Electrolux E30SO75ESS Service Manual

High speed convection microwave oven
Hide thumbs Also See for E30SO75ESS:
Table of Contents

Advertisement

Quick Links

See also: Technical & Service Manual , Use and Care Manual
In the interest of user-safety the oven should be restored to its original condition and only parts identical to those specified should
be used.
WARNING TO SERVICE PERSONNEL: Microwave ovens contain circuitry capable of producing very high voltage and
current, contact with following parts may result in a severe, possibly fatal, electrical shock. (High Voltage Capacitor,
High Voltage Power Transformer, Magnetron, High Voltage Rectifier Assembly, High Voltage Harness etc..)
BEFORE SERVICING .................................................................................................... INSIDE FRONT COVER
WARNING TO SERVICE PERSONNEL .............................................................................................................. 1
MICROWAVE MEASUREMENT PROCEDURE .................................................................................................. 2
FOREWORD AND WARNING ............................................................................................................................. 3
PRODUCT SPECIFICATIONS ............................................................................................................................ 4
GENERAL INFORMATION ................................................................................................................................. 4
OPERATION ........................................................................................................................................................ 6
TROUBLESHOOTING GUIDE .......................................................................................................................... 13
TEST PROCEDURE .......................................................................................................................................... 15
TOUCH CONTROL PANEL ............................................................................................................................... 26
PRECAUTIONS FOR USING LEAD-FREE SOLDER ....................................................................................... 30
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE .............................................................. 31
PICTORIAL DIAGRAM ...................................................................................................................................... 39
POWER UNIT CIRCUIT .................................................................................................................................... 40
CPU UNIT CIRCUIT .......................................................................................................................................... 41
PARTS LIST ...................................................................................................................................................... 42
PACKING AND ACCESSORIES ....................................................................................................................... 47
This document has been published to be used for after sales service only. The contents are subject to
change without notice.
Publication # 5995505426
ELECTROLUX
SERVICE MANUAL

TABLE OF CONTENTS

P. O. Box 212378, Augusta, GA, 30917
800•944•9044
HIGH SPEED CONVECTION
MICROWAVE OVEN
E30SO75ESS
MODEL
1
E30SO75ESS
S75M255E30SO7
Page
P/N 316439260
