LIND PA1540 Series Manual

Automobile power adapter used for: panasonic toughbook cf-01,-17, 25,-27,-28,-34,-35,-45,-47,-48,-61 -62,-63-71,-72

Download this manual

The LIND Laptop Power Adapter is specifically designed to

operate your laptop computer and to charge the internal battery.

The adapter supplies precise current and voltage levels required by

the laptop. The output of the adapter closely emulates the laptop's

own AC adapter output.

The LIND Power Adapter provides a safe power source by

protecting your computer from spikes and power surges which may

occur in a DC voltage electrical system.

Adapter #PA1540-xxx is used for:

CF-01,-17, 25,-27,-28,-34,-35,-45,-47,-48,-61 -62,-63-71,-72

Do not use the PC while driving your vehicle.

Close the LCD screen while driving.

Do not allow vibration or shock while PC is in operation.

This adapter will not charge the PC when the input voltage

drops below 11VDC.

Do not use this adapter with lighter plug splitter or extender

cables. These devices can cause the adapter cigarette lighter plug to

become very hot.

For assistance and recommendations for connecting multiple devices

to the 12VDC source, call Lind Technical Assistance at:

800-659-5956 or 952-927-6303

LIND

Automobile

Power Adapter

Panasonic Toughbook™

Special Use Warning

™

Table of Contents

Need help?

Do you have a question about the PA1540 Series and is the answer not in the manual?

Page 1 The output of the adapter closely emulates the laptop's own AC adapter output. The LIND Power Adapter provides a safe power source by protecting your computer from spikes and power surges which may occur in a DC voltage electrical system.
Page 2: Technical Information
INPUT POWER INDICATOR DC TO DC AUTOMOBILE ADAPTER POWER OUTPUT POWER INDICATOR FUSE IN PLUG (Some models have the output cable permantly attached to the adapter body) LAPTOP COMPUTER Adapter Connections PLUG INTO THE LAPTOP POWER JACK Technical Information Power Input - 12 to 16 VDC Power Output: - Noted on label...
Page 3: Connection Instructions
Connection Instructions Hard Wired DC Input Cable * Part Numbers: #CBLPW-00220A - 27", 18 AWG Wire #CBLPW-00220B - 36", 18 AWG Wire #CBLPW-00220C - 72", 18 AWG Wire Connect white lead wire (positive) to the positive power connec- tion point of the vehicle. Connect the black lead wire(negative) to a location that will provide suitable connection to the vehicle's negative ground.
Page 4 Replacement 36" automobile cable: Order #CBLAU-00218D. Replacement output cable: Order #CBLPW-10019A.
Page 5: Limited Warranty
Fax: (952) 927-7740 E-mail: lrlind@lindelectronics.com Internet: www.lindelectronics.com Lind, Lind Electronics, and the Lind Logo are Trademarks of Lind Electronics, Inc. All other Registered Trademarks and Trademark names are the property of their respective owners. © 2000 Lind Electronics, Inc. 8/15/00...
