Features of LG-TM250
1. Wave Type
• CELLULAR : G7W
• PCS : G7W
2. Frequency Scope
Transmit Frequency (MHz)
PCS
CELLULAR
824.82 ~ 848.19
1850~1910
3. Rated Output Power : CELLULAR = 0.20W
4. Output Conversion Method : This is possible by correcting the key board channel.
5. Voltage and Current Value of Termination Part Amplifier (Catalogue included)
MODE
CELLULAR
PCS
6. Functions of Major Semi-Conductors
Classification
MSM6050-FBGA
MCP (TH50VPF5585ADSB)
RFR6000
RFT6100
7. Frequency Stability
• CELLULAR : ±0.5PPM
• PCS : ±0.1PPM
LG Electronics Inc.
Receive Frequency (MHz)
CELLULAR
PCS
869.82~893.19
1930~1990
PCS = 0.20W
Part Name
Voltage
CX77105
CX77107
Terminal operation control and digital signal processing
Flash Memory (32Mbit) + SRAM (32Mbit)
Storing of terminal operation program
Converts Rx RF signal to baseband signal
Converts baseband signal to Tx RF signal
GPS
1575.42
Current
4.0V
600mA
4.0V
700mA
Function
Power
0.20W
0.20W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LG-TM250 and is the answer not in the manual?

Questions and answers

Related Manuals for LG LG-TM250

Summary of Contents for LG LG-TM250

  • Page 1 Features of LG-TM250 1. Wave Type • CELLULAR : G7W • PCS : G7W 2. Frequency Scope Transmit Frequency (MHz) Receive Frequency (MHz) CELLULAR CELLULAR 824.82 ~ 848.19 1850~1910 869.82~893.19 1930~1990 1575.42 3. Rated Output Power : CELLULAR = 0.20W PCS = 0.20W...
