User’s Guide http://www.omega.com email: info@omega.com MODEL PX2670 Low Pressure Tranducers and Transmitters...
Page 2
OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA Engineering, Inc. accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
Page 3
0 to 10 VDC output and the current model transmitter with 4 to 20 mA output. Environmental Conditions The PX2670 Series is designed to be operated and stored in the following environmental conditions: Temperature - The PX2670 is designed to operate and be stored with the...
Page 4
- please observe polarity. The PX2670 can operate over a voltage range of 9 to 30 VDC. It has been factory calibrated at 24 VDC into a 250 ohm load. The minimum and maximum power supply must be capable of delivering these voltages to the PX2670.
Page 5
Span or full scale output adjustments should only be performed by using an accurate pressure standard (electronic manometer, digital pressure gage, etc.) comparable accuracy as the PX2670 Series. With full scale pressure applied to the high pressure port, adjust span for full scale electrical output of 10.05 VDC.
Page 6
OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months from date of purchase. OMEGA Warranty adds an additional one (1) month grace period to the normal one (1) year product warranty to cover handling and shipping time. This ensures that OMEGA’s customers receive maxi- mum coverage on each product.
Page 7
Where Do I Find Everything I Need for Process Measurement and Control? TEMPERATURE Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies Wire: Thermocouple, RTD & Thermistor Calibrators & Ice Point References Recorders, Controllers & Process Monitors Infrared Pyrometers PRESSURE, STRAIN AND FORCE Transducers &...
