TECHNICAL INFORMATION

Dimensions:
- Length : 270 mm
- Width : 245 mm
- Height : 430 mm (incl. pusher)
- Weight : 4320 g

PARTS LIST

Pos
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
= changed
Service code Description
4203 035 96721 Pusher
4203 035 96731 Lid
4203 035 96741 Juice collector
4203 035 96751 Integrated pulp container
4203 035 96761 Spout accessory
4203 035 96771 Detachable spout
4203 035 96781 Filter
4203 035 96791 Juice jug + Lid
4203 035 96801 Driving shaft
4203 035 96811 Main housing with metal wrap + Motor crussion and Stopper
4203 035 96821 Rubber ring
4203 035 96831 Bottom incl. Current limiter
4203 035 96841 Anti slip ring
4203 035 96851 On/Off knob
4203 035 96861 On/Off switch electronic
4203 035 96871 Safety switch
4203 035 96881 Brack Switch support assembly
4203 035 96891 Plastic holder for On/Off switch
4203 035 96901 Locking arm
4203 035 96911 Locking arm stopper right
4203 035 96921 Locking arm stopper left
4203 035 96931 PCBA 220 - 240 V
4203 035 96941 Motor 220 - 240 V
4203 035 96951 Power cord WEu
4203 035 96961 Power cord CN
4203 035 96971 Power cord TW
4203 035 96981 Power cord UK
4203 035 99611 Power cord AUS
HR1871/00 /05 / HR1873/00
Used materials:
- Housing
- Bottom
- Feet base
- Feet insert
- Speed knob Base Knob : ABS
Knob cover : SAN
- Tray body
- Pulp indication window : SAN
- Spout body
- Spout tube
- Spout accessory
- Juicer lid body
- Juicer ring safety ring
- Pusher
- Pulp container
- Sieve
- Sieve coupling
- Juice jug
- Foam seperator
: ABS
: PP
: PA 6.6
: EPDM rubber
: ABS
: POM
: Stainless steel
: ABS
: SAN
: ABS
: ABS
: ABS
: Stainless steel
: Polyphenylenoxid
incl. 30 % Fibers (PPO GF30)
: SAN
: ABS
