Summary of Contents for Olympus CAMEDIA AZ-2 ZOOM
- Page 1 DIGITAL CAMERA ZOOM BASIC MANUAL ENGLISH...
-
Page 2: For Customers In Canada
Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please read these instructions carefully to enjoy optimum performance and a longer service life. This manual explains shooting and playback basics. For details on functions, read the advanced manual. -
Page 3: Unpacking The Box Contents
Lens cap and Strap xD-Picture Card cap string Lithium ion battery AC adapter (D-7AC) Stand USB cable (LI-20B) AV cable OLYMPUS Master Basic manual Advanced manual CD-ROM (CD-ROM) Warranty card Registration card Camera cleaner Registration card is not provided in some areas. - Page 4 Attach the strap correctly as shown above so that the camera does not fall off. Olympus is not responsible for any damages incurred when the strap is attached incorrectly and the camera comes off. Pull on the strap to make sure it is fastened securely.
-
Page 5: What You Can Do With This Camera
What you can do with this camera You can choose from more than 10 different types of scene shooting modes, making it easy to set the appropriate shooting mode for a variety of shooting situations! Once you’ve selected the shooting mode, just press the shutter button to take the picture. -
Page 6: Table Of Contents
Power off ..........22 What you can do with OLYMPUS Master software ....23 Information . -
Page 7: Safety Precautions
Safety precautions CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL. Lightning flash with an arrowhead, enclosed in a triangle, alerts you to the... - Page 8 Safety precautions Lightning — If a lightning storm occurs while using a specified AC adapter, remove it from the wall outlet immediately. To avoid damage from unexpected power surges, always unplug the AC adapter from the power outlet and disconnect it from the camera when the camera is not in use.
- Page 9 Contact the nearest authorized Olympus service center. Do not touch the camera or AC adapter until charging is finished and the battery has cooled.
- Page 10 Ensure the adapter used is designed for your region or country. For more information, contact the nearest Olympus service center or the store of purchase. Olympus makes no representations or warranties regarding any damages caused by AC adapters not recommended by Olympus.
- Page 11 If the battery leaks, becomes discolored or deformed, or appears abnormal in any way during operation, stop using the camera immediately. Contact your dealer or an authorized Olympus service center. Continued use may result in fire or electric shock. If the battery leaks fluid onto your clothing or skin, remove the clothing and flush the affected area with clean, running cold water immediately.
- Page 12 – Consult your dealer or an experienced radio/TV technician for help. Only the OLYMPUS-supplied USB cables should be used to connect the camera to USB-enabled personal computers (PC). Any unauthorized changes or modifications to this equipment would void the user's authority...
-
Page 13: Loading The Battery
Loading the battery The camera uses an Olympus lithium ion battery (LI-20B). Open the battery/card compartment cover. The OLYMPUS logo should be facing the monitor side. Slide the battery/card compartment cover in the direction of the arrow The cover unlocks and opens in the... -
Page 14: Removing The Battery
Loading the battery Removing the battery Make sure that the power lamp is turned off. Slide the knob in the direction of the arrow With the battery held down, tilt the camera carefully so that the battery does not drop from the camera. Remove the battery Close the battery/ card compartment cover. -
Page 15: Charging The Battery
Charging the battery Charging is performed with the battery loaded in the camera. The battery is not fully charged when purchased. Before use, be sure to charge the battery with the provided AC adapter. To the AC wall outlet AC plug AC adapter (provided) During charging, the power lamp blinks slowly. -
Page 16: Inserting The Card
Inserting the card “Card” in this manual refers to the xD-Picture Card. The camera uses the card to record pictures. Index area Write the card’s contents here. Contact area The area that touches the camera’s electric contact points. The camera reads the card here. Compatible xD-Picture Card: 16 - 512 MB Make sure that the power lamp is... -
Page 17: Removing The Card
Removing the card Push the card all the way in to unlock it, then let it return slowly. The card may eject forcefully if you take your finger off it immediately after pushing it or if you flick it with your fingers. -
Page 18: Power On
High* Low.Charge the battery. * Your digital camera's power consumption varies greatly depending on usage and operating conditions. Under some operating conditions, the camera may turn off without warning that battery power is low. If this occurs, re-charge the battery. -
Page 19: Shooting
Shooting Place the AF target mark on the subject while viewing the monitor to compose your shot. Shooting mode AF target mark HQ 2288 1712 Record mode Adjust the focus. Press the shutter button gently (halfway). Green lamp Flash stand-by/Flash charging mark HQ 2288 1712 Hold the camera firmly with both... - Page 20 Shooting Release the shutter. Press the shutter button all the way (fully). HQ 2288 1712 Never remove the battery, card or AC adapter while the Doing so could destroy stored pictures and prevent storage of pictures you have just taken. When taking pictures against strong backlight, the area of the picture in shadow may appear colored.
-
Page 21: Playback
Playback Display recorded images. The shooting information displayed on the screen The last recorded image disappears after 3 appears. seconds. 100–0015 ’04.12.24 00:00 Use the Joystick to play back images you want to view. Push the Joystick left to display the previous image. Push the Joystick down to jump to the image 10 frames ahead. -
Page 22: Power Off
Power off Attach the lens cap to the lens. Turn off the camera. Press The power lamp turns off. Monitor When the camera is turned off, the monitor turns off. -
Page 23: En What You Can Do With Olympus Master Software
* Install OLYMPUS Master on your computer from the provided CD-ROM. OLYMPUS Master allows you to register as the camera’s owner. Doing so will enable you to receive information on software or firmware upgrades from Olympus. -
Page 24: Information
Memory No. of storable pictures (When using a 16 MB card) : Digital camera (for shooting and displaying) : Digital recording, JPEG (in accordance with Design rule for Camera File system (DCF)) : Exif 2.2, Digital Print Order Format (DPOF),... - Page 25 Image pickup device : 1/2.7" CCD solid-state image pickup 4,230,000 (gross) Lens : Olympus lens 6.2 mm to 17.3 mm, f2.9 to f4.8, (equivalent to 40 mm to 112 mm lens on 35 mm camera) Photometric system : Digital ESP metering, Spot metering system Shutter speed : 1/2 to 1/1000 seconds (the slowest shutter speed is 4 sec.
-
Page 26: Specifications - Provided Accessories
Dimensions Weight SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT ANY NOTICE OR OBLIGATION ON THE PART OF THE MANUFACTURER. : xD-Picture Card for digital camera : NAND Flash EEP-ROM : Shown on the card –20 - 65˚C (–4 - 149˚F) (storage) - Page 27 MEMO...
- Page 28 Two Corporate Center Drive, PO Box 9058, Melville, NY 11747-9058, U.S.A. Tel. 1-631-844-5000 24/7 online automated help: http://www.olympusamerica.com/support Olympus software updates can be obtained at: http://www.olympus.com/digital Wendenstrasse 14-18, 20097 Hamburg, Germany Tel. +49 40 - 23 77 3-0 / Fax +49 40 - 23 07 61 Please visit our homepage http://www.olympus-europa.com...
