- Page 1 HW-J6000R HW-J6001R User manual Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register ©2016 Samsung Electronics Co.,Ltd. All rights reserved...
-
Page 2: Getting Started
GETTING STARTED GETTING STARTED SAFETY INFORMATION SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that high voltage is CAUTION present inside. - Page 3 GETTING STARTED PRECAUTIONS 68.6 mm 99.1mm 99.1mm 99.1mm Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (7~10 cm).
-
Page 4: Table Of Contents
GETTING STARTED CONTENTS GETTING STARTED 24 FUNCTIONS Safety Information Input Mode What’s Included Bluetooth Software Update DESCRIPTIONS 29 TROUBLESHOOTING Top / Front Panel Rear / Bottom Panel Troubleshooting Remote Control 30 APPENDIX 11 INSTALLATION Specifications Installing the Soundbar Installing the Wall Mount ●... -
Page 5: What's Included
GETTING STARTED WHAT’S INCLUDED BEFORE READING THE USER’S MANUAL Note the following terms before reading the user manual. + Icons used in this manual Icon Term Definition Caution Indicates a situation where a function does not operate or settings may be cancelled. Note Indicates tips or instructions on the page that help you operate a function. -
Page 6: Descriptions
DESCRIPTIONS DESCRIPTIONS TOP / FRONT PANEL VOL. - / + (Power) Button Controls the volume level. The numeric value of the volume level Turns the power on and off. appears in the front panel display. (Source) Button Display Selects the D.IN, AUX, HDMI, BT, TV, or USB Displays the current mode. -
Page 7: Rear / Bottom Panel
DESCRIPTIONS REAR / BOTTOM PANEL AUX IN HDMI IN Connect to the Analogue output of an Inputs digital video and audio external device. signals simultaneously using an HDMI cable. Use when connecting a supported external device. OPTICAL IN (D.IN) HDMI OUT (TV-ARC) Connect to the digital Outputs digital video and (optical) output of an... -
Page 8: Remote Control
OFF - ANYNET+, ON - ANYNET+ The Anynet+ function lets you control the Soundbar with the remote from an Anynet+ compatible Samsung TV. The Soundbar must be connected to the TV via an HDMI cable. Press and hold the button for about 5 seconds to turn the Auto Power Link function on or off. - Page 9 DESCRIPTIONS Power Turns the Soundbar on and off. Volume Adjusts the volume level of the unit. Play / Pause Press the p button to pause a file temporarily. Press the p button again to play the selected file. Skip Back If there is more than one file on the device you are playing, and you press the [ button, the previous file is selected.
- Page 10 DESCRIPTIONS + Controlling the Soundbar using Your TV Remote Control 1. Press and hold the SOUND button for more than 5 seconds while the Soundbar is turned on. 2. "ON - TV REMOTE" appears on the Soundbar's display. 3. In the TV's menu, set the TV speaker to external speaker. ●...
-
Page 11: Installation
INSTALLATION INSTALLATION INSTALLING THE SOUNDBAR INSTALLING THE WALL MOUNT + Installation Precautions ● Install on a vertical wall only. ● For the installation, avoid a location with high temperature or humidity, or a wall that cannot sustain the weight of the set. - Page 12 INSTALLATION Center Line Center Line 2. Mark the location where the screws will go through on the wall, and then remove the installation guide. Next, drill holes for the screws using an appropriately sized drill bit. 3. Fasten the 2 Bracket-Wall pieces firmly to the wall at the marked locations using the appropriate screws. 4.
- Page 13 INSTALLATION 5. Insert a Holder-Fix Mount into each hole on the product’s bottom side. Tighten each Holder-Fix Mount to fix the Soundbar to the 2 Bracket-Wall pieces. ● Do not hang onto the installed unit and avoid striking or dropping the unit. ●...
-
Page 14: Placing The Soundbar On A Tv Stand
INSTALLATION PLACING THE SOUNDBAR ON A TV STAND Place the Soundbar on a TV stand. 1. Align the Soundbar’s centre with the centre of the base of the TV, and then carefully push it onto the stand as far as it will go, as shown in the illustration. Be careful not to unbalance the TV. INSTALLING THE SOUNDBAR AS A FREE-STANDING UNIT 1. -
Page 15: Connections
CONNECTIONS CONNECTIONS ● Do not connect the power cord of this product or your TV to a wall outlet until all connections between components are complete. ● Before moving or installing this product, be sure to turn off the power and disconnect the power cord. CONNECTING THE SUBWOOFER CONNECTING TO THE SUBWOOFER AUTOMATICALLY The Subwoofer's linking ID is preset at the factory and the main unit and subwoofer should link (connect wirelessly) -
Page 16: Connecting The Swa-8000S (Sold Separately)
CONNECTING THE SWA-8000S (SOLD SEPARATELY) ● Expand to true wireless surround sound by connecting the Samsung Wireless Rear Speaker Kit (SWA-8000S) to your Soundbar. (Sold separately) ● Before connecting to the Wireless Receiver Module, connect your subwoofer first. -
Page 17: Sold Separately
CONNECTIONS If the Wireless Receiver Module is not linked to your Soundbar (displaying the LED indicator in Red), connect them as follows. 1. Turn off your Soundbar. 2. Press the (Mute) button on your remote control for 5~6 seconds until the ID SET message appears on your Soundbar display. -
Page 18: Connecting To A Tv
● Important: Before you begin, put the battery into the remote. See page 10 for instructions. TV SOUNDCONNECT You can enjoy TV sound through your Soundbar when it is connected to a Samsung TV that supports the TV SoundConnect function. -
Page 19: Connecting To A Tv Using An Hdmi (Digital) Cable
• ON - BLUETOOTH POWER : The Soundbar turns on and off when you turn the TV on or off. • OFF - BLUETOOTH POWER : The Soundbar only turns off when you turn the TV off. ● This function is supported by some Samsung TVs released from 2013 on. CONNECTING TO A TV USING AN HDMI (DIGITAL) CABLE... -
Page 20: Connecting To A Tv Using A Digital Optical Cable
CONNECTIONS CONNECTING TO A TV USING A DIGITAL OPTICAL CABLE Optical Cable (not supplied) OPTICAL OUT OPTICAL IN DC 14V HDMI IN AUX IN 5V 0.5A HDMI OUT OPTICAL IN (TV-ARC) 1. Connect the OPTICAL IN (Audio) jack on the Soundbar to the OPTICAL OUT jack of the TV with a digital optical cable. -
Page 21: Connecting To External Devices
CONNECTIONS CONNECTING TO EXTERNAL DEVICES HDMI CABLE HDMI is the standard digital interface for connecting to TVs, projectors, DVD players, Blu-ray players, set top boxes, and more. HDMI prevents any degradation to the signal due to conversion to analogue and maintains the video and audio quality of the original digital source. -
Page 22: Usb
CONNECTIONS + AUX Cable 1. Connect AUX IN (Audio) on the main unit to the AUDIO OUT jack of the Source Device using an audio cable. 2. Press the button on the top panel of the Soundbar or the SOURCE button on the remote control to select the AUX mode. - Page 23 CONNECTIONS ● Connect USB devices directly to the USB port of the product. Otherwise, you may encounter a USB compatibility problem. ● Do not connect multiple storage devices to the product via a multi-card reader. It may not operate properly. ●...
-
Page 24: Functions
FUNCTIONS FUNCTIONS INPUT MODE button on the main unit’s top panel or the SOURCE button on the remote control to select the mode Press the you want. Input mode Display Optical Digital input D.IN ARC (HDMI OUT) input AUX input HDMI HDMI input BLUETOOTH mode... -
Page 25: Bluetooth
• The device name can only be displayed in English. An underline " _ " will be displayed if the name is not in English. • If the Bluetooth device has failed to pair with the Soundbar, delete the previous "[Samsung] HW-Jxxxx J-Series" found by the Bluetooth device and have it search for the Soundbar again. - Page 26 ● You cannot connect the Soundbar to a Bluetooth device that supports only the HF (Hands Free) function. ● Once you have paired the Soundbar to a Bluetooth device, selecting "[Samsung] HW-Jxxxx J-Series" from the device's scanned devices list will automatically change the Soundbar to BT mode.
-
Page 27: Using The Samsung Audio Remote App
Market search : Samsung Audio Remote + Launching the Samsung Audio Remote App To launch and use the Samsung Audio Remote app, touch the Audio Remote icon on your smart device, and then follow the directions on the screen. ● The Samsung Audio Remote app is only compatible with Android mobile phones and mobile devices... -
Page 28: Software Update
Note that if there are multiple update files, you must load them onto the USB device singly and use them to update the firmware one file at a time. Please visit samsung.com or contact the Samsung call centre to receive more information about downloading update files. -
Page 29: Troubleshooting
The TV SoundConnect (TV pairing) failed. • Does your TV support TV SoundConnect? ¼ TV SoundConnect is supported by some Samsung TVs released from 2012 on. Check your TV to see if it supports TV SoundConnect. ¼ Update your TV with the latest firmware. -
Page 30: Appendix
Design, specifications and App screen are subject to change without prior notice. Nominal specification Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. Weight and dimensions are approximate. For more information about the power supply and power consumption, refer to the label attached to the product. - Page 31 This equipment may only be used indoors. Wireless Models (excluding the frequency of 5.15GHz-5.35GHz) Hereby, Samsung Electronics, declares that this equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The original Declaration of Conformity may be found at http://www.samsung.com, go to Support >...
- Page 32 EIRE EIRE s Samsung product is warranted for the period of twelve (12) months from the origi- Samsung product is warranted for the period of twelve (12) months from the origi- This Samsung product is warranted for the period of twelve (12) months from the origi- beyond the control of Samsung.
- Page 33 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care Centre. Country Contact Centre Web Site Country Contact Centre Web Site ` Europe 0800-SAMSUNG (0800-7267864) AUSTRIA [Only for Premium HA] 0800-366661 www.samsung.com/at/support...
