Before connecting, operating or adjusting this product,
please read the instructions completely.
Please keep this manual for future reference.
Note:
"EB" on the packaging indicates the United Kingdom.
Operations in these instructions are described using
remote control, but you can do the operations with the
main unit if the controls are the same.
Your unit may not look exactly as illustrated.
Table of contents
Safety precautions ................................ 2
Caution for AC Mains Lead ................... 3
Placement of speakers .......................... 3
Getting started ....................................... 4
Overview of controls ............................. 6
Discs ....................................................... 7
Cassette tape ......................................... 9
Radio ....................................................... 10
Timer ....................................................... 11
Sound adjustment ................................. 12
External unit ........................................... 13
Troubleshooting guide .......................... 14
Specifications ........................................ 15
Maintenance ........................................... 15
E
EB
Operating Instructions
CD Stereo System
Model No.
SUPPLIED ACCESSORIES
SUPPLIED ACCESSORIES
Please check and identify the supplied accessories.
Use numbers indicated in parentheses when asking for
replacement parts. (As of May 2006).
1 x Remote control
(N2QAYB000030)
1 x FM indoor antenna
(RSA0007-L)
2 x Speaker cables
(RFAV0074)
1 x Antenna plug
adaptor
(For the United Kingdom:
K1YZ02000013)
SC-PMX1
1 x AC mains lead
(For the United Kingdom:
K2CT3CA00004)
(For others:
K2CQ2CA00002)
1 x AM loop antenna
(N1DAAAA00002)
2 x Remote control
batteries
RQTV0154-1B
Advertisement
Table of Contents
Related Manuals for Panasonic SC-PMX1
Summary of Contents for Panasonic SC-PMX1
-
Page 1: Table Of Contents
Operating Instructions CD Stereo System SC-PMX1 Model No. Before connecting, operating or adjusting this product, please read the instructions completely. Please keep this manual for future reference. Note: “EB” on the packaging indicates the United Kingdom. Operations in these instructions are described using remote control, but you can do the operations with the main unit if the controls are the same. -
Page 2: Safety Precautions
• Most major credit and debit cards accepted. • All enquiries transactions and distribution facilities are TÄMÄ LAITE ON TARKOITETTU KÄYTETTÄVÄKSI provided directly by Panasonic UK Ltd. LEUDOSSA ILMASTOSSA. • It couldn’t be simpler! • Also available through our Internet is direct shopping for DETTE APPARATET ER BEREGNET TIL BRUK UNDER a wide range of finished products, take a browse on our... -
Page 3: Caution For Ac Mains Lead
– If you see this symbol – Caution for AC Mains Lead Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households) (For United Kingdom) This symbol products and/or (“EB” area code model only) accompanying documents means that used For your safety, please read the following text carefully. -
Page 4: Getting Started
Getting started Step 1 Step 1 - Making the connections - Making the connections Connect the AC mains lead only after all other connections have been made. Connect the FM indoor antenna. Connect the speaker cables. Red (ª) Black (·) Copper (ª) Adhesive Black (·) - Page 5 Optional antenna connections Optional antenna connections FM outdoor antenna AM outdoor antenna FM outdoor antenna AM loop antenna (not included) (included) AM outdoor antenna (not included) 75 Ω coaxial cable (not included) • Never use an outdoor antenna during a lightning storm. •...
-
Page 6: Overview Of Controls
Overview of controls Main unit Main unit Refer to the numbers in parentheses for page reference. AC supply indicator (AC IN) This indicator lights when the unit is Display panel connected to the AC mains supply. Remote control sensor 1 Standby/on switch (y/l) (7, 12) Press to switch the unit from on to standby Cassette slot cover open (9) mode or vice versa. -
Page 7: Discs
Discs Numeric buttons Play Mode function Play Mode function Basic play Basic play Press [CD 6]. Press [y] to turn the unit on. Press [PLAY MODE] to select the desired mode. Press [0] to open the disc tray and then load the disc. - Page 8 Discs (continued) Advanced play Advanced play Press [CD 6] and then [STOP Direct access play Direct access play Press [PROGRAM]. This function allows you to start play from a specific track. Press [ALBUM ] to select your desired album. Press the numeric buttons to select and play your Press /FF/¡/¢] once and then the numeric desired track.
-
Page 9: Cassette Tape
Cassette tape TPS (Tape Program Sensor) TPS (Tape Program Sensor) This function enables you to search the beginning of a track, up to a maximum of 9. Press [ /REW/4/1] or [ /FF/¡/¢] during play. Play resumes from the track found. Note TPS may not function properly: •... -
Page 10: Radio
Radio RDS broadcasting RDS broadcasting Enable you to display the name of a broadcasting station or a program type. Press [DISPLAY] to display: Station Name (PS) Program Type (PTY) Frequency display RDS displays may not be available if reception is poor. Numeric buttons Program type displays... -
Page 11: Timer
Timer Using the play or record timer Using the play or record timer You can set the timer to come on at a certain time to wake you up (play timer) or to record from the radio or music port source (record timer). -
Page 12: Sound Adjustment
Sound adjustment Timer (continued) Other basic operations Other basic operations Action Repeat steps 1 to 4 and 6. ( ➡ page 11) change the settings ˚ change the source 1) Press [ PLAY/REC] to clear the timer or volume indicator from the display. 2) Make changes to the source or volume. -
Page 13: External Unit
External unit Connecting to a portable audio equipment Connecting to a portable audio equipment Enjoying surround sound Enjoying surround sound This feature enables you to enjoy music from portable audio Enable you to add natural width and depth to the stereo equipment. -
Page 14: Troubleshooting Guide
Troubleshooting guide Before requesting service, make the below checks. If you can’t fix the system as described below, or if something not listed here occurs, refer to the enclosed directory to locate an Authorized Service Center convenient to you or contact your dealer. -
Page 15: Specifications
Specifications AMPLIFIER SECTION CD SECTION RMS OUTPUT POWER both channel driven Disc played [8 cm or 12 cm] simultaneously (1) CD-Audio (CD-DA) 10 % Total harmonic distortion (2) CD-R/RW (CD-DA, MP3 formatted disc) 80 W per channel (4 ) (3) MP3 Input impedance Sampling frequency MUSIC PORT... - Page 16 STØT ELLER SKADER PÅ PRODUKTET, MÅ DETTE APPARATET IKKE UTSETTES FOR REGN, FUKTIGHET, VANNDRÅPER ELLER VANNSPRUT. DET MÅ HELLER IKKE PLASSERES GJENSTANDER FYLT MED VANN, SLIK SOM BLOMSTERVASER, OPPÅ APPARATET. Matsushita Electric Industrial Co., Ltd. Web Site: http://panasonic.net RQTV0154-1B L0506CH1066...
