2.4 GHz WIRELESS
AUDIO/VIDEO SENDER
VS6966
With remote control extender
PLEASE READ BEFORE USE
OWNER'S MANUAL
296 05 600.6
B
G128
Z
512H
T
FCC ID: LB3AV-RECEIVER
FCC ID: LB3AV-SENDER
DOC NO: 20003257 Rev: 1A
DATE: 12- SEP-1997
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lorex VS6966
Summary of Contents for Lorex VS6966
- Page 1 2.4 GHz WIRELESS AUDIO/VIDEO SENDER VS6966 296 05 600.6 With remote control extender G128 512H FCC ID: LB3AV-RECEIVER FCC ID: LB3AV-SENDER PLEASE READ BEFORE USE c Copyright Strategic Vista Corp. 2000 OWNER'S MANUAL No Dissemination or use Allowed Without Prior Written Permission DOC NO: 20003257 Rev: 1A All specification subject to change without notice.
- Page 2 However, there is no guarantee that CUSTOMER SERVICE interference will not occur in a particular installation. If this 1-888-42-LOREX equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and...
-
Page 3: Table Of Contents
G. Troubleshooting, Care and maintenance Table of Contents Please read this owner's manual carefully and follow the steps described in it. If you still have difficulties, consult the following table. It will guide you though the most common problems and their solutions. A. -
Page 4: Introduction To 2.4 Ghz Wireless Video Sender
RF signal is converted back to the original IR signal and beamed to the audio/video source. VS6966 also integrates an UHF remote control extender to allow you to control the audio or video source from another room using your existing TV remote control. -
Page 5: Description Of Box Contents
B. Description of Box Contents REMOTE REMOTE ANTENNA CONTROL CONTROL ANTENNA ANTENNA ANTENNA PITTED Check to make sure that all of the items shown as below are included SIDE REMOTE PITTED with your system. If something is missing, please contact your dealer CONTROL ANTENNA SIDE... -
Page 6: Panel Controls And Features
E. Orienting Units for Optimal performance 6. a) IR extender to connect to transmitter's rear panel NOTE The system should be placed on a flat, stable surface to prevent damage to it from falling. b) fasten strips X 2 For uneven or slick surfaces, such as the top of your TV, audio/video equipment, or entertainment center, fastener strips have been provided to secure the units (cut the strips into smaller squares with scissors). - Page 7 REAR VIEW FOR RECEIVER Connecting Receiver to Remote TV through VCR This setup enables you to record transmitted audio and video on your remote VCR and also enjoy the picture and sound on a remote TV at the same time. Power ON/OFF switch TV modulator output 1.
-
Page 8: Setting Up System
Connecting the Receiver D. Setting Up System How To Receive Wireless Audio/Video on Your TV To enjoy wireless video and audio, just connect the transmitter to whatever audio/video source you There are two ways to receive wireless audio/video signals on your remote TV (TV want to enjoy from another location, and connect the receiver to the TV, monitor or powered in another location such as the bedroom or kitchen): speakers in that other location. - Page 9 How To Transmit Audio/Video from Your Satellite Receiver How To Transmit Audio/Video from Your VCR You can transmit audio/video either directly from your satellite receiver, or by connecting 1. Connect one set of audio/video (A/V) cables to the A/V jacks of the transmitter it to your VCR.
