- Page 1 10203.3TzPrDpsScLbJVSm 10203.3TzDpsScLbJVW 10203.3TzDpsScLbJVSm INSTRUCTION MANUAL BUILT-IN ELECTRIC OVEN IO-CBI-0117 / 8063463 (12.2015./1)
-
Page 2: Dear Customer
DEAR CUSTOMER, The oven is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the oven will be easy. Before being packaged and leaving the manufacturer, the oven was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully. -
Page 3: Table Of Contents
TABLE OF CONTENTS Safety instructions ......................4 Description of the appliance ..................... 8 Installation ......................... 10 Operation ........................... 13 Baking in the oven – practical hints ................30 Cleaning and maintenance ....................31 Troubleshooting........................38 Technical data ........................39... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning... - Page 5 SAFETY INSTRUCTIONS Only use the meat probe recommended for this oven. Danger of burns! Hot steam may escape when you open the oven door. Be careful when you open the oven door during or after cooking. Do NOT lean over the door when you open it.
-
Page 6: How To Save Energy
HOW TO SAVE ENERGY Using energy in a respon- sible way not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: Do not uncover the pan too often (a watched pot never boils!). - Page 7 DISPOSAL OF THE APPLIANCE UNPACKING Old appliances should not sim- During transportation, protec- ply be disposed of with normal tive packaging was used to household waste, but should protect the appliance against be delivered to a collection and any damage. After unpack- recycling centre for electric and ing, please dispose of all electronic equipment. A symbol...
-
Page 8: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Control panel On/Off switch Oven door handle Oven functions Active functions Text messages Temperature Time display Touch controls... - Page 9 SPECIFICATIONS OF THE APPLIANCE Cooker fittings: Grill grate Baking tray* (drying rack) Meat probe* Roasting tray* Side racks *optional...
-
Page 10: Installation
INSTALLATION Installing the oven The kitchen area should be dry and aired and equipped with efficient ventillation. When installing the oven, easy access to all control elements should be ensured. This is a Y–type design built–in oven, which means that its back wall and one side wall can be placed next to a high piece of furniture or a wall. - Page 11 INSTALLATION Adjust the position of the oven door Adjustment mechanism allows you to change the height of right side of the oven door as limited by its design. Oven door height adjustment on one side allows you to level the door and align it with the control panel. Adjustment method Loosen the nut [1] with size 13 open-end wrench.
-
Page 12: Electrical Connection
INSTALLATION Electrical connection Warning: This appliance must be earthed. The appliance must be installed by a com- petent electrician using a double pole control unit of 16 ampere minimum capacity with 3 mm minimum contact separation at all poles. We recommend that the appliance is con- nected by a qualified electrician who is mem- ber of the N.C.E.I.C. -
Page 13: Operation
OPERATION Before using the appliance for Important! the first time The oven features touch control panel and display. To activate each touch sensor, touch the glass above the Remove packaging, clean the interior of sensor (indicated by a pictogram). An the oven, acoustic signal will be heard. -
Page 14: Using The Control Panel
OPERATION Using the control panel Touch controls The control panel features 12 touch sensors (no backlight), marked as shown above. Each time you touch a sensor a beep is emitted (except as indicated in detailed operating instruc- tions). On/off switch is on the right side of the display. - Page 15 OPERATION - clock settings - kitchen timer, duration, end time settings - plus / up [+] - minus / down [-] - back [<] - confirm Oven functions Oven functions are indicated as follows: Display backlight brightness. Backlight brightness changes throughout the day. Backlight brightness is set to high during 05:00—22:00 and low during 22:00—05:00. Backlight bright- ness is also determined by the oven operating mode: ...
- Page 16 OPERATION Temperature Oven cavity temperature and heating indicator........Meat probe and activation indicator............. Start Time/ End Time and activation indicator........Time display HH:MM time display and symbols: AM/PM, kitchen timer, duration, end time Text messages Text information area includes 2 lines x 34 characters for displaying text information in the following languages: English, German, Polish, Russian, Czech, Serbian, Lithuanian, Estonian, Latvian, French, Spanish, Turkish, Swedish, Norwegian, Finnish, Danish, Italian, Dutch.
- Page 17 OPERATION Turn on the appliance and set the time. Standby mode When you plug in the appliance for the first In this mode, the power consumption of the time you need to select the language. The appliance is limited to 800mW (except when display is off except the text messaging area. cooling down or using the light).
- Page 18 OPERATION Operation. Clock In this mode you can select the desired Touch and hold for a few seconds to functions, programmes and adjust settings. change the current time. In turn you can You can use and sensors that set time display mode (12h/24h), hours and activate the Child Lock.
- Page 19 OPERATION Light Heating functions Touch to select heating functions. You sensor operates independently and can use the following controls: using it does not affect other functions and – open pre-set programmes menu (clear settings. sensor is inactive in a standby unconfirmed settings);...
- Page 20 OPERATION ter 5 seconds of confirming. Function Description [Duration ] symbol is displayed and time conventional display shows time that has elapsed. You can cancel a heating programme at any cake time. Touch: rotisserie – you can select pre-set programmes; grill – standby mode. turbo grill Set the timer to control if the oven is on/off.
- Page 21 OPERATION Meat probe* Fast oven cavity heat-up. If you plug in the meat probe before select- When you select the heating function and ing the heating function, you can set the temperature the fast heating function be- meat probe immediately after setting the comes available.
- Page 22 OPERATION Recommended meat probe temperature Timer. settings Touch to access timer settings. You oven Type of meat Temperature features a timer, which is not affected by [°C] other settings. You can set Duration or End Pork 85 - 90 Time and Duration. Touch to set Kitchen Beef 80 - 85...
- Page 23 OPERATION ration). The symbol indicator flashes and or do nothing for 5 seconds to abort or "0:00" is shown (or, if the function has been touch OK to confirm. Once End Time is con- previously activated, the remaining duration firmed the symbols light up stead- until the oven turns off). Touch ily and the Current Time is shown again. adjust settings. Touch or do nothing for 5s indicators are on during the to abort and keep previous settings or touch...
- Page 24 OPERATION Child Lock Child lock is designed to prevent children from changing the oven settings. Once the child lock is activated the oven stops responding to any controls except the unlocking com- bination. You can activate the Child Lock (lock the touch sensors) at any time.
- Page 25 OPERATION Door Pre-set programmes Oven door must be closed during operation. Pre-set programmes are pre-defined heat- If the door is opened during appliance op- ing functions including temperature and eration, the heating elements are discon- times to specific cooking applications. You nected and the light is on.
- Page 26 OPERATION ed group are displayed on the right. settings such as temperature, heating func- When you confirm, the selected pre-set pro- tion and times are applied and the pro- gramme is displayed on the left side. gramme starts. "Programme in progress" message will be displayed. Adjust settings. If meat probe is plugged in but you select a Start programme with fast heat-up pre-set programme that does not use a meat...
- Page 27 OPERATION Cleaning programme. When you confirm door status is checked. If the door is open the message "Close oven Cleaning programme can be found in the door and touch OK to start" is displayed. If "Heating functions", but it operates much the door is closed the message is displayed: like pre-set programmes.
- Page 28 OPERATION Settings menu 2. Light Touch together to enter setup "Select light mode" is displayed on the left. menu. The appliance must be in operating Available options are displayed on the right: mode to enter setup. Continuous and ECO. The default is the cur- Menu navigation: rent setting and the factory setting is: ECO.
- Page 29 OPERATION confirm, you will see "Operation display The message will be shown: Restore factory brightness" or "Standby display brightness" settings? Touch OK to restore factory set- or "Night display brightness" depending on tings and go back or to abort and go back. your choice.
-
Page 30: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking we recommend using the baking trays which were provided with your cooker; it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;... -
Page 31: Cleaning And Maintenance
CLEANING AND MAINTENANCE Proper routine maintenance and cleaning of Important! the oven can significantly extend its trouble- Do not use any abrasive agents, free operation. harsh detergents or abrasive ob- Turn off the oven before cleaning. jects for cleaning. Do not begin cleaning until the Only use warm water with a small oven has cooled. - Page 32 CLEANING AND MAINTENANCE Ovens have stainless steel sliding tel- escopic runners attached to the wire shelf supports The telescopic runners should be removed and cleaned together with the wire shelf supports. Before you put the baking tray on them, they should be pulled out (if the oven is hot, pull out the telescopic runners by hooking the rear edge of the baking tray at the front of the...
- Page 33 CLEANING AND MAINTENANCE Pyrolytic cleaning* Important! During pyrolytic cleaning, the oven Oven pyrolytic self-cleaning. The oven heats chamber can reach a very high tem- up to a temperature of about 480°C. Grilling perature. Consequently, the outer or baking residue is burnt into an easy to re- oven surfaces can heat up more than move ash that can be wiped off with a damp usual, so keep children away at all...
- Page 34 CLEANING AND MAINTENANCE Replacing the halogen bulb in the oven Note: Do NOT touch the halogen bulb di- rectly with your fingers! Before replacing the halogen bulb, make sure the appliance is disconnected from the electric mains to avoid a possible Replacing the halogen bulb in the oven electric shock.
-
Page 35: Door Removal
CLEANING AND MAINTENANCE Removing the inner panel* Door removal 1. Using a flat screwdriver unhook the up- per door slat, prying it gently on the sides In order to obtain easier access to the oven (fig. B). chamber for cleaning, it is possible to remove 2. Pull the upper door slat loose. (fig. B, C) the door. - Page 36 CLEANING AND MAINTENANCE Removing the inner panel* 3. Pull the inner glass panel from its seat 1. Using a cross-head screwdriver undo (in the lower section of the door). Re- the screws in the upper door slat (fig. B). move the inner panel (fig. D). 2. Using a flat screwdriver remove the up- 4. Clean the panel with warm water with per door slat, prying it gently on the sides some cleaning agent added.
- Page 37 CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat Regular inspections (in the lower section of the door). Important! Risk of damage to glass Besides keeping the oven clean, you should: panel mounting. Do not lift the glass ● carry out periodic inspections of the con- panel up but pull it out.
-
Page 38: Troubleshooting
TROUBLESHOOTING In the event of any fault: turn off the appliance, disconnect the power supply, based on the instructions given in the table below, some minor issues can be corrected by the user. Please check the consecutive points in the table before you refer the repair to customer service. -
Page 39: Technical Data
TECHNICAL DATA Electrical supply 220-240V ~50Hz Maximum load 3,1 kW Oven: bottom heater 1,1 kW top heater 0,9 kW grill 2,0 kW ultra-fan 2,0 kW Cooker dimensions H/W/D 59,5 / 59,5 / 57,5 cm Complies with EU regulations EN 60335-1, EN 60335-2-6 standards Certificate of compliance CE The Manufacturer hereby declares that this product complies with the general requirements pursuant to the following European Directives:...
