Pairing Process - Cognisys Stackshot 3X Owner's Manual

To power off the Remote, press and hold the center "B" (power) button for one second until the
blue LED goes out.

3. Pairing Process

In order to use the Remote with your StackShot 3X, you first must go through a pairing process.
You will only need to do this once (unless you update your Remote software). Start with your
Remote turned off.
Note: The Remote requires that your StackShot 3X be running software version 1.0.01 or later.
You can see the current version of your controller when you first turn it on. If you need to
update your StackShot 3X version, please visit the following link:
StackShot 3X Technical Specs
The following instructions may appear slightly different for versions later than the 1.0.01
software, but the process is the same.
On your StackShot 3X controller, press the "Settings" button:
Use the down arrow and navigate to the "Wireless Config" option:
6
