VA Series Vapor Actuated Dial Thermometer
The carrier will not honor damage claims unless all shipping
material is saved for inspection. After examining and
removing contents, save packing material and carton in the
event reshipment is necessary.

Case and Mounting Dimensions

Front Flange
(Panel Mount)

Installing the Indicating Head

Surface Mount (Rear Flange)
1. Make a circular cutout in the center of the hole mounting pattern for
the capillary tube to fit through.
2. Drill the three (3) mounting holes.
3. Using the screw holes that you drilled, screw the back of the head to
your wall or panel.
2
Figure 2. Case and Mounting Dimensions
N O T E
U-Clamp
(Panel Mount)
Rear Flange
(Surface Mount)
