- Page 1 User's Guide http://www.omega.com e-mail: info@omega.com CIO-RELAY08 CIO-RELAY16 CIO-RELAY24 CIO-RELAY32...
-
Page 2: Table Of Contents
....... 6.1 CIO-RELAY08, 16, 24 and 32 (standard versions) .. -
Page 3: Introduction
The CIO-RELAY16 is a 16 channel relay interface board for ISA bus computers. The board provides 16 Form C (SPDT) relays. The CIO-RELAY08 board is designed for applications that require fewer relays and is identical to the RELAY16 board except that only 8 relays are installed. -
Page 4: Quick Start
6.2 MERCURY WETTED (/M) VERSIONS POWER CONSUMPTION CIO-RELAY 510 mA + (22 mA per activated relay max) GENERAL SPECIFICATIONS Number 8 / 16 Contact arrangement Form A (SPST) Contact rating 50 Watts @ 1Amp or 500VDC resistive Contact type Mercury wetted Contact resistance 50 milliohms max. -
Page 5: Run Instacaltm
I/O pins are working correctly. To check this select External Test and follow the instruction provided. This will require the use of an ohmmeter. 6 SPECIFICATIONS 6.1 CIO-RELAY08, 16, 24 and 32 (standard versions) POWER CONSUMPTION +5V supply 510 mA typical plus 22 mA per active (on) -
Page 6: Hardware Installation
Choose a new base address from those available and set the switch using the guide below. Please note that the switch shown below is for the CIO-RELAY08 and CIO- RELAY16 boards. Since the CIO-RELAY32 and CIO-RELAY24 board require 4 I/O address, their base address switch does not provide switch 2. -
Page 7: Wait State
FUNCTION RANGE RANGE 000-00F 8237 DMA #1 2C0-2CF 020-021 8259 PIC #1 2D0-2DF 040-043 8253 TIMER 2E0-2E7 060-063 8255 PPI (XT) 2E8-2EF 060-064 8742 CONTROLLER (AT) 2F8-2FF 070-071 CMOS RAM & NMI MASK (AT) 300-30F 080-08F DMA PAGE REGISTERS 310-31F 0A0-0A1 8259 PIC #2 (AT) 320-32F... -
Page 8: Programming
5 CONNECTING TO RELAYS 5.1 I/O CONNECTOR DIAGRAMS The CIO-RELAY08 and CIO-RELAY16 boards use a single 50 pin connector for sig- nal interfacing. The CIO-RELAY24 and CIO-RELAY32 use two 50 pin connectors. The pin-outs of the connector are shown here. -
Page 9: Programming Notes
For example, to assemble the control byte that will turn on relays 0. 1. 3. 5 and 7 we can see from the chart below we need to write decimal 171 (hex AB): RELAY ON = 1 WEIGHT DECIMAL 4.2 PROGRAMMING NOTES WRITE = CONTROL: Write a byte to the register to control the relays.
