Register your product at www.Toro.com
48in and 52in Bagger
For Zero-Turn-Radius Riding Mower
Model No. 79155—Serial No. 270000001 and Up
The installation of this kit requires a Bagging Blade Kit:
79141 for 48in decks or 79142 for 52in decks.
Contact you local Authorized Service Dealer for more
information.
Form No. 3358-176 Rev A
Original Instructions (EN)
Advertisement
Table of Contents
Related Manuals for Toro 79155
Summary of Contents for Toro 79155
- Page 1 Form No. 3358-176 Rev A 48in and 52in Bagger For Zero-Turn-Radius Riding Mower Model No. 79155—Serial No. 270000001 and Up The installation of this kit requires a Bagging Blade Kit: 79141 for 48in decks or 79142 for 52in decks. Contact you local Authorized Service Dealer for more information.
-
Page 2: Introduction
You may contact Toro directly at www.toro.com for product and accessory information or help finding a dealer. Whenever you need service, genuine Toro... -
Page 3: Table Of Contents
Specifications Contents Introduction ............2 Model Number: Specifications..........3 79155 Safety ............4 Dimensions Training............4 Overall Width with Bagger: Preparation ..........4 48” Deck: 58.0” (147 cm) Operation ..........4 52” Deck: 62.0” (157 cm) Think Safety First........4 Overall Length with Bagger: Slopes............5 48” & 52”Deck: 95” (241 cm) Slope Chart..........6... -
Page 4: Safety
Training operator or bystanders. • Regard the Toro Bagger as a piece of Operation power equipment and teach this regard to all who operate this unit. Although hazard control and accident prevention are partially dependent upon the •... -
Page 5: Slopes
Slopes • • Progressively greater care is needed as Use EXTREME caution when mowing the slope increases. and/or turning on slopes as loss of • traction and/or tip-over could occur. The Always avoid sudden starting or stopping operator is responsible for safe on a slope. -
Page 6: Slope Chart
Slope Chart... -
Page 7: Safety And Instructional Decals
Safety and Instructional Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or lost. PART NO. 109-6809 LOCATION: Inside Hood on bracket 1. Crushing hazard of hand—do not remove the whole bagger from the machine;... -
Page 8: Setup
Setup Note: If your mower does not have mounting Installing the Weight holes on the foot rest, position the back of the weight support assembly on the cross bar Parts needed for this step: under the foot rest. Center the weight support assembly and mark the two mounting holes Description Qty. -
Page 9: Installing The Hood And Bags
2. Install the two 3/8-16 x 5 carriage bolts Installing the Hood and Bags (item 1) through the holes on the frame as Parts needed for this step: shown in Figure 5. Place two stiffeners (item 2) on the top and bottom of the Description Qty. -
Page 10: Installing The Boot Mount Bracket And Tubes
Installing the Boot Mount Bracket and Tubes If you remove the spring-loaded hood Parts needed for this step: when it is closed (in the down position), the hood may suddenly fly Description Qty. open and you or someone else may be Nut, Nyloc 5/16-18 Flg ....... -
Page 11: Installing The Discharge Baffle (52" Deck Only)
Installing the Discharge Baffle – Operation 52” Deck Only Note: The left and right sides of the machine are Parts needed for this step: determined while sitting in the seat in the normal operating position. Description Qty. Baffle, Discharge 52”......Emptying the Grass Bags Bolt, Carriage 5/16-18 x 3/4 .... -
Page 12: Clearing Obstructions From The Bagger
4. Install the bags by sliding the bag frame Removing the Bagger hooks onto the retaining brackets (Figure 12). An uncovered discharge opening will allow objects to be thrown in operator’s or bystander’s direction. Also, contact with blade could occur. Thrown objects or blade contact can cause serious injury or kill you or bystanders. -
Page 13: Replacing The Discharge Deflector
installed. If removed, replace the original hardware in the deck holes. If you remove the spring-loaded hood Replacing the Discharge when it is closed (in the down Deflector position), the hood may suddenly fly open and you or someone else may be bruised, pinched, or injured in another way. -
Page 14: Operating Tips
2. Position the new discharge deflector Operating Tips assembly with the bracket ends between Larger Machine with Bagger the welded brackets on the deck as shown in Figure 13. Remember that the mower is longer and wider with this attachment installed. By turning too 3. - Page 15 As the bagger fills, extra weight is added to the back of the machine. If you stop and start suddenly on hills, you may lose traction and steering control or the machine may tip. • Do not start or stop suddenly when going uphill or down hill.
-
Page 16: Maintenance
Maintenance Note: The left and right sides of the machine are determined while sitting in the seat in the normal operating position. Recommended Maintenance Schedule(s) Maintenance Service Maintenance Procedure Interval After the first 10 operating • Inspect the bagger hours •... -
Page 17: Inspecting The Bagger Attachment
Inspecting the Bagger Cleaning the Bagger Attachment Attachment Inspect the bagger attachment after the first 1. After each use, remove and wash the 10 hours of operation, and monthly inside and outside of the bagger top, thereafter. discharge tube, chute, and the underside of the mower, using water sprayed from a 1. -
Page 18: Tips And Troubleshooting
Always install the original Toro blades, blade bushing, spring disk washers and blade bolts as shown. Note: Refer to mower Operator’s Manual for... -
Page 20: The Toro Total Coverage Guarantee
(Dealer) to obtain guarantee policies for your country, province, or state. If for any reason you are dissatised with your Distributor’s service or have difculty obtaining guarantee information, contact the Toro importer. If all other remedies fail, you may contact us at Toro Warranty Company.
