Page 1: Installation Manual
INSTALLATION MANUAL English SPLIT SYSTEM Air Conditioners MODELS (Ceiling mounted Cassette built-in type) FBQ60BV1 FBQ60BVL FBQ71BV1 FBQ71BVL READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE. -
Page 2: Table Of Contents
FBQ60BV1 FBQ60BVL SPLIT SYSTEM Air Conditioner Installation manual FBQ71BV1 FBQ71BVL CONTENTS 1. SAFETY CONSIDERATIONS ..................1 2. BEFORE INSTALLATION ....................2 3. SELECTING INSTALLATION SITE.................5 4. PREPARATIONS BEFORE INSTALLATION ..............6 5. INDOOR UNIT INSTALLATION ..................7 6. REFRIGERANT PIPING WORK ..................8 7. DRAIN PIPING WORK ....................10 8. -
Page 3: Before Installation
• Make sure that all wiring is secured, the specified wires and used, and no external forces act on the terminal connections or wires. Improper connections or installation may result in fire. • When wiring the power supply and connecting the wiring between the indoor and outdoor units, position the wires so that the control box lid can be securely fastened. - Page 4 • For the installation of an outdoor unit, refer to the installation manual attached to the outdoor unit. • Do not use the unit in locations with high salt content in the air such as beachfront property, locations where the voltage fluctuates such as factories, or in automobiles or marine vessels. 1.
-
Page 5: Optional Accessories
Decoration panel Canvas duct for Model Min. height above ceiling decoration panel Color White ∗ FBQ60BV1 KSAJ25K80 FBQ71BV1 BYBS71DJW1 FBQ60BVL Installation not required ∗ 35 cm or more FBQ71BVL ∗ When using the canvas duct for the decoration panel, the decoration panel needs at least 42.5 cm of ceiling space. -
Page 6: Selecting Installation Site
c. Points for explanation about operations The items with WARNING and CAUTION marks in the operation manual are the items pertaining to possibilities for bodily injury and material damage in addition to the general usage of the product. Accordingly, it is necessary that you make a full explanation about the described contents and also ask your customers to read the operation manual. -
Page 7: Preparations Before Installation
For standard installation (air inlet on the both side), choose one of the below two means of installation. NOTE • For other than standard installation, contact your Daikin dealer for details. For mounting decoration panel with canvas duct Indoor unit... -
Page 8: Indoor Unit Installation
3. Install the suspension bolts. (Refer to Fig. 2) (Use M10 size bolt for the suspension bolt) <Installation example> Use anchors for existing ceilings, and a sunken insert, Ceiling slab sunken anchor or other field supplied parts for new ceil- ings to reinforce the ceiling to bear the weight of the unit. -
Page 9: Refrigerant Piping Work
6. REFRIGERANT PIPING WORK 〈 〈 〈 〈 For refrigerant piping of outdoor unit and BP unit, see the installation manuals attached to the out- door unit and BP unit.〉 〉 〉 〉 〈Execute heat insulation work completely on both sides of the gas piping and the liquid piping. Otherwise, a water leakage can result sometimes.〉... - Page 10 Not recommendable but in case of emergency You must use a torque wrench but if you are obliged to install the unit without a torque wrench, you may follow the installation method mentioned below After the work is finished, make sure to check that there is no gas leak. When you keep on tightening the flare nut with a spanner, there is a point where the tightening torque suddenly increases.
-
Page 11: Drain Piping Work
• Nitrogen should be set to 0.02 Mpa (0.2 kg/cm ) with a pressure-reducing valve if brazing while inserting nitrogen into the piping. (Refer to Fig. 9) Pressure-reducing valve Refrigerant piping Taping Part to be hands valve brazed Nitrogen Nitrogen Fig. - Page 12 <PRECAUTIONS FOR DRAIN RAISING PIPING> • Install the drain raising pipes at a height of less than 250 mm. • Install the drain raising pipes at a right angle to the indoor unit and no more than 300 mm from the unit. Ceiling slab 300 mm or less 1~1.5m...
-
Page 13: Electric Wiring Work
WHEN ELECTRIC WIRING WORK IS NOT FINISHED CAUTION • Electrical wiring work should be done by a certified electrician. • If someone who does not have the proper qualifications performs the work, perform the following after test run is complete. •... - Page 14 PRECAUTION Connection of wiring units, ground wire and remote controller cord. (Refer to Fig. 18 and 19) • Wiring the units and ground for the wire Remove the control box lid and pull out the control box. (Refer to Fig. 18) Next, pull the wires inside through the rubber bush A and connect them to their respective terminals on the terminal block for wiring the units (4P) inside.
- Page 15 Observe the notes mentioned below when wiring to the terminal block for wiring the units. CAUTION • When clamping wiring, use the included clamping material to prevent outside pressure being exerted on the wiring connections and clamp firmly. When doing the wiring, make sure the wiring is neat and does not cause the control box lid to stick up, then close the cover firmly.
-
Page 16: Wiring Example
9. WIRING EXAMPLE For the wiring of outdoor unit and BP unit, refer to the installation manuals attached to the outdoor unit and BP unit. Confirm the system type. • 1 remote controller control: 1 remote controller controls 1 indoor unit (standard system). (Refer to Fig. 21) •... -
Page 17: Field Setting
10. FIELD SETTING <Field setting must be made from the remote controller in accordance with the installation condi- tion.> • Setting can be made by changing the “Mode No.”, “FIRST CODE NO.” and “SECOND CODE NO.”. • For setting procedures and instructions, refer to the “FIELD SETTING” in the installation manual of the remote controller. -
Page 18: Installation Of The Decoration Panel
5. Control by 2 remote controllers (Controlling 1 indoor unit by 2 remote controllers) • When using 2 remote controllers, one must be set to “MAIN” and the other to “SUB”. MAIN/SUB CHANGEOVER (1)Insert a screwdriver into the recess between the upper and lower part of remote controller and, working from the 2 positions, pry off the upper part. - Page 19 PRECAUTIONS • Refer to the diagnoses below if the unit does not operate properly. • After completing the test run, press the INSPECTION/TEST OPERATION button once to put the unit in inspection mode, and make sure the Malfunction code is “00” (=normal). If the code reads anything other than “00”, refer to the malfunction diagnoses below.
- Page 20 Type set improper Capacity data is wrongly preset. Or there is nothing programmed in the data hold IC. Sensor (R2T) for heat exchanger temperature is fault Sensor (R3T) for heat exchanger temperature is fault Sensor for suction air temperature is fault Sensor for remote controller is fault The remote controller thermistor does not function, but the system thermo run is possible.
- Page 21 Transmission error (indoor unit – outdoor unit) Wrong wiring between indoor and outdoor units or malfunction of the PC board mounted on the indoor and the outdoor units. If UF is shown, the wiring between the indoor and outdoor units is not properly wired. Therefore, immediately disconnect the power supply and correct the wiring.
-
Page 22: Wiring Diagram
13. WIRING DIAGRAM English... - Page 23 3P156215-4C EM04A076B (0506) HT...
