- Page 1 Standard Operating Manual AX030-0090 Turntable ADDRESS 2230 Brush College Road Decatur, IL 62526 Phone: 217-423-6001 www.AxialIndustrialTurntables.com Fax: 217-422-1049 E-mail: sales@alignprod.com...
-
Page 3: Table Of Contents
Table of Contents Important Precautions ························································································ 4 Description of Equipment ················································································· 4 III. Installation and Start-Up ················································································· 5 Specifications ··································································································· 6 Air Supply ··········································································································· 6 Operation ········································································································ 6 VII. Maintenance ································································································· 7 VIII. Troubleshooting ·························································································· 8 Recommended Spare Parts ············································································· 8 Warranty ···········································································································... -
Page 4: Important Precautions
Never restore power or air pressure to the control system without first clearing the turntable of personnel, tools or other obstructions. Never alter the equipment in any way unless authorized by a qualified Axial/Align Production Systems employee. II. Description of Equipment This equipment consists of a 7.5-ft. -
Page 5: Installation And Start-Up
Inspect the equipment for possible damage in shipment or unpacking. Please contact Axial if there is any damage to the unit that may hinder the operation. In order to move the system around, you must attach a lifting device to the four lifting lugs located on the base plate and welded inside the tubes (see below). -
Page 6: Specifications
It is best to center the load onto the turntable for best results. NOTE: DO NOT let anything overhang the turntable as this may cause damage to the unit if it were to rotate. Digital Indicator Drive Forward/Reverse Air Spring Actuator Air Connection Electrical Connection AX030-0090-MANUAL | 6... -
Page 7: Maintenance
(5/8-11 hex-head bolts). Then the table bolts to the top of the bearing (5/8-11 flat-head bolts), and finally the access panel is bolted to the table top (5/8-11 flat-head bolts). Turntable access panel Turntable Bearing Shim Plate Scale AX030-0090-MANUAL | 7... -
Page 8: Troubleshooting
EFUELT0015 Scale digital indicator ENCBCS0001 Drive wheel WHL0023C Air spring pilot valve VMC-56C53RA To reorder a part, please call 1-800-888-0018 and ask for the Parts Department. If possible, please have your Axial serial number handy for reference. AX030-0090-MANUAL | 8... -
Page 9: Limited Warranty
APS is not responsible for, any labor or other expense for inspections, removal or reinstallation of components or products. Align Production Systems Brand Lineup Airfloat Axial Industrial Turntables Silvestrini NA Tecbo Tooling Safebilt Phone: 217-423-6001 Fax: 217-422-1049 E-mail: sales@alignprod.com...
