Use these instructions for the following Ellipticals:
• ClubStride® 5100-LE
•
Receiving
When the carrier delivers your order, verify that the number of items received equals the number listed on
the freight bill or express receipt.
Inspect the containers for damage. Itemize discrepancies and damage on the waybill and have the agent
sign it. Failure to describe external evidence of loss adequately may result in the carrier refusing to honor
your claim. Do not discard the packing materials until you have verified physical condition and proper
operation.
Installation Notice
The elliptical must be installed correctly before being used. StairMaster® recommends that you contact
your elliptical dealer or sales representative when your equipment arrives. The representative will help
unpack, install, and demonstrate it, to ensure that:
• Equipment is free from shipping damage
• Installation and operation are in accordance with StairMaster® standards.
Incorrect installation by unauthorized personnel can lead to equipment damage and may void the warranty.
Hardware Included:
• (4) Screw, 3/8" -16 X 3⁄4", Hex Head
• (4) Washer, 3/8" Split Lock
• (4) Washer, 3/8" Flat
• (18) Screw, #10-32 X 3⁄4", Pan Head W/Lock Washer
• (4) Washer, Plastic, 1 1⁄2" I.D. X 2 1⁄4" O.D.
• (2) Screw, 1⁄2"-13 X 4", Hex Head
• (4) Washer, 1⁄2" Flat
• (2) Nut, 1⁄2" – 13, Self Locking
1 of 6
Elliptical Unpacking and Installation Instructions
40735 REV A

Advertisement

loading

Related Manuals for Stairmaster ClubStride 5100-LE

Summary of Contents for Stairmaster ClubStride 5100-LE

  • Page 1 Do not discard the packing materials until you have verified physical condition and proper operation. Installation Notice The elliptical must be installed correctly before being used. StairMaster® recommends that you contact your elliptical dealer or sales representative when your equipment arrives. The representative will help unpack, install, and demonstrate it, to ensure that: •...
  • Page 2 Components Included: • (1) Bottom Front Left Cover • (1) Bottom Front Right Cover • (2) Bottom Pivot Cover #1 • (2) Bottom Pivot Cover #2 • (2) Bottom Swing Arm Shaft Tools Required • Shears or razor knife • 9/16” Hex Socket Wrench •...

  • Page 3: Main Frame

    4X 3/8" FLAT WASHER 4X 3/8" LOCK WASHER 4X 3/8"-16 HEX HEAD SCREWS FRONT BOTTOM FRONT FLANGE FLANGE (UPRIGHT) (MAIN FRAME) FIGURE 1 9. Rotate the Elliptical mast into the proper position, taking care not to pinch the electrical cable at the bottom in the process.
  • Page 4 SWING ARM (RH SHOWN) SWING ARM SHAFT 2X 1 1/2" I.D. PLASTIC FLAT WASHER 1/2"-13 2X 1/2" FLAT WASHER 1/2"-13 HEX HEAD SCREW FOOT SUPPORT TUBE (RH SHOWN) FIGURE 2 12. Install (1) “Bottom Swing Arm Shaft” into the front of the foot support tube.(See Figure 2). 13.
  • Page 5 FRONT BOTTOM FRONT BOTTOM RIGHT COVER LEFT COVER 10X #10-32 PHILLIPS HEAD SCREW FIGURE 3 15. Install the front bottom left and right covers and align the holes at the sides. (See Figure 3). 16. Install and tighten (10) #10-32 phillips head screws. This will require a #2 phillips head screw driver. (See Figure 3).
  • Page 6 19. Repeat step 17 and 18 for the opposite foot support tube. 20. The Elliptical can now be removed from the pallet and is ready for use. If the Elliptical does not run smoothly, contact your StairMaster® Fitness sales representative before using Nautilus Health & Fitness Group StairMaster®...
