Nokia E6-00 Service Schematics
Hide thumbs
Also See for E6-00:
- User manual (140 pages) ,
- Manual del usuario (137 pages) ,
- Service schematics (12 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
User Manual
Service
Schematics
IMPORTANT
This document is intended for use by authorized Nokia servi-
ce centers only. Please use the document together with other
documents such as the Service Manual and Service Bulletins.
Version information
While every effort has been made to ensure that the docu-
ment is accurate, some errors may exist. Please always
check for the latest published version for this document.
If you find any errors in the document please
send email to:
service.manuals@nokia.com
1.0
First approved version.
Confidential Copyright © 2011 Nokia. Only for training and service purposes
Page 1 (12) | Front page | Nokia E6-00 RM-609 | Board: 3DH_04a | v1.0 | 11.03.2011
Nokia E6-00
Contents
Front page
Imaging processor, Display conn, Main camera, Secondary camera
RAPUYAMA, Touch panel conn, UI conn, Sensors
RAPUYAMA, Combo memory
PEARL, Battery conn, Power key, Charging, USB IF
PEARL, SIM conn, MMC conn, AV IF, Audio clock, Microphones, Vibra
BTH FM, WLAN, GPS
RF part
Keyboard flex
Component finder Main board top
Component finder Main board bottom
Component finder Keyboard flex
RM-609
1
2
3
4
5
6
7
8
9
10
11
12
