Panasonic SC-PMX5DB Operating Instructions

Draft
Confidential
2/12/2012
Until:
Thank you for purchasing this product.
For optimum performance and safety, please read these
instructions carefully.
Please keep this manual for future reference.
Panasonic Corporation
Web Site: http://panasonic.net
Do the procedures with the remote control. You can Safety precautions
also use the buttons on the main unit if they are the
same.
WARNING!
Your system and the illustrations can look differently.
These operating instructions are applicable to the following
Unit
system.
• To reduce the risk of fire, electric shock or product
System SC-PMX5DB damage,
– Do not expose this unit to rain, moisture, dripping or
Main unit SA-PMX5DB
splashing.
Speakers SB-PMX5
– Do not place objects filled with liquids, such as vases,
on this unit.
– Use only the recommended accessories.
– Do not remove covers.
– Do not repair this unit by yourself. Refer servicing to
qualified service personnel.
CAUTION!
Back of product
Unit
• To reduce the risk of fire, electric shock or product
damage,
– Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure this unit
is well ventilated.
– Do not obstruct this unit's ventilation openings with
newspapers, tablecloths, curtains, and similar items.
– Do not place sources of naked flames, such as lighted
candles, on this unit.
• This unit is intended for use in moderate climates.
• Install this unit so that the AC mains lead can be
unplugged from the socket outlet immediately if any
problem occurs.
• This unit may receive radio interference caused by
mobile telephones during use. If such interference
occurs, please increase separation between this unit
Inside of product
and the mobile telephone.
• This unit utilizes a laser. Use of controls or adjustments
or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
SC-PMX5DBGN_RQT9674-B_gb.indd 1 SC-PMX5DBGN_RQT9674-B_gb.indd 1
Specifications
Amplifier section
RMS output power stereo mode
Operating Instructions
Front Ch (both ch driven)
60 W per channel (3 ), 1 kHz, 10% THD
CD Stereo System
Total RMS stereo mode power
Tuner section
SC-PMX5DB
Preset station FM 30 stations
Model No.
Frequency modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 (unbalanced)
DAB section
DAB memories 20 channels
Frequency band (wavelength)
Band III (AUSTRALIA)
9A to 9C (202.928 MHz to 206.352 MHz)
Band III (XXXXX)
5A to 13F (174.928 MHz to 239.200 MHz)
Sensitivity BER 4x10 -4
Min requirement
DAB external antenna
Terminal F - Connector (75 )
GN
En
RQT9674-B
L0312LL0
Battery – If you see this symbol –
• Do not break open or short-circuit the battery.
Information on Disposal in other Countries outside
• Do not charge the alkaline or manganese battery.
the European Union
• Do not use the battery if the cover has peeled off.
This symbol is only valid in the European
• Do not heat or expose to flame.
Union.
• Do not leave the battery(ies) in a car exposed to direct
If you wish to discard this product, please
sunlight for a long period of time with doors and windows contact your local authorities or dealer and
ask for the correct method of disposal.
closed.
• Remove the battery if you do not use the remote control
for a long period of time. Keep in a cool, dark area.
• Danger of explosion if battery is incorrectly replaced.
Replace only with the type recommended by the
MPEG Layer-3 audio coding technology licensed from
manufacturer.
Fraunhofer IIS and Thomson.
• When disposing the batteries, please contact your local
authorities or dealer and ask for the correct method of
disposal.
"Made for iPod" and "Made for iPhone" mean that an
electronic accessory has been designed to connect
specifically to iPod, or iPhone, respectively, and
has been certified by the developer to meet Apple
performance standards.
Apple is not responsible for the operation of this device
or its compliance with safety and regulatory standards.
Please note that the use of this accessory with iPod, or
iPhone may affect wireless performance.
iPhone, iPod, iPod classic, iPod nano, and iPod touch
are trademarks of Apple Inc., registered in the U.S. and
other countries.
Terminals section Speaker section
USB port Type 3 way, 3 speaker system (bass reflex)
USB standard USB 2.0 full speed Speaker unit(s)
Media file format support MP3 (*.mp3) Woofer
USB device file system FAT12, FAT16, FAT32 Tweeter 1.9 cm soft dome type
USB port power 500 mA (max) Super tweeter
120 W
Headphones jack Impedance
Terminal Stereo, 3.5 mm jack Output sound pressure
AUX input (rear) Pin jack Frequency range 41 Hz to 43 kHz (–16 dB)
48 Hz to 36 kHz (–10 dB)
Disc section
Dimensions (W x H x D) 161 mm x 238 mm x 262 mm
Disc played (8 cm or 12 cm)
Mass
CD, CD-R/RW (CD-DA, MP3 )
General
Pick up
Wavelength 790 nm (CD)
Power supply AC 220 to 240 V, 50 Hz
Laser power CLASS 1
Power consumption
Audio output (Disc)
Dimensions (W x H x D) 210 mm x 120 mm x 266 mm
Number of channels 2 ch (FL, FR)
Mass
FL = Front left channel,
Operating temperature range
FR = Front right channel
Operating humidity range
MPEG-1 Layer 3, MPEG-2 Layer 3
35% to 80% RH (no condensation)
Power consumption in standby mode
–98 dBm
0.4 W (approximate)
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyzer.
Supplied accessories Preparing the remote control
Check and identify the supplied accessories.
1 x AC mains lead
R6/LR6, AA
1 x DAB antenna
Use alkaline or manganese battery.
Install the battery so that the poles (+ and –) align with
those in the remote control.
2 x Speaker cables Point the remote control at the remote control sensor,
away from obstacles, at a maximum range of 7 m directly
in front of the main unit.
1 x Remote control
(N2QAYB000640)
1 x Remote control battery
Overview of controls
Top view
14 cm cone type
Q
1.5 cm piezo type
I
A
R
3
81 dB/W (1 m) J
S
B
F
K
D
C
L
2.6 kg A
D
T
E
40 W
A A Standby/on switch [`], [1] Standby/on switch [`], [1]
F
Press to switch the unit from on to standby mode or
3 kg
vice versa. In standby mode, the unit is still consuming
M
0°C to +40°C a small amount of power.
G N
B Numeric buttons [1 to 9, 0, 10]
To select a 2-digit number
O Example: 16: [ 10] → [1] → [6]
C Delete a programmed track
P
H
D Select audio source
E Basic playback control
F Select the sound effects
View the iPod menu
G
View content information
H
Decrease the brightness of the display panel
Press and hold the button to use this function.
To cancel, press and hold the button again.
Placement of speakers Making the connections
Tweeter
Connect the AC mains lead only after all the
other connections have been made.
1
3
Place the speakers so that the tweeter is on the inner side.
To prevent damage to the speakers, do not touch the
speaker cones if you remove the nets.
Use only the supplied speakers.
To household mains socket
The combination of the main unit and speakers give the
best sound. You can cause damage to the system and
1 Connect the speakers (rear).
decrease the sound quality if you use other speakers.
Note:
Red (q)
• Keep your speakers more than 10 mm from the main
Black (r)
unit for ventilation.
• Put the speakers on a flat safe surface.
• These speakers do not have magnetic shielding. Do
not put them near TVs, PCs or other equipment easily
influenced by magnetism.
• When you play at high levels for a long period, it can
cause damage to the system and decrease the life of
the system.
• Decrease the volume in these conditions to prevent
damage:
– When you play distorted sound.
– When you adjust the sound quality.
CAUTION!
• Use the speakers only with the recommended
system. If not, you can cause damage to the
Silver (r)
amplifier and speakers and can cause a fire.
Consult an approved service personnel if damage
occurs or if there is a sudden apparent change in Be careful not to cross (short-circuit) or reverse
performance. the polarity of the speaker wires as doing so may
damage the speakers.
• Do the procedures included in these instructions
when you attach the speakers.
I Clock and timer operation
J Set the program function
Adjust the volume of the system
K
Mute the sound of the system
L
Press the button again to cancel.
"MUTE" is also cancelled when you adjust the volume
or when you switch off the system.
K
M Set the play menu item
F
N Set the radio menu item
E
O Select the option
W
V Automatically switch off the system
P
This function switches off the system (except in radio
U
source) if you do not use the system for approximately
30 minutes.
To cancel, press the button again.
Q Dock for iPod/iPhone
R Headphones jack ( )
• Plug type: Ø 3.5 mm stereo (not supplied)
• Avoid listening for prolonged periods of time to
prevent hearing damage.
• Excessive sound pressure from earphones and
headphones can cause hearing loss.
• Listening at full volume for long periods may damage
the user's ears.
• Be sure to use the supplied or recommended
headphones or earphones.
S Display panel
T USB port ( )
U Remote control sensor
V Disc tray
W Open or close the disc tray
2
Connect the DAB antenna.
Place the antenna where reception is best.
2
Tapes
Be sure to fully
tighten the nut.
Use DAB outdoor antenna for better reception.
DAB outdoor antenna
(not supplied)
Rear panel of
this main unit
Red
(q)
Be sure to fully
tighten the nut.
3 Connect the AC mains lead.
Black (r) Do not use an AC mains lead from other equipment.
Conserving power
The system consumes approximately 0.4 W when it is
in standby mode. Disconnect the power supply if you
do not use the system.
Copper (q)
Some settings will be lost after you disconnect the
system. You have to set them again.
