- Page 1 Rev 1: 21 August 2011 CORPION LYER Multi-rotor Aircraft build Manual Guilin Feiyu Electronic Technology Co., Ltd Rm. B305, Innovation Building, Information Industry Park, Chaoyang Road, Qixing District, GuiLin, CN www.feiyu-tech.com Email: feiyutech@yahoo.cn...
- Page 2 Guilin Feiyu Electronics Co., Ltd. Aircraft Parameters 1. Dimensions 450mm 681mm Aircraft Diameter Maximum Propeller Diameter 2. Empty Weight: 630g (receiver and battery not included) 3. Payload capacity: 800g (includes battery, receiver, etc.) 4. Maximum Gross Take-Off Weight: 1430 grams. For safety reasons do not exceed this weight.
- Page 3 Guilin Feiyu Electronics Co., Ltd. Step 1: Frame Arm Assembly (3 sets) 1. Unpack the Arm pairs. Note the arms have LEDs with color: Blue, Red or Green. 2. Unpack these parts to complete the 3 arm sets: • M3 x 5mm button head screws & M3 x 30mm pillars •...
- Page 4 Guilin Feiyu Electronics Co., Ltd. Figure 2: Solder (red arrows) the 3 arms onto the bottom fuselage plate: M3×25mm Pillar Cross any two wire , Bottom plate with change Motor rotation Electronic components Cable tie through square groove to hold ESC to frame. Solder points 1.
- Page 5 Guilin Feiyu Electronics Co., Ltd. Step 3: Install ESCs and flight pack Power connector 1. After soldering the 3 arms, install the 6 ESCs by connecting the 3 ESC output wires to the 6 motors. At this juncture, don’t worry about the motor rotation direction. 2.
- Page 6 Guilin Feiyu Electronics Co., Ltd. Step 4 : Test The Motor Rotation Front Y6 SCORPION FLYER 1 (top) = ESC 1 CW 2 (top) = ESC 2 CW 3 (top) = ESC 3 CW 4 (bottom) = ESC 4 CCW...
