GENEE TECHNOLOGIES
INDIA PRIVATE LIMITED
®
An ISO 9001:2008 certi ed company
Classroom for the Future
6100
®
6100
Classroom for the Future
@
User manual
Tel: 0124-4934500
Email: info.india@geneeworld.com
Website: www.genee-india.com, www.geneeworld.com
Fax: 0124-4934521
WWW
Plot No. 698, Udog Vihar, Phase V, Gurgaon, Harana-122016, India
Advertisement
Related Manuals for Genee World GV6100
Summary of Contents for Genee World GV6100
- Page 1 GENEE TECHNOLOGIES INDIA PRIVATE LIMITED ® An ISO 9001:2008 certi ed company Classroom for the Future 6100 ® 6100 Classroom for the Future User manual Tel: 0124-4934500 Email: info.india@geneeworld.com Website: www.genee-india.com, www.geneeworld.com Fax: 0124-4934521 Plot No. 698, Udog Vihar, Phase V, Gurgaon, Harana-122016, India...
- Page 2 PRECAUTIONS Please follow these precautions: To prevent fire or shock hazard, do not expose the unit to rain or moisture. To prevent electrical shock, do not open the cabinet. Refer to qualified personnel for service only. Do not use the unit continuously for more than 24 hours with camera auto focus on.
-
Page 3: Parts Identification
PARTS IDENTIFICATION... - Page 5 Use the computer RS232 cable (9-pin to 9-pin) to make the connections shown below to control the visualiser from an external computer. USB connection enables capturing still images / video streams from the visualiser to the computer. Special software is required for this operation. 8.
- Page 6 Set up 1 RGB in Set up 1 The simplest set-up, using the RGB lead, to project projector comp in images on to a screen. PROJECTOR Set up 2 Set up 2 LAPTOP 2 This set-up allows you to toggle between the Visualiser, the PC / laptop running RGB in the interactive whiteboard...
- Page 7 PROJECTOR INPUTS SELECTION When the projector is connected to several input sources, use the “Pin” button to switch signal inputs of the projector. (On the remote control, press the “PROJECTOR INPUT” button) Note: Please connect the projector RS232 cable between the projector and the visualiser first. If you cannot switch projector inputs by pressing this button, you need to manually program the RS232 code into the visualiser.
- Page 10 6. If you can not use buttons on the operation panel to control the projector, please use Code-Writing software’s projector control code testing function to check if the control code is correct. Click “Projector” button, the following dialog box appears as below: Connect the visualiser to a computer with a RS232 cable (Please disconnect the projector from the RS232 port first) and select the Baud Rate and Parity based on the projector’s Baud Rate, then click the “TEST”...
