation
Control Buttons
Push Button A
In stopwatch function:
Start / Stop
0
1
2
Crown Positions
1: Date setting
2: Time setting
Push Button B
In stopwatch function:
Split / Split release / Reset
Advertisement
Related Manuals for Invicta VD53
Summary of Contents for Invicta VD53
- Page 1 Movement Caliber : VD53 Presentation Display Elements Control Buttons Minutes Hand Push Button A In stopwatch function: Hour Hand Start / Stop Stopwatch Minutes Hand (Move in second increments) Movement Caliber Second Hand Stopwatch VD53 Minutes Hand Crown Positions (Move in second...
- Page 2 Movement Caliber : VD53 Setting Press button A or B to reset all stopwatch hands to “0” position. Adjusting the Stopwatch Hand Position · The stopwatch minute hand moves correspondingly with the stopwatch Before setting the time, check if all the chronograph hands - second, second hand. minute - are at the “0”(12 o’clock) position.
- Page 3 Movement Caliber : VD53 Setting Time Setting • Before setting the time, check that the chronograph measurement isstopped. • Do not set the date between 9:00 P.M. and 1:00 A.M, otherwise the day may not change properly. If it is necessary to set the date during the time period, firstly change the time to any time outside it, set the date and then reset the correct time.
-
Page 4: Standard Measurement
Movement Caliber : VD53 Functions How to Use the Stopwatch • The measurement time is indicated by the stopwatch hands that move independently of the center hands (and 24-hour hand where applicable). Start • The stopwatch can measure up to 60 minutes. - Page 5 Movement Caliber : VD53 Functions Accumulated Elapsed Time Measurement E.g. basketball game (Press the buttons in the following order A > A / A ···· > A > B ) Restart and stop of the stopwatch can be repeated as many times as necessary by pressing button A. 4.1 Start > Stop (Start of game) (Time out) 4.2 Restart (Restart of game), 5 Seconds 10 Seconds 4.3 Stop (Game Over), 20 Seconds 00 Seconds...
- Page 6 Movement Caliber : VD53 Functions Split Time Measurement E.g. 5,000m race (Press the buttons in the following order A > B / B ···· > A > B ) Measurement and release of the split time can be repeated as many times as necessary by pressing button B. 5.1 Start 5.2 Split / Split release, 5 Minutes 50 Seconds 5.3 Stop, 15 Minutes 10 Seconds...
