AMT Legend amps F-1 User Manual

Safety Instructions
CAUTION! There are no user-serviceable components inside the device. Only
qualified specialists must perform the device repair.
WARNING! To avoid possible malfunctions the device must not be exposed to rain
or moisture. Prevent water or other liquids from getting inside the device. Do not
place vessels filled with liquids (such as vases etc.) on top of the device.
This symbol points out important information related to the
device maintenance and operation, which can be found in the
accompanying documentation.
Please read the instruction manual carefully.
1. Keep the manual at hand.
2. Pay close attention to the warning instructions.
3. Adhere to all maintenance instructions.
4. Uses only dry cloth to clean the device, which must be
disconnected from the power adapter.
5. Do not place the device next to heat sources, avoid direct
sunlight.
6. Lay the power cable in such a way that it is impossible to be
stepped on. Besides, avoid its contacts with sharp angles etc.
If the plug of the power adapter is used for the device
disconnection from mains, it must be easily accessible.
7. Use only auxiliary devices and accessories recommended by
the manufacturer.
8. Turn the device off during thunderstorms.
9. All works related the device repair must be carried out only by
qualified servicing personnel.
10. IMPORTANT! All servicing instructions are intended exclusively
for qualified personnel. Do not carry out any repair works not
specified in the instruction manual. All repair works are to be
carried out by qualified personnel only.
www.amtelectronics.com
1
Contents
Important instructions
Complete set
Introduction
Before you start
Specifications
Controls
Top panel
Right panel
Left panel
Only for qualified personnel
FX.LOOP mode switch
Audio connections and switching
Audio connections (1 channel)
Audio connections (2 channels)
Block diagram
Power adapter low-voltage contacts arrangement
IMPORTANT INSTRUCTIONS!
NON-OBSERVANCE OF THE FOLOWING INSTRUCTIONS MIGHT RESULT
IN YOUR DEVICE DAMAGE. GUARANTEE IS VOID IF THE DAMAGES ARE
CAUSED BY NON-OBSERVANCE OF THESE INSTRUCTIONS.
After transportation or storage of the device under negative
temperatures make sure to leave the device under room
temperature in its original packaging for AT LEAST 2
HOURS!
To connect the guitar preamp to other devices use
exclusively cables intended for such connections.
Under no circumstances use other types of cables such as
for speakers etc.
CONNECTION of the guitar preamp to power adapter:
Connect the adapter only AFTER all audio connections have
been accomplished!
Before connecting the preamp to power adapter make sure
that the casing, cables, low-voltage connector and power
plug are free from damages: no cuts, cracks, dents and so
on and are in operable condition.
To connect the preamp to the power adapter first insert the
low-voltage connector of power adapter into corresponding
socket on the right panel of the switch and then plug the
adapter into the wall outlet.
DISCONNECTION of the guitar preamp from power adapter:
To disconnect the guitar preamp from the power adapter
first disconnect the
disconnect its low-voltage connector from the socket on
the right panel of the guitar preamp.
COMPLETE SET
1.
Guitar preamp
2.
Instruction manual
3.
Packaging box
4.
Power adapter
5.
Warranty card
