LOGIJET T4
LOGIJET T6
LOGIJET T4 RFID
LOGIJET T6 RFID
Operator's Manual
Edition 1.3L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOGIJET T4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microplex LOGIJET T4

Summary of Contents for Microplex LOGIJET T4

  • Page 1 ________________________________________________________________________________ LOGIJET T4 LOGIJET T6 LOGIJET T4 RFID LOGIJET T6 RFID Operator’s Manual Edition 1.3L ________________________________________________________________________________...
  • Page 2 _______________________________________________________________________________________________ _______________________________________________________________________________________________...

  • Page 3: Table Of Contents

    Roll-Fed Media Handling 5.2.1. Tear Off Media Loading 5.2.2. Media Removal 5.3. Handling of Ribbon (Foil) 5.3.1. Ribbon Loading 5.3.2. Ribbon Tension Adjustment 5.3.3. Ribbon Removal 5.4. Printhead Pressure Adjusting _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 4 Transparent Code Adjustment 7.17. Selection of Memory Distribution (Input Buffer) 7.18. Setting to Factory Default 7.19. Font Selection 7.20. Text Orientation Selection 7.21. Symbol Code Selection 7.22. Print Speed Adjustment _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 5 Writing Data into a Data Block of the RFID Label 8.4.4. Generating a Page ID Number, Receiving the RFID data after Printing 8.5. Syntax of RFID Data (Status Messages) 8.6. RFID Errors _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 6 Configuration of the Status Channel 13.1.1. Status Messages automatically or on Request 13.1.2. Changing the Separator and Terminator Characters 13.2. Survey of Print Job Status Messages 13.3. Survey of Printer Status Messages 14. Index _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 7: Introduction

    The printers LOGIJET T4 and LOGIJET T6 are provided with a controller that is also used in SOLID laserprinters. So the advantages of the thermal print technology are combined with the flexibility of the „laserprinter intelligence“.

  • Page 8: Information On Rfid Technology

    Introduction _______________________________________________________________________________________________ 1.2. Information on RFID Technology The MICROPLEX printers LOGIJET T4 RFID and LOGIJET T6 RFID are provided with an integrated multi-protocol RF Write/Read module. The printer functions as a complete system for writing, reading and printing RFID labels (Radio Frequency IDentification), when it is connected to a host computer.

  • Page 9: Fundamentals Of Thermal Printing

    The dyes and developers within the paper respond to the heat of particular dots, change their colour to black and so the wanted image emerges. The LOGIJET T4 /T6 /RFID printers can be used for both methods of printing. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 10: Conventions

    Link to another chapter or a different document. By clicking the blue colored text blue colored text you'll enter the concerning chapter or document. [Menu Level 1 ] This symbol represents messages shown in the display (panel). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 11: Ce - Conformity

    Also the generic standard EN 50082-1/DIN VDE 0839 for interference strength is complied. The LOGIJET T4 RFID and LOGIJET T6 RFID printers incorporate an integrated compact reader (RF Write/Read module). The Declaration of Conformity can be found in section 8.1 Integrated RF Write/Read module.

  • Page 12: _______________________________________________________________________________________________

    Introduction _______________________________________________________________________________________________ This MICROPLEX product and its consumables are designed and tested according to strict safety standards. Heeding the following instructions ensures secure operation: - Please make sure your electricity source is appropriately grounded. - Install the device on solid and level ground.

  • Page 13: _______________________________________________________________________________________________

    - After switching off the device, wait at least 15 seconds before the device is switched on again. - Please follow all the information and hints directly attached to the device and/or described in this manual. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 14: Installation

    Take hold of the printer from the bottom. Do not use other parts of the printer (e.g. plastic parts at the printer's front or rear side ...) to lift the device! _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 15: _______________________________________________________________________________________________

    Remove the foil covering the printer. Place the printer onto a suitable base (see section 2.3). Please retain the original packing materials in case the printer has to be transported in the future. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 16: Check List

    Open the cardboard box carefully and check the contents: 1. Printer LOGIJET T4 /T6 /RFID 2. Power cord 3. Data cable (USB) 4. CD containing: • Operator’s Manual for LOGIJET T4 /T6 /RFID • Print drivers • IDOL Programming Manual Fig. 2.2.a Accessories _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 17: Printer Installation

    Relative atmospheric humidity: 30% to 85% (without condensation) - Do not expose the printer to abrupt temperature changes (heating, window or air condition). - The printer should not be exposed to direct sunlight. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 18: Printer Components

    Fig. 2.4.a Main view of the printer Rear view: Centronics interface USB interface Ethernet interface Power switch Input power connector Fig. 2.4.b Rear view of the printer _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 19: _______________________________________________________________________________________________

    Printer mechanism Lower cover Printhead pressure lever Fig. 2.4.c Printer opened Dispense Ribbon sensor supply shaft Tear off edge Ribbon Platen roller rewind shaft Fig. 2.4.d Details printer mechanism _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 20: Media And Ribbon Requirements

    This media includes the label, backing, and an RFID transponder inlay encased by the label material. High quality RFID labels are recommended to ensure against premature printhead wear. We strongly recommend the use of MICROPLEX supplies for continuous high- quality printing. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 21: Basic Operation Sequences 21

    8 m a r g i n s e t t i n g s e e c h a p t e r 7 _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 22: _______________________________________________________________________________________________

    An output of the current setting values can be generated using the "Printing the Status Sheet“ panel function (see section 7.6). Detailed information on the operations above and to further functions of the printer LOGIJET T4 /T6 /RFID can be found in the following chapters. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 23: Handling Of Consumables

    (see chapter 6 and 7) fit to the printer implementation (ribbon inserted /not inserted). Ribbon and material should only be inserted/exchanged by specially instructed personnel. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 24: Winding Diagram

    5.3.1 Ribbon Loading. The figure above shows the winding directions for “Ink inside the roll” ribbons. Also pay attention to the instructions located on the inside of the printer hood. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 25: Roll-Fed Media Handling

    Fig. 5.2.1.a Goring the tear off roll-fed media Switch the printer to OFF LINE mode. Open the printer hood. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 26: _______________________________________________________________________________________________

    Pull the label supply guide rightward. Label supply guide Fig. 5.2.1.c Pulling the label supply guide rightward. Swivel the label supply guide upward. Fig. 5.2.1.d Swivelling the label supply guide upward _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 27: _______________________________________________________________________________________________

    Swivel the label supply guide downward. Slide the label supply guide in towards the label roll (as shown in the right figure below). False Fig. 5.2.1.f Please refer to the right photo! _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 28: _______________________________________________________________________________________________

    11. Slide the material guide to its outermost position. (Compare figure 5.2.1.j). 12. Feed the label through under the label tension plate (under the moveable sensor) to the tear off bar. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 29: _______________________________________________________________________________________________

    13. Align the media to ensure a straight transport. 14. Slide the material guide inwards until it contacts the edge of the media, without deforming the media. Fig. 5.2.1.j Setting the material guide _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 30: _______________________________________________________________________________________________

    Fig. 5.2.1.k Adjusting the sensor position 16. The right position is found when the pointer is located above the material’s gap. Pointer Fig. 5.2.1.l The pointer indicates the sensor position _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 31: _______________________________________________________________________________________________

    - There is a danger of fingers, hair, clothing, jewellery etc. being drawn into the machine in the vicinity of the ribbon and media transport unit. 18. Close the hood of the printer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 32: Media Removal

    Remove the roll with the tear off roll-fed media (if necessary protect the media against unintentional unwinding first). Close the hood of the printer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 33: Handling Of Ribbon (Foil)

    Fig. 5.3.1.a Pull the printhead pressure lever out and swivel it upward (counterclockwise). Take the ribbon roll and remove the protection foil, if necessary (by unwinding it and cutting it off). Find out the right winding direction for your ribbon roll: _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 34: _______________________________________________________________________________________________

    Slide the empty ribbon sleeve (ribbon core) onto the ribbon rewind shaft. Route the ribbon around the printhead without folds. Be sure you don’t feed the ribbon underneath the moveable sensor. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 35: _______________________________________________________________________________________________

    Make sure that the ribbon rewind direction is correct. (Compare figure 5.3.1.b.) Rewind shaft Fig. 5.3.1.e Tautening the ribbon by turning the ribbon rewind shaft _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 36: _______________________________________________________________________________________________

    If necessary, tauten the ribbon by turning the rewind shaft. 11. Swivel the printhead pressure lever clockwise back to its original position making sure it clicks into place. Printhead pressure lever Fig. 5.3.1.f Locking the pressure lever _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 37: Ribbon Tension Adjustment

    " Adjusting ring Fig. 5.3.2.a Adjusting the ribbon tension at the ribbon rewind shaft _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 38: _______________________________________________________________________________________________

    Check to see that slack and wrinkles on the ribbon are removed completely. Do not be afraid to ’waste’ a little extra ribbon to ensure the ribbon is running correctly and wrinkle-free. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 39: _______________________________________________________________________________________________

    Check to see that slack and wrinkles on the ribbon are removed completely. Do not be afraid to ’waste’ a little extra ribbon to ensure the ribbon is running correctly and wrinkle-free. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 40: Ribbon Removal

    If the inserted ribbon is not used-up, cut it close to the ribbon rewind shaft. Rotate the ribbon supply shaft until the free end of the ribbon is winded up. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 41: _______________________________________________________________________________________________

    Remove the used-up ribbon from the rewind shaft and dispose it according to the rules. The media for thermal direct printing has to be loaded as described in section 5.2.1. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 42: Printhead Pressure Adjusting

    - Excessive contact pressure can result in premature wearing of the printhead. - See also section 9.2 Printhead Exchange and section 9.3 Adjusting the Right Pressure Value. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 43 Normally, the wider the paper, the farther the spring boxes on the right side have to be positioned from the center wall (and vice versa for small labels). Fig. 5.4.c Lateral shifting of the spring boxes _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 44: _______________________________________________________________________________________________

    Printhead pressure lever Fig. 5.4.e Locking the pressure lever The following picture helps you to locate the setting screws for the printhead pressure: _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 45: _______________________________________________________________________________________________

    If one side of the printed material is not being printed clearly, or if ribbon wrinkles occur, then adjust the thermal printhead spring box position or pressure appropriately to cure the problem. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 46: Control Panel

    2. Use a proper interface line to connect the printer to the computer or to attach the printer to the network. The printers LOGIJET T4 /T6 /RFID are provided with several interfaces; see figure 2.4.b and chapter 12 Specifications for more information.

  • Page 47: Control Panel View

    6.3. Control Panel View Power Ready Error LEDs (3 units) ON LINE LOGIJET T6 RFID Display OFFL. FEED CANCEL PAUSE Current designation /meaning of the function keys Function keys (3 units) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 48: Function Of The Control Panel Elements

    *) This innovation was created to make this printers — in spite of their small number of panel keys — flexible in operation. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 49: _______________________________________________________________________________________________

    The MENU key (panel key on the right) is used to enter menu level 1. Now the following key designations are available: Power Ready Error OFFLINE Menu Level 1 NEXT ENTER Current meaning of the FEED PAUSE CANCEL function keys _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 50: _______________________________________________________________________________________________

    The descriptions above are valid in a similar manner for getting access to the key designation VAL-. (Alternation from VAL+ to the key designation VAL- to enable the reduction of function values.) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 51: Configuration Via The Control Panel

    In addition a software (called printADMIN) will be available for the LOGIJET T4 /T6 /RFID printers to allow a printer configuration via Ethernet. The controller has its integrated website with information on the printer status and the printjob status.

  • Page 52: Menu Structure

    Access to the menu structure is possible as soon as the printer is turned OFF LINE and the MENU key was pressed. The menu structure of the printers LOGIJET T4 /T6 /RFID is arranged in different levels: O N LIN E m od e C U T O FFL.

  • Page 53: _______________________________________________________________________________________________

    The ENTER key has two main functions. It gives the user access ENTER to a particular menu and, once in the menu, it allows the user to select a particular function. ["Function"] _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 54: _______________________________________________________________________________________________

    If the ESC key is pressed instead, the changes are only stored temporary (not saved as setup). (This key takes the user to the respective previous menu level). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 55: _______________________________________________________________________________________________

    Pressing the ESC key shortly takes the user to the respective previous menu level. Aim is to jump back to the OFF LINE mode, where the key ONL. designation ONLINE is available. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 56: Syntax Of Diagrams

    ENTER The ″Panel display″ column shows the display messages ["Message"] corresponding to the sequences listed on the left. In the column ″Notes″ explanations to particular operational steps are given. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 57: Panel Functions

    For thermal direct printing it is not allowed to insert a ribbon to avoid damaging the printhead. Make sure your settings match to the printer implementation (ribbon inserted/not inserted). Description of this control panel function continues on the next page. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 58: _______________________________________________________________________________________________

    In addition this new value can be EN TER saved as setup value (using the ENTER key). After this decision turn the printer EN TER ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 59: Media Setting (Material; Label Or Continuous)

    In addition this new value can be EN TER saved as setup value (using the ENTER key). After this decision turn the printer EN TER ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 60: Page Length Adjustment

    In addition this new value can be saved as EN TER setup value (using the ENTER key). After this decision turn the printer ON LINE EN TER again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 61: Starting The (Printer's) Measurement Of Label Length

    Use the ENTER key to start the measurement of label length, use the ESC key to suppress this function. The printer saves the measured label length temporal (as long as the printer stays turned on). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 62: Material Width Adjustment (Paper Width)

    In addition this new value can be saved as setup value (using the ENTER key). After this decision turn the printer ON LINE again: EN TER Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 63: Configuration Of Text Margins

    In addition this new value can be saved as EN TER setup value (using the ENTER key). After this decision turn the printer ON LINE again: Press the ENTER key longer EN TER than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 64: Printing The Status Sheet

    [Status Sheet ] Press the ENTER key again. ENTER A status sheet is printed. [Status Sheet ] ENTER Turn the printer ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 65: _______________________________________________________________________________________________

    / left bottom / right Default character code Options Fonts installed (Font banks) Note: Use the panel function Printing the Font List to show the fonts installed (see the following section). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 66: Printing The Font List

    & & & [Font List ] ENTER The font list is printed. [Font List ] Turn the printer ON LINE again: ENTER Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 67: Hexdump-Mode Activation

    Hexdump Mode. Time between turning the printer off and on again should be at least 15 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 68: Normal Print Mode Activation (Incl. Form Feed)

    This is necessary because after a test in the Hexdump Mode it is possible that data can remain in the input buffer unintentionally (cause: in the Hexdump Mode no control characters are evaluated and no FORM FEED is effected). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 69: Clearing The Input Buffer (Cancel Job)

    [Cancel Job ] ENTER All data contained in the input buffer will be cleared. [Cancel Job ] ENTER Turn the printer ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 70: Printing The Menu Page

    & & & until [Menu Page ] is displayed. [Menu Page ] ENTER A menu structure presentation of the LOGIJET T4 /T6 /RFID is printed out (compare section 6.6). [Menu Page ] ENTER Turn the printer ON LINE again: Press the ENTER key longer than 2 seconds.

  • Page 71: Generating Test Prints (Sliding Pattern)

    [Sliding Pattern ] Turn the printer ON LINE again: ENTER Press the ENTER key longer than 2 seconds. The printing out of test prints can be stopped by pushing the ESC key. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 72: Data Interface Selection

    LINE again: Press the ENTER key longer than 2 seconds. Note: The printer uses SIA (Simultaneous Interface Administration) to check, which interface is currently used for the transfer of print data. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 73: Emulation Selection

    In addition this new value can be saved as setup value (using the ENTER EN TER key). After this decision turn the printer ON EN TER LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 74: _______________________________________________________________________________________________

    Eltron EPL2, ZPL II (Zebra Programming Language) Optional: TIFF (CCITT group 4), Kyocera Prescribe, Printronix IGP/PGL, µPostscript Notice: The brand names mentioned are registered trademarks of the enterprises named above. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 75: Display Language Selection

    In addition this new value can be saved as setup value (using the EN TER ENTER key). After this decision turn the printer EN TER ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 76: Transparent Code Adjustment

    In addition this new value can be saved as EN TER setup value (using the ENTER key). After this decision turn the printer ON LINE EN TER again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 77: Selection Of Memory Distribution (Input Buffer)

    In addition this new value can be saved as setup value (using the ENTER key). EN TER After this decision turn the printer ON LINE again: Press the ENTER key EN TER longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 78: Setting To Factory Default

    Only if you press the ENTER key a EN TER second time the configuration will be back-outed to factory defaults. EN TER Turn the printer ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 79: Font Selection

    In addition this new value can be saved as setup value (using the EN TER ENTER key). After this decision turn the printer EN TER ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 80: _______________________________________________________________________________________________

    Panel Functions ________________________________________________________________________________________________ The LOGIJET T4 /T6 /RFID standard equipment contains the following fonts: Font no. Font width Font height Font name 0600 Kurilen 0602 Kurilen Italic 0610 10.1 Kurilen 1710 10.1 Kurilen Italic 4508 Helgoland 4510 Helgoland 4714 14.4...

  • Page 81: _______________________________________________________________________________________________

    Additional fonts can be selected from the font catalogue depending upon the memory capacity. You can use the panel function Printing the Font List (see section 7.7) to generate a list of all fonts installed to the printer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 82: Text Orientation Selection

    2 seconds. Text orientation assignment: Orientation 0 = Portrait (upright format) Orientation 1 = Landscape (horizontal format) Orientation 2 = Portrait upside down Orientation 3 = Landscape upside down _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 83: Symbol Code Selection

    In addition this new value can be EN TER saved as setup value (using the ENTER key). After this decision turn the printer EN TER ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 84: Print Speed Adjustment

    In addition this new value can be saved as setup value (using the EN TER ENTER key). After this decision turn the printer ON LINE again: Press the ENTER key EN TER longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 85: Contrast (Density) Setting

    LINE again: Press the ENTER key longer than 2 seconds. * Note: Please consider that using high contrast values (more than 100%) can result in a reduced lifetime of the printhead. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 86: Image Shifting To The X-Direction

    In addition this new value can be saved as setup value (using the ENTER key). EN TER After this decision turn the printer ON LINE again: Press the ENTER key longer EN TER than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 87 X-direction. In this example the value of the Image X-Position was Feed increased (NEXT key). direction (print direction) Previous position of the printout margin (prior to the image shifting) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 88: Image Shifting To The Y-Direction

    In addition this new value can be saved as setup value (using the ENTER key). EN TER After this decision turn the printer ON LINE again: Press the ENTER key EN TER longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 89 Y-direction. direction In this example the value of the (print Image Y-Position was increased direction) (NEXT key). Previous position of the printout margin (prior to the image shifting) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 90: Selecting The Light Sensor Type

    In addition this new value can be saved as setup value (using the ENTER EN TER key). After this decision turn the printer ON EN TER LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 91: Automatic Sync Sensor Adjust

    This function serves to adjust the printer’s Sync Sensor to the material in use. If this automatic function does not work with your specific print material, please read the following section: Manual Sync Sensor Adjust. 7.27.1. Overview _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 92: Example

    In addition this new value can be saved EN TER as setup value (using the ENTER key). After this decision turn the printer ON EN TER LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 93: Manual Sync Sensor Adjust

    Higher contrast values are more advantageous so long as there is no rising of the masking paper level. If this conditions are not satisfied, you have to adjust the Sync sensor current as well. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 94: Overview: Level And Current Adjusting

    Panel Functions ________________________________________________________________________________________________ 7.28.1. Overview: Level and Current Adjusting _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 95: Description Of Level And Current Adjusting

    If the adjusting of the Gap Sync sensor failes because the contrast value of the label material itself is very low, use the panel function Sync.Sens.Logic to invert the logic. (Black marks can be used as “inverse gaps” in this way.) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 96: Example

    24 %. So the reading 75 % at the black bar will be ignored. The steps to adjust the Sync sensor level can be found on the following page. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 97 In addition this new value can be EN TER saved as setup value (using the ENTER key). After this decision turn the printer ON EN TER LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 98: Peripheral Device Activation (Tear Off Edge, Cutter)

    [Service Mode ] is displayed shortly. [Service Mode ] Now the functions of the service mode are available (compare dashed areas in the Menu Structure of section 6.6). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 99 & & & displayed. [Cutter ] ENTER The cutter (option) is selected. [Saved! ] Turn the printer ON LINE again: ENTER Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 100: Selecting The Tear Off Mode (Option: Cutting Mode)

    In addition this new value can be saved as setup value (using the EN TER ENTER key). After this decision turn the printer ON LINE again: Press the EN TER ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 101 Cutting Menu instead of the Tear Off Menu. The adjustment of the cutting parameters has to be done in the same way as it is described for the tear off functions in the following section. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 102: Selecting The Print Mode

    In addition this new value can be saved as setup value (using the ENTER EN TER key). After this decision turn the printer ON LINE again: Press the ENTER key EN TER longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 103 Transponder Position as well as the comments in figure 8.4.1.a). Using the optional cutter, RFID labels equipped with a tag position shorter than 31 mm are cutted not before the next page is ready to print. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 104 Transponder Position as well as the comments in figure 8.4.1.a). Using the optional cutter, RFID labels equipped with a tag position shorter than 31 mm are cutted not before the next page is ready to print. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 105: Adjusting The Tear Off Position (Option: Cutting Position)

    EN TER LINE again: Press the ENTER key longer than 2 seconds. # If a cutter is installed and activated, the concerning panel function Cutting Position has to be used. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 106: Configuration Of Network Parameters (Ip Address, E.g.)

    [192.168.010.123 ] be). The new IP address is saved as setup value. ENTER [Saved ! ] Turn the printer ON LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 107 (compare section 6.6 Menu Structure). Select the subitem Off from the network menu to switch off the network access. " Dynamic Host Configuration Protocol: offers among other things a centralized address management. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 108 Capability of a device for sending and receiving data at the same time. In the case of full duplex, collision detection is deactivated. A full duplex capable device is able to buffer data packets. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 109: Using The Rfid Functions

    Using the RFID Functions _______________________________________________________________________________________________ 8. Using the RFID Functions The LOGIJET T4 RFID and LOGIJET T6 RFID printers incorporate an integrated compact reader (RF Write/Read module). 8.1. Integrated RF Write/Read module A Block diagram of High Frequency Identification technology (RFID, Radio Frequency IDentification) is shown in section 1.2 Information about RFID...
  • Page 110 Using the RFID Functions _______________________________________________________________________________________________ _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 111: Rfid Panel Functions

    In addition this new value can be saved as setup value (using the ENTER EN TER key). After this decision turn the printer ON EN TER LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 112: Selecting The Communication Protocol

    [ISO18000-6b ] ENTER The protocol ISO18000-6b is selected (saved as setup value). [Saved ! ] Turn the printer ON LINE again: ENTER Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 113: Adjusting The Transponder Position (Tag Position)

    Using the ENTER key this new value can be saved as setup value. After this decision turn the printer ON EN TER LINE again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 114 - Set the transponder position manually (see next page). - If there is still no proper access to the RFID tags inspite of setting the right transponder position value manually, please choose a different material. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 115 (Distance between the RFID-Inlay and the end of the previous label) 2. Insert your label material into the printer. Further details on inserting consumables can be found in chapter 5 Handling of Consumables. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 116 In addition this new value can be saved as EN TER setup value (using the ENTER key). After this decision turn the printer ON LINE EN TER again: Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 117 [Tag position ] panel function to set the transponder position value (offset). (Second approximate value for the Tag Position.) 8. Repeat the steps 4 up to 7 until the RFID Inlay (Tag) is positioned central above the printer antenna. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 118 Autom. Read ID = on is the factory default setting. The panel function described in section 8.2.6 allows to change this setting. The panel function [RFID Test ] can be used as well to read the label. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 119: Adjusting The Number Of Rfid Access (Timeout)

    After this decision turn the printer ON LINE again: Press the ENTER key longer than 2 EN TER seconds. Note: Maximum throughput results when labels are programmed on the first try. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 120: Adjusting The Transmission Speed (Bit Rate)

    [T=40, R= 40 kBit ] ENTER The transmission speed was reduced (saved as setup value). [Saved ! ] Turn the printer ON LINE again: ENTER Press the ENTER key longer than 2 seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 121: Reading The Label Identification Number Automatically

    In addition this new value can be saved as EN TER setup value (using the ENTER key). After this decision turn the printer ON LINE again: Press the ENTER key longer than 2 EN TER seconds. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 122: Data Interface Status Out

    In the second mode you have to "ask" the printer via IDOL commands about the current status. For further information about the configuration of the Data Interface Status Out please take notice of the appendix of this manual. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 123: Idol Commands For Rfid

    8.4.1. Overview Function Group RFID Function: Thanks to a number of parameters the rf command can be used for many different RFID tasks. Syntax: <ESC><ESC>rf <k xx nn> ... <k 99 "cc"> _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 124: Data Format

    01 = user When reading: nn = block number n = 1-digit Data format 0 = binary = default (ASCII presented as they are) 1 = Hex-ASCII *EPC: Electronic Product Code _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 125 Please refer to chapter 7 for more information (for example: 7.30 Selecting the Tear Off Mode (Option: Cutting Mode) and 7.31 Selecting the Print Mode). Refer to section 8.4.2 and following, too. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 126: Reading The Label Id Number (Prior To The Print Process)

    The command described above may reduce the print speed. If a higher output of print material is needed, a different command should be preferred (see section 8.4.4). Please read the following sections for details! _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 127: Writing Data Into A Data Block Of The Rfid Label

    The IDOL command used in the following example enables you to write data into the data blocks of the RFID label. Example: The text ”MICROPLEX“ is to be written into the user block of the RFID label. Send the following command to the printer via the print data channel: &%&%rf 11 01 99*MICROPLEX*...

  • Page 128: Generating A Page Id Number, Receiving The Rfid Data After Printing

    Set the printer to the automatical status message mode (EEPROM Word 23 Bit 13 = 0). Then status messages (OFF LINE, Paper Jam ...) will be sent to the host automatically. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 129 1000 message via the status channel. This message contains an “X” instead of the label ID: 1000<S><Page ID><S><X><S><T> Please read the following section for details! _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 130: Syntax Of Rfid Data (Status Messages)

    Only ASCII characters are to be used. It is possible to configure the separator and terminator (see Appendix). For more details about the status messages, see the appendix of this manual. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 131 See previous sections: parameter of the status request command. Label ID = 058000098B7C1F6B : Identification number of the label (in this example the string includes 16 characters) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 132: Rfid Errors

    Hint: The panel function described in section 8.2.4 is used to set the maximum number of unsuccessful RFID accesses (read, program, etc.) being allowed until the printer treats this label as defective. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 133 Position, too. - check the communication protocol setting See section 8.2.2 Selecting the Communication Protocol. - increase the number of retries See section 8.2.4 Adjusting the Number of RFID Access. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 134 RFID tag was set to the right position - see section 8.2.3 Adjusting the Transponder Position (Tag Position), too. * Note: The RFID printer pauses while programming the RFID tag _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 135 Position, too. - choose different label material, if the distance between the tags of your material in use is too small If the remedies above are not successful, please call a MICROPLEX authorized service engineer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...
  • Page 136 - the RFID write/read module is defective [RFID Error An error occurred during update of the RFID [Update TimeOut ] reader software (firmware). If the remedies above are not successful, please call a MICROPLEX authorized service engineer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 137: Operator Maintenance

    In order to run the printer on its highest quality level, it is necessary to perform regularly simple cleaning operations, and to occasionally replace certain components. These operations can be performed by a MICROPLEX trained operator. A not trained person is not allowed to perform these operations.

  • Page 138: Printer Cabinet Cleaning

    If necessary the cloth can be moistured with water or a neutral detergent. Inside the printer dust or paper dust can be removed best with a soft (non-metallic) brush. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 139: Printhead Cleaning

    • Move the cloth or pen along the print area of the printhead (see figure 9.1.2.a). This working step requires light pressure and has to be repeated several times. Printhead Fig. 9.1.2.a Cleaning the printhead _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 140 This working step has to be repeated several times. Fig. 9.1.2.c Moving the cleaning strip in both directions • Release the printhead pressure lever, remove the cleaning strip from the printer and discard the cleaning strip. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 141 To help keep the printhead clean and to avoid premature wear out of the printhead, the hood of the printer should always be closed. Moreover it is not allowed to use dusty or dirty print media. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 142: Transport Roller Cleaning

    Make sure the concerning transport rollers have been cleaned on their whole extent so that there is no reason for irregular media transport after that. Allow the transport rollers to dry for at least 3 minutes. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 143: Printhead Exchange

    Only use consumables being specially developed for this device. Using unsuitable consumables or excessive contact pressure can result in premature wearing of the printhead. Only a MICROPLEX - trained operator is allowed to exchange the printhead. The following operations have to be done to carry out the...

  • Page 144: Printhead Removal And Installation

    - The printhead must not be touched on the print bar or on the plug-in contacts. 6. Grasp the printhead assembly with both hands (as shown in the next picture). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 145 Later on the new printhead has to be assembled just in the same way. 7. Now gently pull the old printhead assembly completely out of the device. Fig. 9.2.1.c Removing the printhead _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 146 Fig. 9.2.1.d Insert the printhead into the side guides 10. Pay attention to the connectors of the printhead: line up the plug. Fig. 9.2.1.e Line up the printhead plug _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 147 Operator Maintenance _______________________________________________________________________________________________ 11. Gently press the printhead into its carriage until it clicks into place. Fig. 9.2.1.f Inserting the printhead into its carriage _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 148: Adjusting The Right Pressure Value

    The abrasion of the concerning components (for example the printhead surface) will be accelerated considerably due to the increase of the pressure value. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 149: Troubleshooting

    - Make sure all covers of the device are completely closed afterwards. Any others but the troubles described on the following pages are only to be repaired by a MICROPLEX authorized operator or a service engineer. When reporting a problem to your service engineer, please give him the exact error message.

  • Page 150: Printer Error Messages

    - insert a ribbon - make sure the ribbon has been loaded correctly (compare section 5.3) - Correct the print process setting, if you don’t want to use a ribbon. (compare section 7.1) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 151 - a new printhead has to be installed Note: Information about error messages referring to the RFID — functions of the printer can be found in section 8.6. If the remedies above are not successful, please call a MICROPLEX authorized service engineer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 152: Reduced Print Quality

    2.3 and 12) Printout too strong - check the print process selecting and correct it, if necessary (see section 7.1) - reduce the contrast (see section 7.23) _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 153 - the printhead has to be exchanged if, for example after a big printout performance the printout isn’t correct any more (printhead exchange; see section 9.2) If the remedies above are not successful, please call a MICROPLEX authorized service engineer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 154: Incorrect Media Transport

    - release the printhead pressure lever to remove the paper (compare chapter 5) - check if the jammed consumables have been removed completely. If the remedies above are not successful, please call a MICROPLEX authorized service engineer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 155: Rewinder, Dispenser And Cutter Error Messages

    An error occured during rewinder operation - check if the label/carrier, which should be wound up, is torn - check if the consumables have been loaded correctly (compare section 5.2) - reload the material _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 156 An error occured during cutter operation. - check for a paper jam. Remove the jammed paper. - reload the consumables (paper) If the remedies above are not successful, please call a MICROPLEX authorized service engineer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID...

  • Page 157: Print Repetition After An Error

    EEPROM - configuration) if the user wants to resume the print job at a position he chooses himself. In addition to this see panel function Clearing the Input Buffer (section 7.10). _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 158 Troubleshooting _______________________________________________________________________________________________ _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 159: Measures For Transport And Shipping (Repacking)

    • Lock all moveable parts of the printer (use all original transport safety devices, adhesive fasteners and so on). Repack all items in their original packing material and ship them in the original boxes. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 160 Measures for Transport and Shipping _______________________________________________________________________________________________ _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 161: Specifications

    30 to 85 % (without condensation) Mains connection: 230 V AC, 50 Hz, (Europe, United Kingdom e.g.) 120 V AC, 60 Hz, (North America) Power input: max. appr. 0.30 kVA max. appr. 0.33 kVA _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 162 Specifications _______________________________________________________________________________________________ Reader Specifications: The MICROPLEX printers LOGIJET T4 RFID and LOGIJET T6 RFID are both equipped with an compact reader to allow UHF tag programming and reading. The technical specifications of this compact reader module are listed below. The reader is fully compliant to the European telecommunication regulation ETSI EN 300 220 (869.525 MHz).
  • Page 163 There isn’t any generally valid rule to calculate the costs per page. Therefore values given by different manufacturers are very often not comparable. The values given by MICROPLEX are based on the utilization time of the so-called consumables of the printer. There isn’t any generally valid rule for this calculation, either. Therefore MICROPLEX has fixed the definition of consumables as follows: 1.
  • Page 164 CAQ (Customer Acceptable Quality) is a purely subjective lower limit which a respective customer is willing to accept the print quality. An exchange of parts is only then necessary even if the MNPSQ is already exceeded. quality Utilization time exchange exchange MNPSQ MNPCAQ pages _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 165: Appendix

    Bit 13 = 0 : Mode 1, messages will be sent to the host automatically and after a request. Bit 13 = 1 : Mode 2, messages will be sent after a request only. Please use the IDOL command <ESC><ESC>ee for setting the bit 13. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 166 To set the word no. 23 to the new value <EFFF>, send the command <ESC><ESC>ee 023 EFFF to the printer. After power off and on the new value will be valid. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 167: Changing The Separator And Terminator Characters

    <ESC><ESC>ee 030 237C After power off and on the new values will be valid. Note: The character for separator and terminator has to be different. Otherwise the default characters will remain valid! _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 168: Survey Of Print Job Status Messages

    ( <ESC><ESC>: 0011). 1020 : Answer to a RFID support command. This message will appear after a command like "Read Label ID Number" was sent to the printer. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 169: Survey Of Printer Status Messages

    Refilling of the empty cassette generates no special message. The status of those cassettes not in use will not be checked. _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 170 Appendix _______________________________________________________________________________________________ _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

  • Page 171: Index

    66 CUT 49 fonts 64, 79 cutter 155 FORM FEED 68 cutter activation 98 frequency 162 cutting menu 101 function keys 47 cutting mode 100, 101 fundamentals 9 _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 172 OFFLINE key 47, 49, 53 ON LINE key 55 label 59 operation sequences 21 label ID 130 operator maintenance 137 label length 61 labels 8 language 75 LCD display 48 light sensor type 90 _______________________________________________________________________________________________ MICROPLEX Operator‘s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 173 18 roll-fed media 25 printer installation 17 printer status 165 printer status messages 169 printhead cleaning 139 printhead exchange 143 printhead pressure 42 printhead removal 144 protocol, communication 112 _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 174 63 text orientation 82 text string 130 thermal direct printing 9, 23, 57 thermal transfer printing 9, 33, 57, 150 timeout 119 transmission speed 120 transparent code 76 _______________________________________________________________________________________________ MICROPLEX Operator‘s Manual LOGIJET T4 /T6 /RFID Edition 1.3...
  • Page 175 Index _______________________________________________________________________________________________ _______________________________________________________________________________________________ MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3...

This manual is also suitable for:

Logijet t6Logijet t6 rfidLogijet t4 rfid

Table of Contents
