Table of Contents ....................................................................................... 1
Usage Notice .............................................................................................. 2
Precautions ......................................................................................................... 2
Introduction ................................................................................................ 4
Product Features ................................................................................................ 4
Package Overview ............................................................................................. 5
Product Overview ................................................................................................ 6
Main Unit ........................................................................................................................ 6
Control Panel ................................................................................................................ 7
Connection Ports .......................................................................................................... 8
Remote Control ............................................................................................................. 9
Installation ............................................................................................... 10
Connecting the Projector .................................................................................. 10
Powering On/Off the Projector .......................................................................... 11
Powering On the Projector ......................................................................................... 11
Powering Off the projector .......................................................................................... 12
Warning Indicator ....................................................................................................... 12
Adjusting the Projected Image ......................................................................... 13
Adjusting the Projector Image Height ........................................................................ 13
Adjusting the Projector Zoom / Focus ....................................................................... 14
Adjusting Projected Image Size ................................................................................. 14
User Controls ............................................................................................ 15
On-Screen Display Menus ............................................................................... 18
How to operate ............................................................................................................ 18
Language ..................................................................................................................... 19
Image-I ......................................................................................................................... 20
Image-II (Computer Mode) ......................................................................................... 22
Image-II (Video Mode) ................................................................................................ 24
Audio ............................................................................................................................ 26
Management ................................................................................................................ 27
Lamp Setting ............................................................................................................... 29
Appendices .............................................................................................. 30
Troubleshooting ............................................................................................... 30
Replacing the lamp .......................................................................................... 34
Compatibility Modes ........................................................................................ 35
Ceiling Mount Installation ................................................................................. 36
