  • Page 1: Technical Data

    Air Conditioning Technical Data EEDEN14-100 RZQSG-L(8)Y1...

  • Page 3: Table Of Contents

    • Outdoor Unit • RZQSG-L(8)Y1 TABLE OF CONTENTS RZQSG-L(8)Y1 Features ............. 2 Specifications .

  • Page 4: Rzqsg-L(8)Y1

    Top efficiency: - new compressor that offers substantial efficiency • Daikin outdoor units are neat, sturdy and can easily be mounted on a improvements - new control logic that optimises efficiency at the most roof or terrace or simply placed against an outside wall frequently encountered operating conditions and that optimises the •...

  • Page 5: Specifications

    • Outdoor Unit • RZQSG-L(8)Y1 Specifications 2-1 Nominal Capacity And Nominal Input FCQHG100F/RZQSG100L8Y1 FCQHG125F/RZQSG125L8Y1 FCQHG140F/RZQSG140LY1 Cooling capacity Nom. 12.0 13.4 Heating capacity Nom. 10.8 13.5 15.5 Power input Cooling Nom. 2.57 3.71 4.17 Heating Nom. 2.51 3.60 4.29 Seasonal efficiency Cooling Energy label (according to...

  • Page 6: Nominal Capacity And Nominal Input

    • Outdoor Unit • RZQSG-L(8)Y1 Specifications 2-3 Nominal Capacity And Nominal Input FAQ100C/RZQSG100L8Y1 Seasonal efficiency Cooling Energy label (according to Pdesign 9.50 EN14825) SEER 5.61 Annual energy consumption Heating (Average Energy label climate) Pdesign 6.81 SCOP 4.01 Annual energy 2,378 consumption Nominal efficiency 3.01...

  • Page 7: Nominal Capacity And Nominal Input

    • Outdoor Unit • RZQSG-L(8)Y1 Specifications 2-5 Nominal Capacity And Nominal Input FBQ100C8/RZQSG100L8Y1 FBQ125C8/RZQSG125L8Y1 FBQ140C8/RZQSG140LY1 Nominal efficiency 3.31 3.21 3.02 (cooling at 35°/27° 3.65 3.51 3.41 nominal load, heating Annual energy consumption 1,435 1,870 2,220 at 7°/20° nominal Energy label Cooling load) Heating...

  • Page 8: Technical Specifications

    • Outdoor Unit • RZQSG-L(8)Y1 Specifications 2-8 Technical Specifications RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1 Capacity control Method Inverter controlled Casing Colour Ivory white Material Painted galvanized steel plate Dimensions Unit Height 1,430 Width Depth Packed unit Height 1,170 1,610 Width 1,015 Depth Weight Unit Packed unit...

  • Page 9: Electrical Specifications

    • Outdoor Unit • RZQSG-L(8)Y1 Specifications 2-8 Technical Specifications RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1 Piping connections Liquid Quantity Type Flare connection 9.52 Quantity Type Flare connection 15.9 Drain Quantity Type Hole Piping length OU - IU Min. Max. System Equival Chargel Additional refrigerant charge kg/m See installation manual Level difference...

  • Page 10: Electrical Data

    • Outdoor Unit • RZQSG-L(8)Y1 Electrical data 3 - 1 Electrical Data • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 11: 3 Electrical Data

    • Outdoor Unit • RZQSG-L(8)Y1 Electrical data 3 - 1 Electrical Data • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 12: 3 Electrical Data

    • Outdoor Unit • RZQSG-L(8)Y1 Electrical data 3 - 1 Electrical Data • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 13: Options

    • Outdoor Unit • RZQSG-L(8)Y1 Options 4 - 1 Options • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 14: Combination Table

    • Outdoor Unit • RZQSG-L(8)Y1 Combination table 5 - 1 Combination Table • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 15: Capacity Tables

    • Outdoor Unit • RZQSG-L(8)Y1 Capacity tables 6 - 1 Cooling Capacity Tables • Split - Sky Air • RZQSG-L(8)Y1...
  • Page 16 • Outdoor Unit • RZQSG-L(8)Y1 Capacity tables 6 - 1 Cooling Capacity Tables • Split - Sky Air • RZQSG-L(8)Y1...
  • Page 17 • Outdoor Unit • RZQSG-L(8)Y1 Capacity tables 6 - 1 Cooling Capacity Tables • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 18: Heating Capacity Tables

    • Outdoor Unit • RZQSG-L(8)Y1 Capacity tables 6 - 2 Heating Capacity Tables • Split - Sky Air • RZQSG-L(8)Y1...
  • Page 19 • Outdoor Unit • RZQSG-L(8)Y1 Capacity tables 6 - 2 Heating Capacity Tables • Split - Sky Air • RZQSG-L(8)Y1...
  • Page 20 • Outdoor Unit • RZQSG-L(8)Y1 Capacity tables 6 - 2 Heating Capacity Tables • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 21: Capacity Correction Factor

    • Outdoor Unit • RZQSG-L(8)Y1 Capacity tables 6 - 3 Capacity Correction Factor • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 22: Dimensional Drawings

    • Outdoor Unit • RZQSG-L(8)Y1 Dimensional drawings 7 - 1 Dimensional Drawings • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 23: Centre Of Gravity

    • Outdoor Unit • RZQSG-L(8)Y1 Centre of gravity 8 - 1 Centre of Gravity • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 24: Piping Diagrams

    • Outdoor Unit • RZQSG-L(8)Y1 Piping diagrams 9 - 1 Piping Diagrams • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 25: Piping Diagram Twin Application

    • Outdoor Unit • RZQSG-L(8)Y1 Piping diagrams 9 - 2 Piping Diagram Twin Application • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 26: Piping Diagram Triple Application

    • Outdoor Unit • RZQSG-L(8)Y1 Piping diagrams 9 - 3 Piping Diagram Triple Application • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 27: Piping Diagram Double Twin Application

    • Outdoor Unit • RZQSG-L(8)Y1 Piping diagrams 9 - 4 Piping Diagram Double Twin Application • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 28: Wiring Diagrams

    • Outdoor Unit • RZQSG-L(8)Y1 Wiring diagrams 10 - 1 Wiring Diagrams - Three Phase ∼ ∼ ∼ ∼ ∼ ∼ ∼ ∼ ∼ • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 29: Sound Data

    • Outdoor Unit • RZQSG-L(8)Y1 Sound data 11 - 1 Sound Power Spectrum • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 30: Sound Pressure Spectrum - Cooling

    • Outdoor Unit • RZQSG-L(8)Y1 Sound data 11 - 2 Sound Pressure Spectrum - Cooling • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 31: Sound Pressure Spectrum - Heating

    • Outdoor Unit • RZQSG-L(8)Y1 Sound data 11 - 3 Sound Pressure Spectrum - Heating • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 32: Sound Pressure Spectrum Quiet Mode

    • Outdoor Unit • RZQSG-L(8)Y1 Sound data 11 - 4 Sound Pressure Spectrum Quiet Mode • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 33: Installation

    • Outdoor Unit • RZQSG-L(8)Y1 Installation 12 - 1 Installation Method • Split - Sky Air • RZQSG-L(8)Y1...
  • Page 34 • Outdoor Unit • RZQSG-L(8)Y1 Installation 12 - 1 Installation Method • Split - Sky Air • RZQSG-L(8)Y1...

  • Page 35: Operation Range

    • Outdoor Unit • RZQSG-L(8)Y1 Operation range 13 - 1 Operation Range • Split - Sky Air • RZQSG-L(8)Y1...
  • Page 37 All content is copy- righted by Daikin Europe N.V. Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende...
