Movement Caliber
8040.N
Battery: 384
INFO
(diametaer 7.9mm x 3.6mm / SR 41 Accuracy: +20 / -10 seconds per monthSW)
Display Elements
Minute Hand
Day
Hour Hand
Minute Counter
Center Stop-Second
Second Hand
1/10 Second Counter
(Hour counter after 30 minutes)
Date
Movement Caliber : 8040.N
Presentation
Control Buttons
Push Button A
1
2
3
Crown Positions:
1. Normal position
2. Quick correction of date
3. Correction of hour,
minute, day, date and
second time zone / 24-hour
Push Button B
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Invicta 8040.N
Summary of Contents for Invicta 8040.N
- Page 1 Movement Caliber : 8040.N Presentation Control Buttons Display Elements Push Button A Minute Hand Hour Hand Minute Counter Movement Caliber Center Stop-Second Second Hand 8040.N Crown Positions: 1/10 Second Counter 1. Normal position (Hour counter after 30 minutes) 2. Quick correction of date Date 3.
-
Page 2: Setting The Time
Movement Caliber : 8040N Setting Setting the Time Pull out the crown to position 3 ➊ (the watch stops) ➋ Turn the crown until you reach the correct time 8:45. ➌ Push the crown back into position 1.* ➊ ➌ ➋... - Page 3 Movement Caliber : 8040N Setting Setting the Date (Quick Mode) Pull out the crown to position 2 ➊ (the watch continues to run) ➋ Turn the crown counter clockwise until the correct date 1 appears. ➌ Push the crown back into position 1. ➊...
- Page 4 Movement Caliber : 8040N Setting Setting the Date / Weekday and Time ➊ Example: – Date / time on the watch: 17 / 1:25 AM / MON ➋ – Present date / time: 23 / 20:30 PM / SAT ➊ Pull out the crown to position 3 (the watch stops).
-
Page 5: Chronograph: Basic Function
Movement Caliber : 8040N Functions Chronograph: Basic Function (Start / Stop / Reset) Example: A ➊ ➋ ➊ Start: Press push button A. ➋ Stop: To stop the timing, press push button A once more and read the 3 chronograph counters: 4 min / 38 sek / 7/10 sec Zero positioning: Press push button B. - Page 6 Movement Caliber : 8040N Functions Chronograph: Accumulated Timing Example: ➊ ➋ ➌ ➍ Start: ➊ (start timing) ➋ Stop: (e.g. 15 min 5 sec following ➊ ) Restart: ➌ (timing is resumed) Stop: ➍ (e.g. 13 min 5 sec following ➌ ) = 28 min 10 sec (The accumulated measured time is shown) B ➎...
- Page 7 Movement Caliber : 8040N Functions Chronograph: Intermediate or Interval Timing Example: ➊ ➍ Start: ➊ (start timing) ➋ Display interval: e.g. 10 minutes 10 seconds (timing continues in the background) Making up the measured time: ➌ (the 3 chronograph hands are quickly advanced to the ongoing measured time) B ➎...
- Page 8 Movement Caliber : 8040N Calibration Adjusting the Chronograph Hands to Zero Position ➊ Example: One or several chronograph hands are not in their correct zero position and have to be adjusted (e.g. following a battery change) Pull out the crown to position 3 ➊...
