Boston i-DS3 plus Service Manual page 2

Boston Acoustics Service Parts
Model: iDS3 Plus
Item Component Part Number
5 110-002369
8 110-002185
25 120-003118
28 120-003119
28 120-003132
1 120-003120
1 120-003186
120-003121
120-003122
4 120-003123
2 131-000760
2 131-000761
12 110-002186
10 120-003124
3 120-003125
120-003126
132-000165
3 120-003130
120-003131
132-000166
120-003127
120-003134
126-000098
141-002611
141-002610
120-003284
120-003285
142-003544
PCB ASSEMBLY BREAKDOWN FOR IDS3 BAR
33 120-003264
34 120-003265
120-003266
PCB ASSEMBLY BREAKDOWN FOR IDS3 SUBWOOFER
126-000135
126-000136
120-003267
120-003268
120-003269
120-003270
Updated 22-JAN-2010
Component Description
WOOFER 3" FULL RANGE
TWEETER
X-O ASSY HIDS3
CONTROL BUTTON ASSY HIDS3B
CONTROL BUTTON ASSY HIDS3W
GRILLE HIDS3B
GRILLE HIDS3W
MAIN AMP ELECTRONICS HIDS3
IR ELECTRONICS HIDS3
RUBBER FOOT HIDS3-BAR
GRILLE GROMMETS HIDS3B
GRILLE GROMMETS HIDS3W
SUBWOOFER WOOFER
RUBBER FOOT HIDS3-SUB
AMP ASSY HIDS3-SUB 120V
POWER CORD HIDS3-SUB 120V
FUSE 1.0A 250V 20MM VDE
AMP ASSY HIDS3-SUB 230V
POWER CORD HIDS3-SUB 230V
FUSE 0.5A 250V 20MM TIME LAG
REMOTE CONTROL HIDS3B
REMOTE CONTROL HIDS3W
BAR POWER SUPPLY 100/120/230
RSC-1-EA HIDS3B
RSC-1-EA HIDS3W
IPOD ADAPTER KIT BLK
IPOD ADAPTER KIT WHT
OWNERS MANUAL HIDS3
051-IDS3IPOD-EP
PCB ASS'Y FOR IDS3 SAT KEY-IR
PCB ASS'Y FOR IDS3 SAT DAMP- (includes Damp, Main, MCU, Tx)
(note: module is mounted inside box item 11 from back of unit)
Transformer 120V
Transformer 230V
PCB ASS'Y FOR iDS3 SUB
PCB ASS'Y FOR Tvee 2.1 SUB RX
PCB ASS'Y FOR Tvee 2.1 SUB PRE-AMP
PCB ASS'Y FOR IDS3 SUB-AMP
(for 120V sub only)
(for 230V sub only)
