Summary of Contents for American Beauty V36GL3
- Page 1 Soldering Solutions User Manual for Soldering Stations www.americanbeautytools.com...
-
Page 2: Table Of Contents
Proper Use of Soldering Station 9-10 MAINTENANCE & CARE ACCESSORIES TROUBLE SHOOTING 13-14 REPLACEMENT PARTS WARRANTY & SERVICE DETAILS Company Information American Beauty Tools are made just outside of Detroit Michigan, USA. 1.248.280.2810 1.800.550.2510 Fax: 1.248.280.2878 Email: info@americanbeautytools.com Website: www.americanbeautytools.com... -
Page 3: Introduction
American Beauty has been a fixture in the soldering tool market- place since 1894. Our tools are a throw-back to a time when people took pride in the tools they used and companies took pride in the tools they manufactured. Today, American Beauty ®... -
Page 4: Product Contents
The chart below is used to illustrate these differences for the user: Model # Wattage Tips Included V36GL3 60 Watt 704, 709, 724 V36GM3 40 Watt 610, 625, 643... -
Page 5: Safety
Soldering irons are extremely hot. Operators of this product should be made aware of and fully understand all of the warnings as they relate to the operation or use of this device. Failure to observe the following safety instruction could result in serious injury. Safety - Personal •... -
Page 6: Safety - Device
Safety - Device • Most American Beauty Industrial Grade Soldering Stations are available in both a low voltage (110-120VAC) and high voltage (220-240VAC) version. Please consult your cord label to determine what version you have purchased and ensure your solder station is properly plugged in to the appropriate outlet. -
Page 7: Set-Up & Operation
Selecting a Location Choosing a good location to station your Industrial Grade Soldering Station is the first step to operating your soldering station safely and efficiently. To assist with this, we have created a checklist of considerations to guide you in selecting a location for your soldering station. - Page 8 The following graphics illustrate the correct assembly of the soldering iron tray: Attach the tray to the unit:...
-
Page 9: Proper Use Of Soldering Station
Proper Use of Soldering Station When installing a soldering tip into your iron please ensure the tip is fully seated in the iron. This will help prevent premature burnout of the heating element. Plug the station into an approved 3-wire (grounded) outlet while iron is resting in iron stand. - Page 10 8. Turn unit “OFF”, unplug, and allow iron to cool to room temperature prior to storing. PROPOSITION 65 WARNING: American Beauty tools & accessories are lead-free & RoHS Compliant. However, use of this product with lead-bearing solders (or any other chemicals...
-
Page 11: Maintenance & Care
Note: Do not take a file to your American Beauty Paragon tip to clean it. Using a file on your soldering iron tip will lead to the removal of it’s iron plating which will significantly degrade the life of the tip. -
Page 12: Accessories
Brass Sponge Solder Tip Cleaner & Tip Tiner Model CS-BS1 Model CS-TT1 Solder & Fluxes Solder, Models Flux, Models CS-PBF1 & CS-PBF2 CS-FX1, CS-FX2, CS-FX3 Desoldering Braid Single 5 ft Bobbins: 484-1G, 2G, 3G, 4G, 5G Sleeve of 25 Bobbins: 484-1,2,3,4,5 Thumb Wheel Dispenser: 485-8C... -
Page 13: Trouble Shooting
Both the tip and heating element will need to be replaced. (Pg. 15) Soldering iron no longer American Beauty soldering irons are seems to reach the same ‘full-output’ irons, meaning they either top temperatures. operate at maximum potential or they completely expire. - Page 14 Warning: Disconnect the power cord prior to performing any service or diagnostics on your Industrial Grade Solder Station. Failure to do so could cause serious harm and electric shock. Service to your solder station should be performed by qualified personnel to avoid injury or damage.
-
Page 15: Replacement Parts
Replacement Parts List American Beauty offers a full line of replacement parts for your Industrial Grade Soldering Station Repairs are straight forward, however for those wanting the work done for them, please see our website www.americanbeautytools.com/repair to take advantage of our Repair and Refurbish program. -
Page 16: Warranty & Service Details
Warranty Details American Beauty tools are warrantied to be free from defects in material and workmanship as outlined below. No warranty is made with respect to products which have been altered, subjected to abuse or improperly used. Consumable Parts - NOT COVERED Items include such parts as Soldering Iron Tips, Desoldering Braid, Resistance Soldering Elements and Electrodes, etc.
