Garmin Approach S5 Owner's Manual

Approach S5 Owner's Manual
®
See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
Keys
Select to turn on the backlight.
Hold to turn the device on and off.
Select to measure a shot
Hold to reset the measurement.
Select to open the menu for the current screen.
Select to enter your score for the hole
page 2).
Hold to view scores for all holes.
Select to use CourseView
Select to return to the previous screen.
Turning on the Device
The device comes partially charged. You may need to charge
the device before playing golf
NOTE: The time of day and date are set automatically when you
go outdoors and the device locates satellites.
1 Hold , and follow the on-screen instructions.
2
Select Start Round.
3 Wait while the device locates satellites.
Unlocking the Device
After a period of inactivity, the device goes into watch mode and
the screen is locked. The device displays the time and date, but
does not use GPS.
Select any key except
Status Icons
Battery level
GPS status
Alarm
Bluetooth technology status
®
Charging the Device
This device contains a lithium-ion battery. See the Important
Safety and Product Information guide in the product box for
product warnings and other important information.
April 2016
WARNING
(Measuring a Shot, page 3).
(Keeping Score,
(Using CourseView, page
(Charging the Device, page
to unlock the device.
WARNING
To prevent corrosion, thoroughly clean and dry the contacts and
the surrounding area before charging or connecting to a
computer. Refer to the cleaning instructions in the appendix.
1
Plug the USB cable into a USB port on your computer.
2
Align the charger posts with the contacts on the back of the
device, and press the charger
3
Charge the device completely.
Playing Golf
Before you can play golf, the device must locate satellite signals.
This may take 30 to 60 seconds.
1 Select > Start Round.
2
Select a course from the list of nearby courses.
3 Tap the screen to scroll through the data screens for each
hole.
TIP: You can select
2).
1).
• displays the hole information
page 1).
• displays the layup and dogleg information
Layup and Dogleg Distances and Saved Locations,
page 2).
• displays the time of day.
The device automatically transitions when you move to the
next hole.
Hole Information
By default, the device calculates the distance to the front,
middle, and back of the green. If you know the location of the
pin, you can set it more precisely using the green view
the Green, page
Printed in Taiwan
NOTICE
until it clicks.
to return to the previous screen.
(Hole Information,
2).
(Viewing
(Viewing
190-01865-00_0B
