10.1 DUAL SCREEN PORTABLE DVD PLAYER
&
MEDIA PLAYER
MODEL:SDVD1010
DISPLAY ON/OFF
MUTE
DISPLAY SETUP
/SETUP
USB/SD
OPEN
INSTRUCTION MANUAL
Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDVD1010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sylvania SDVD1010

  • Page 1 " 10.1 DUAL SCREEN PORTABLE DVD PLAYER & MEDIA PLAYER MODEL:SDVD1010 DISPLAY ON/OFF MUTE DISPLAY SETUP /SETUP USB/SD OPEN INSTRUCTION MANUAL Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
  • Page 2: Important Safety Instructions

    Important Safety Instructions The lightning flash with arrowhead symbol within an equilateral CAUTION triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’ s enclosure that may be of RISK OF ELECTRIC SHOCK sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 3 Important Safety Instructions Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna.
  • Page 4 Important Safety Instructions 17) Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 18) Object and liquid entry Never push objects of any kind into the product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
  • Page 5: Notes On Handling

    Important Safety Instructions NOTES ON MOISTURE CONDENSATION: NOTES ON HANDLING: • Moisture condensation damages the DVD When shipping the DVD player, always use player. Please read the following carefully. the original shipping carton and packing materials. For maximum protection, repack •...
  • Page 6: About Discs

    About Discs THE REGION NUMBER FOR THIS DVD PLAYER IS: See the following page for information regarding region numbers. PLAYABLE DISCS: The following discs can be played on this DVD player: DISC TYPES: Data on most DVDs is divided into sections called titles and then into subsections called chapters, each of which is given a title or chapter number.
  • Page 7: Main Unit Overview

    Product Overview MAIN UNIT: /SETUP USB/SD OPEN VOLUME ~ Press to pause during playing, press again to resume playing. ~ Or, press to select or confirm during certain operation, such as setting up operation. Press and hold the button to enter virtual remote function when there is a disc is playing. SETUP Press and hold the button to enter setting up when no disc, USB or Card playing.
  • Page 8 Product Overview MAIN UNIT: POWER DC IN PHONE AV OUT SD/MMC CARD DC OUT ON/OFF: Power ON/OFF switch. Slide to ON position to power on, slide to OFF position to shut off. PHONE: Headphone jack. AV OUT: Audio/Video output jack. SD/MMC: Card slot.
  • Page 9: Virtual Remote Control Operation

    Product Overview MAIN UNIT: Virtual remote control operation During playing, press and hold the button to enter remote control interface. Press button repeatedly to highlight the desired function, press to select and confirm. Press the button repeatedly to Repeat Chapter, Repeat Title, Repeat All for DVD REPEAT: disc.
  • Page 10: Secondary Unit Overview

    Product Overview SECONDARY UNIT: DISPLAY ON/OFF MUTE DISPLAY SETUP VOLUME VOLUME DC IN AV IN PHONE POWER DISPLAY ON/OFF: Press to turn the display ON or OFF. MUTE: Press to turn the sound OFF. Press again to resume. DISPLAY SETUP: Press to enter the display setup menu. Power Indicator: Indicates when the secondary unit is ON/OFF.
  • Page 11: Power Source

    Power Source unit has a built-in Lithium-ion rechargeable battery. Recharge it as follows: main Charging by supplied AC/DC adapter: 1. Connect the plug from the supplied AC/DC adapter to the DC IN Jack on the main unit. 2. Connect the AC/DC adapter to the wall outlet having AC 100-240V~; 50/60Hz. Notes: •...
  • Page 12: Making Connections

    Making Connections Connecting the main unit to the secondary unit. MAIN UNIT: SECONDARY UNIT: DC to DC cable (included) 3.5mm audio/video cable (included) Note: The secondary unit must be connected to the main unit, it can not be operated independantly.
  • Page 13: Operation

    Operation MAIN UNIT: 1. Recharge or connect the unit to AC/DC Adaptor/ Car Adaptor as previous procedure. 2. Press the OPEN button on main unit to open the CD door. 3. Insert the disc to the center spindle with label side face up and close the lid. 4.
  • Page 14: Usb/Sd/Mmc Card Playback

    USB or SD/MMC Card Playback 1. Insert the USB Device or SD/MMC memory card into the USB port/card slot as shown below: DC IN PHONE AV OUT SD/MMC CARD DC OUT USB device SD, MMC card (not included) (not included) Note: The unit supports the following file formats: MP3, WMA(Music File)
  • Page 15: Setting Menu

    Setting Menu Setting Menus: In fully stop mode and no any external device playing, press and hold the SETUP button, setting menu will appear on screen as below. Press or to cursor, press the STOP button to return, press to select and confirm. After setting, press and hold the SETUP button to save and exit.
  • Page 16 Setting Menu IN SPEAKER SETUP PAGE: If Speaker Setup is selected, press the button, the sub-setting menu will appear. 1. If Downmix is selected, use the buttons set it to Lt/Rt; Stereo. • If set to Lt/Rt, the rear left or rear right channels will play on both Left and Right Speakers.
  • Page 17 Setting Menu Dolby IN VIDEO SETUP PAGE: 1. If Panel Quality is selected, use the buttons to set the panel quality (Sharpness; Brightness; Contrast; Hue or Saturation) as desired. Sharpness: To adjust the sharpness Brightness: To adjust the video brightness level on a scale of -20 to +20. Contrast: To adjust the video contrast level on a scale of –16 to +16.
  • Page 18 Setting Menu IN PREFERENCE SETUP PAGE: 1. If TV Type is selected, use the buttons to set to PAL, AUTO or NTSC. (NOTE: The TV system in USA, Canada and Mexico is NTSC.) buttons to the 2. If Audio, Subtitle or Disc Menu is selected, use the priority of the available language.
  • Page 19: Caring For Discs

    Care and Maintenance CARING FOR DISCS Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to contact with the shiny, unprinted side of the disc. • Do not attach adhesive tape, stickers, etc. to the disc label. •...
  • Page 20: Specifications

    Specifications Power source of main unit ........Built-in DC 7.4V, 2000mAh Lithium-ion rechargeable battery, recharge by DC 12V, 1.5A AC Adapter ..............Input: 100-240V~, 50/60Hz Output: DC 12V, 1500mA Car Adapter ..............Input Voltage: DC Output Voltage: DC 12V, 2A Disc compatibility: ............DVD/VCD/SVCD/DVCD/CD/CD-R/CD-RW/ DVD±R/DVD±RW Power consumption ..........18W (Max) Battery charging time ..........Approximately...
  • Page 21 Mounting Strap Installation Step 1 Step 1 Go the strap through the two holes on both sides of the rear side of the player as shown on the above figure. Step 2 Pull out Go the strap from gap and go out from the rear side of the gap as shown on the above figure.
  • Page 22 LECTEUR DVD ET MULTIMÉDIA PORTABLE AVEC DOUBLE ÉCRAN 10,1 MODÈLE : SDVD1010 DISPLAY ON/OFF MUTE DISPLAY SETUP /SETUP USB/SD OPEN MODE D'EMPLOI Lisez ce mode d'emploi avec attention pour garantir l'utilisation correcte de ce produit, et conservez-le pour référence future.
  • Page 23: Consignes De Sécurité Importantes

    CONSIGNES DE SÉCURITÉ IMPORTANTES ATTENTION RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR ATTENTION : AFIN DE RÉDUIRE TOUT RISQUE DE CHOC ÉLECTRIQUE, NE PAS RETIRER LE COUVERCLE (OU L'ARRIÈRE). AUCUNE PIÈCE UTILISATEUR À L’INTÉRIEUR CONFIER TOUT ENTRETIEN À DES TECHNICIENS QUALIFIÉS VEUILLEZ CONTACTER LE PERSONNEL QUALIFI_ É...
  • Page 24 secteur. Les dégâts entraînés par la foudre et les pics de courant NE SONT PAS couverts par la garantie de ce produit. Le symbole d'éclair avec une flèche, à l'intérieur d'un triangle équilatéral, indique à l'utilisateur la présence de « tension dangereuse » non isolé à l'intérieur de l'appareil, qui pourrait être suffisant pour constituer un risque de choc électrique.
  • Page 25 Tout changement ou modification effectuée sans l'approbation du fabricant de l'équipement pourrait annuler son autorité sur le bon fonctionnement de cet équipement. Lorsque les câbles d'interface blindés ont été fournis avec le produit ou des composants ou accessoires supplémentaires particuliers prévus ailleurs pour être utilisés avec l'installation du produit, ils doivent être utilisés pour assurer la conformité...
  • Page 26 exemple à proximité d'un bain, bol de liquide, évier, machine à laver, dans un sous-sol humide, près d'une piscine, etc. 6) Nettoyer seulement avec un chiffon sec Débrancher cet appareil avant le nettoyage Ne pas utiliser de nettoyant liquide ou en aérosol.
  • Page 27 15) Source d'alimentation Ce produit devrait être alimenté seulement à partir de la source d'alimentation spécifiée sur l'étiquette. Si vous n'êtes pas certain de la source d'alimentation, veuillez contacter le vendeur ou la compagnie d'électricité locale. Pour les produits conçus pour fonctionner avec des piles ou d'autres sources, se référer au mode d'emploi.
  • Page 28 ANTENNA DISCHARGE UNIT UNITÉ DE DÉCHARGE DE L'ANTENNE (NEC SECTION 810-20) (NEC SECTION 810-20) GROUNDING CONDUCTORS CONDUCTEURS DE MISE À LA TERRE (NEC SECTION 810-21) (NEC SECTION 810-21) GROUND CLAMPS PINCES DE MISE À LA TERRE POWER SERVICE GROUNDING SYSTÈME D'ÉLECTRODE DE MISE À ELECTRODE SYSTEM LA TERRE DE LA SOURCE ÉLECTRIQUE (NEC ART 250, PARTH)
  • Page 29 f) Lorsque le rendement de l'appareil diminue, cela indique un besoin d'entretien. 25) Note à l'installateur du système CATV Ce rappel est destiné à attirer l'attention de l'installateur du système CATV sur l'article 820-40 du NEC qui fournit des directives pour la mise à la terre adéquate et, en particulier, spécifie que le câble de mise à...
  • Page 30 quel type de solvant, tel que diluant et benzène, car ils pourraient endommager la surface de l'appareil. ● Si vous utilisez un chiffon saturé de produits chimiques pour nettoyer l'appareil, suivez les instructions de ce produit. REMARQUES SUR LA CONDENSATION CAUSÉE PAR L'HUMIDITÉ : La condensation causée par l'humidité...
  • Page 31: Disques Compatibles

    À propos des disques LE NUMÉRO DE RÉGION POUR CE LECTEUR DVD EST : Voir la page suivante pour obtenir des informations sur les numéros de zone. DISQUES COMPATIBLES : Les disques suivants peuvent être lus sur ce lecteur DVD : TYPES DE DISQUES : Les données sur la plupart des DVD sont divisées en sections appelées titres et en sous-sections...
  • Page 32 Ce lecteur est conforme aux systèmes de couleur PAL et NTSC. Cependant, si vous habitez aux États-Unis, au Canada ou au Mexique, laissez le réglage sur NTSC. Si incorrectement réglé sur PAL, l'image de du téléviseur pourrait se déplacer verticalement. Dans ce cas, réglez le système TV sur NTSC. Notes sur les droits d'auteur : Il est interdit par la loi de copier, diffuser, montrer, diffuser sur le câble, jouer en public et louer du matériel sous copyright sans autorisation.
  • Page 33: Unité Principale

    Présentation du produit UNITÉ PRINCIPALE /SETUP USB/SD OPEN VOLUME II : ~ Appuyez pour mettre en pause, appuyez de nouveau pour reprendre. ~ Ou, appuyez pour sélectionner ou confirmer pendant certaines opérations, comme par exemple lors de la configuration. : Maintenez appuyé pour activer une fonction de télécommande virtuelle pendant la lecture d'un disque.
  • Page 34 Présentation du produit UNITÉ PRINCIPALE : POWER DC IN PHONE AV OUT SD/MMC CARD DC OUT 8. ON/OFF : Bouton d'alimentation ON/OFF. Faites-le glisser sur ON pour allumer, et sur OFF pour éteindre. 9.TÉLÉPHONE : Prise casque. 10.SORTIE AV : Prises de sortie Audio/Vidéo 11.SD/MMC : Fente pour insérer une carte mémoire 12.USB : Port USB.
  • Page 35 Présentation du produit UNITÉ PRINCIPALE Utilisation de la télécommande virtuelle Pendant la lecture, maintenez le bouton appuyé pour afficher la télécommande virtuelle. Appuyez sur ou sur de manière répétée pour mettre en surbrillance la fonction désirée, et appuyez sur II pour sélectionner et confirmer. REPEAT Appuyez sur le bouton II de manière répétée pour Répéter...
  • Page 36 Présentation du produit UNITÉ SECONDAIRE : DISPLAY ON/OFF MUTE DISPLAY SETUP VOLUME VOLUME DC IN AV IN PHONE POWER 1. ALLUMER OU ÉTEINDRE L'ÉCRAN : Appuyez pour activer ou désactiver l'écran. 2. MUET : Appuyez pour désactiver le son. Appuyez de nouveau pour rétablir. 3.
  • Page 37: Source D'alimentation

    Source d'alimentation L'appareil est doté d'une batterie au lithium-ion rechargeable. Rechargez-la comme suit : Recharge à l'aide de l'adaptateur secteur inclus : 1. Branchez la petite fiche de l'adaptateur secteur dans la prise d'entrée Entrée alimentation située sur l'unité principale. 2.
  • Page 38 Effectuer des connexions Connecter l'unité principale à l'unité secondaire. UNITÉ PRINCIPALE : UNITÉ SECONDAIRE : Câble chargeur vers chargeur (inclus) Câble de connexion audio 3,5 mm (inclus) Note : L'unité secondaire doit être connectée à l'unité principale. Elle ne peut pas fonctionner indépendamment.
  • Page 39 Mode d'emploi UNITÉ PRINCIPALE : 1. Rechargez ou branchez l'appareil à l'adaptateur CA/CC ou à l'adaptateur allume-cigare comme indiqué précédemment. 2. Appuyez sur le bouton OUVRIR pour ouvrir la porte du CD. 3. Placez le disque sur le moyeu au centre du plateau, l'étiquette en haut. 4.
  • Page 40 LECTURE VIA USB ou CARTE SD/MMC 1. Insérez le dispositif USB ou la carte mémoire SD / MMC dans le port USB / la fente de carte comme sur la figure ci-dessous : DC IN PHONE AV OUT SD/MMC CARD DC OUT Périphérique USB Carte SD, MMC...
  • Page 41 5.Menu de configuration Menus de configuration : Lorsqu'aucun fichier n'est lecture, maintenez appuyé bouton CONFIGURATION pour afficher le menu des réglages à l'écran. Appuyez sur les boutons pour déplacer le curseur. Appuyez sur le bouton STOP pour revenir, appuyez sur II pour sélectionner et confirmer.
  • Page 42 Menu de configuration PAGE DE CONFIGURATION DU HAUT-PARLEUR : Si Configuration haut-parleurs est sélectionnée, appuyez sur le bouton mi pour afficher le sous-menu. 1. Si Remixage sélectionné, utilisez les boutons II pour choisir pG/pD ou Stéréo. S'il est réglé sur pG/pD, les canaux arrière gauche ou arrière droit seront ...
  • Page 43 Menu de configuration Dolby DANS LA PAGE DE CONFIGURATION VIDÉO : 1. Si Qualité image est sélectionné, utilisez les boutons II pour définir la qualité de l'image (Netteté, Luminosité, Contraste, Teinte ou Saturation) comme désiré. Netteté : Pour régler la netteté. Luminosité...
  • Page 44 Menu de configuration DANS LA PAGE DE CONFIGURATION DES PRÉFÉRENCES : 1. Si Type TV est sélectionné, utilisez les boutons II pour sélectionner PAL, AUTO ou NTSC. (REMARQUE : Le système de télévision aux États-Unis, au Canada ou au Mexique est NTSC.). 2.
  • Page 45: Nettoyage De L'appareil

    Nettoyage et entretien Soin des disques Traitez le disque avec soin. Manipulez le disque uniquement par ses bords. Manipulez le disque uniquement par ses bords. Ne pas fixer de ruban adhésif, autocollants, etc sur l'étiquette de disque.  Nettoyer le disque périodiquement avec un chiffon sec doux, non pelucheux. ...
  • Page 46: Fiche Technique

    Fiche technique Alimentation de l'unité principale batterie rechargeable au lithium-ion 7,4 V, 2000 mAh. Rechargeable via secteur 12V, 1,5A Adaptateur secteur ..entrée : 100-240V ~, 50/60Hz Sortie : CD ~ 12V, 1500mA Adaptateur de voiture ...Voltage d'entrée : CC 12V Tension de sortie : CC ~ 12V, 2A Disques compatibles : ..
  • Page 47 Installation de la sangle de fixation Étape 1 Faites passer la sangle dans les deux trous situés de chaque côté de la partie arrière du lecteur comme illustré ci-dessus. Étape 2 Tirer Tirez la sangle depuis le trou ① puis faites-le passer dans l'arrière du trou ② comme illustré...
