Parts List - Omega Engineering HH-21 User Manual

Schematic
Designation*
C1, 2, 17
C3, 9, 10
C4, 8, 11, 13, 14
C5, 6, 7
C12
C15, 16
CON1 (1)
CON2
CON3
CON4 (1)
D1
DS1
J1
Q1, 3
Q2
R1, 2, 30, 31
R3, 4, 9, 13, 14, 15, 16,
32
R5, 6
R7, 21, 24, 25, 26, 27,
28, 33
R8
R10
R11
R12
R17, 18, 19, 29, 39,
40, 41
R20
R22, 42
R34
R35, 36
R37, 38 (1)
R23
U1
U2
U3
U4, 5
U6
U7, 10
U8, 14 (2)

5. PARTS LIST

Description
Capacitor, Polyester
Capacitor, Aluminum
Capacitor, Ceramic
Capacitor, Ceramic
Capacitor, Aluminum
Capacitor, Ceramic
Connector, TC
Connector, TC
Connector, Right Angle
Connector, Pwr Jack
Diode, Zener
Display, Liquid Xtal
Plug, Shorting
Transistor, PNP
Transistor, NPN
Resistor, Carbon
Resistor, Metal Film
Resistor, Metal Film
Resistor, Metal Film
Resistor, Metal Film
Resistor, Metal Film
Resistor, Metal Film
Resistor, Metal Film
Resistor, Carbon
Resistor, Metal Film
Resistor, Metal Film
Resistor, Carbon
Resistor, Carbon
Resistor, Metal Film
Resistor, Carbon
I.C., Band-Gap Ref.
I.C., Temp. Sensor
I.C., Analog Mux.
I.C., Op. Amp.
I.C., NAND
I.C., D-Flop
I.C., Regulator
Part Number
C-344-.1
C-513-33
C-237-.1
C-237-220P
C-513-1
C-237-100P
CS-613
CS-613
CS-614
CS-615
DZ-213
DD-203
CS-791
TG-84
TG-47
R-76-15M
R-88-1K
R-88-909K
R-88-10K
R-88-23.7K
R-88-42.2
R-88-9.09K
R-88-1M
R-76-100K
R-88-210K
R-88-365K
R-76-22K
R-76-1M
R-88-1.58K
R-76-220K
DZ-62
IC-850
IC-277
IC-765
IC-102
IC-103
IC-837-2
23
