- Page 1 CCTV Power Supply Manual 16 Channel =(2 x 8Channel) with Dual Volt / Amp meter 24VAC 1.5U Rack Mount Model: PAC-24RM1616(S84745)
- Page 2 PAC-24RM1616(S84745) PAC-24RM1616(S84745) Front Panel Overview: This PACOM Rack Mount CCTV Power Supplies provides 24VAC distributed via sixteen (16) PTC protected outputs for powering CCTV Cameras and other video accessories. 24.3 24.3 Notes: 2 Power On/Off Switches have been provided for each of the 8 Channels at the 6.55...
- Page 3 PAC-24RM1616(S84745) PAC-24RM1616(S84745) PAC-24RM1616(S84745) Parallel Output Configuration By connecting more than 1 output in parallel the normal current availability can be doubled, tripled or even quadrupled 24VAC Cable Distance (meters) 24VAC Cable Distance (meters) Normal Current Limit X 2 (208ma) (208ma)
-
Page 4: Troubleshooting
PAC-24RM1616(S84745) PAC-24RM1616(S84745) Troubleshooting 1. Power does not turn on • Check front panel leds and rear main fuse • Ensure power cord is firmly in its socket and switch A and B are in the on position • Ensure you have 240VAC supply to the Power Supply Unit 2.
