P RTS LIST - V
20
Reject Water
OUT
12
11
9
7
8
12. RO membrane housing end cap.
13. RO membrane housing end cap 'O' ring (not shown -
inside housing end cap) (order code 5885).
14. RO membrane housing including end cap and 'O rings
(order code 5871).
15. RO membrane housing 'O' ring (not shown - on the
threaded part of the housing) (order code 5886).
16. Pure water outlet.
17. Reject water 90° connecting elbow hosetail including locking
nut (order code 5874).
18. Flow restrictor with combined manual flush valve (50 = order
code 5879, 75 = order code 5880, 100 = order code 5881).
19. Flow restrictor connecting T piece and locking nuts (not
shown) (order code 5876).
20. Reject water outlet (to order a replacement flow
restrictor straight outlet hosetail order code 5872).
21. RO membrane - not shown (50 = order code 5858,
75 = order code 5859, 100 = order code 5860).
22. Self piercing "C" clamp water connection fitting (order code 5868).
1
23. 2m / " RO flexible tubing (WHITE feed water tubing) (order
4
code 5866 - per metre).
1
24. 2m / " RO flexible tubing (BLUE pure water tubing) (order
4
code 5865 - per metre).
1
25. 2m / " RO flexible tubing (RED reject water tubing) (order
4
code 5864 - per metre).
26. Filter housing tool (order code 5882).
27. Drain saddle clamp (order code 5867).
28. Dust prevention plugs (if installed).
29. TDS Monitor (order code 5857).
Pure dvanced
29
14
18
10
10
1. Wall mounting bracket.
2. Feed water (mains water)
17
3. 10" 5 micron sediment filter
1
4. Filter housing 'O' ring
5. Filter housing 'O' ring B (not
6. 10" 5 micron sediment filter
7. 10" active carbon block filter
8. 10" active carbon block filter
3
9. Integrated pressure gauge (order
10. 90° connecting elbow hosetail
6
11. RO membrane water inlet 90°
Feed
Water
IN
2
3
inlet (to order replacement 90°
hosetail including hosetail locking
nut order code 5873).
housing (transparent housing)
(order code 5870).
shown - on the threaded part of
the housing) (order code 5883).
shown - inside housing lid) (order
code 5884).
cartridge (order code 5863).
housing (white housing) (order
code 5869).
including 2pcs of flat rubber
gaskets (order code 5862).
code 5887).
including locking nuts (order code
5873).
connecting elbow hosetail
including locking nut (order code
5874).
B CK VIEW
Pure Water
OUT
16
(not
10
