Samsung RF263TE Series User Manual

Hide thumbs Also See for RF263TE Series:
Table of Contents

Advertisement

Quick Links

Free Standing Appliance
DA68-02601A(EN+FR+ES)-0.2.indb 1
Refrigerator

user manual

imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service or accessory parts,
please register your product at or contact
www.samsung.com/register
1-800-SAMSUNG (726-7864)
RF263TE****
RF263BE****
English
2012.3.31 9:49:28 AM

Advertisement

Table of Contents
loading

Related Manuals for Samsung RF263TE Series

Summary of Contents for Samsung RF263TE Series

  • Page 1: User Manual

    RF263TE**** RF263BE**** Refrigerator user manual English imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service or accessory parts, please register your product at or contact www.samsung.com/register 1-800-SAMSUNG (726-7864) Free Standing Appliance DA68-02601A(EN+FR+ES)-0.2.indb 1 2012.3.31 9:49:28 AM...
  • Page 2 safety information SAFETY INFORMATION Call the contact center for help. Before operating the appliance, please read this Note. manual thoroughly and retain it for your reference. Use this appliance only for its intended purpose as described in this instruction manual. These warning signs are here to prevent This appliance is not intended for use by persons injury to you and others.
  • Page 3 • This appliance should be positioned in such a • The appliance must be positioned so that the way that it is accessible to the power plug. plug is accessible after installation. Failing to do so may result in an electric shock •...
  • Page 4 If you smell pharmaceutical or smoke, pull scientifi c materials, or temperature sensitive out power plug immediately and contact your products in the refrigerator. Samsung Electronics service center Products that require strict temperature controls must not be stored in the refrigerator. •...
  • Page 5 A spark may result in explosion or fi re. If any dust or water is in refrigerator, pull out If the products is equipped with the LED Lamp, the power plug and contact your Samsung do not disassemble Lamp Cover and LED Electronics service center.
  • Page 6 Unplug the refrigerator before cleaning by a 3rd party on this fi nished appliance or making repairs. are not covered under Samsung warranty service, nor can Samsung be State of California Proposition responsible for safety issues that result WARNING 65 Warnings: from 3rd party modifi...
  • Page 7 door/door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance. Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure.

  • Page 8: Getting Ready To Install

    Setting up your French Door Refrigerator The following chart details the exact height and GETTING READY TO INSTALL depth of this Samsung French Door Refrigerator. THE REFRIGERATOR RF263T** / RF263B** / RF263N** Model RF261B**/ RF260B** Congratulations on your purchase of this Samsung Depth “A”...

  • Page 9: Removing The Refrigerator Doors

    FLOORING REMOVING THE For proper installation, you must place this REFRIGERATOR DOORS refrigerator on a level, hard surface that is the same height as the rest of the floor. This surface For some installations you need to remove the should be strong enough to support a fully loaded fridge and freezer drawers so you can move the refrigerator to its final location.
  • Page 10 Fix the handles to the doors by sliding them left side firmly. Fix the handles to the doors by sliding them down firmly. Tilt up the Handle bar and tighten with wrench Tighten with wrench fi firmly. Drawer door handle assembly Disassemble the refrigerator doors Be careful not to drop and scratch the Check the direction of Handle...

  • Page 11: Refrigerator Doors

    2 ) on the left side Disconnect two connectors ( REATTACHING THE door. To remove the water coupler from the REFRIGERATOR DOORS hinge, twist and pull it from the hinge. Remove the water line ( 3 ) while pressing the marked To reattach the fridge doors after you have moved part ( 4 ) of the water line coupler.

  • Page 12: Making Minor Adjustments Between

    Holding the top of the Freezer Drawer, pull it out How to adjust the level all the way and then remove it from the rail system. Open the freezer drawer and remove the lower basket. Insert a flat-blade screwdriver (-) into a notch on the left control lever, and turn it counter clockwise to level the refrigerator.

  • Page 13: Installing The Water Dispenser Line

    Pull out the freezer drawer ( 1 ) to reveal After you have connected the water line, make the lower hinge ( 2 ). sure the water storage tank inside the refrigerator Insert the supplied allen wrench (3/16”) ( is properly filled. To do this, press the water dispenser lever until the water runs from the water into the shaft ( 4 ) of the lower hinge.
  • Page 14 Only connect the water line to a drinkable water source. If you have to repair or disassemble the water line, get a snug, leak-free connection. Refrigerator You can test the water line quickly using a paper cup.Under normal conditions, the water Plastic Tubing Compression (Assembled)
  • Page 15 Do not store food which goes bad easily at low temperature, such as bananas, melons. Your appliance is frost free, which means there is no need to manually defrost your appliance, as this will be carried out automatically. Temperature rise during defrosting can comply with ISO requirements.

  • Page 16: Using The Control Panel

    Operating your French Door Refrigerator USING THE CONTROL PANEL ( 4 ) Alarm Hold 3 sec for If the door alarm is set to On, an alarm Lighting beeps if any refrigerator door is left open for more than three minutes. The beeping stops when you close the door.

  • Page 17: Changing The Water Filter

    WARNING of water filters in your SAMSUNG Refrigerator. USE ONLY SAMSUNG BRAND WATER FILTERS. SAMSUNG will not be legally responsible for any damage, including, but not limited to property Touch the “Ice Type/Water damage caused by water leakage from the use of Hold 3 sec for Filter Reset ”...

  • Page 18: Controlling The Freezer Temperature

    Removing any residual matter inside The basic temperature and recommended temperatures of the Freezer and Refrigerator the water supply line after installing Compartments are 0°F and 37°F(or -18°C and the water filter. 3°C) respectively. If the temperature of the Freezer Turn ON the main water and Refrigerator Compartments are too high or supply and supply water...

  • Page 19: Using The Ice Dispenser

    Display light may blink. If the blinking continues Maintaining the Ice Bucket for a long period of time, please contact a Samsung Electronics Service Center. To clean the ice bin/bucket, wash with a mild detergent, rinse well, and dry thoroughly it. Do not use harsh or abrasive cleaners or solvents.
  • Page 20 remove all ice cube tray. If not using the ice dispenser, it is possible to stack the cubes. Hold down the button. Remove the tank in the direction of the arrow. Dispose of ice cubes or ice mass. Push the bottom of the tray until it clicks. and try again.

  • Page 21: Parts And Features

    Please wait 1 second before removing the cup after dispensing water to prevent spills. Do not pull out the lever dispenser after dispensing ice or water. It comes back automatically. Ice is made in cubes. When you select “Crushed”, the ice maker Test button grinds the ice cubes into crushed ice.

  • Page 22: Using The Cool Select Pantry

    USING THE COOL SELECT Deli Fresh Chilled Pineapple cucumbers steaks PANTRY lemon apples hard cheeses avocado oranges cold cuts The Cool Select Pantry is a full-width drawer with adjustable temperature control. This pantry potato grapes bacon can be used for large party trays, deli items, pizza, zucchinis hot dogs beverages or miscellaneous items.

  • Page 23: Using The Doors

    Injury may occur if the door bins are not To relocate the Cool select pantry – Push firmly assembled. the rails to the back of the refrigerator. Place the Do not allow children to play with the bins. Sharp drawer onto the rails and slide the pantry back corners of the bins may cause injury.

  • Page 24: Cleaning The Refrigerator

    Tilt up the rear of the drawer and lift straight out. To relocate - Place the drawer onto the rails ( 4 ) Caring for your Samsung French Door Refrigerator by tilting it up. Lower the drawer into place until it prolongs the life of your appliance and helps keep the refrigerator free of odor and germs.
  • Page 25 Cleaning the Ice / Water Dispenser Wipe the Ice / Water Dispenser with a clean and soft cloth. When using the crushed ice selection from the dispenser CAUTION some residual ice chips may start to collect in the ice chute. To prevent that residual ice from melting and running out of the chute you should clean out the residual...

  • Page 26: Food Storage Tips

    FOOD STORAGE TIPS Foods Refrigerator Freezer Storage Tips DAIRY PRODUCTS Butter 2-3 Weeks 6-9 Months Wrap or cover tightly. Check date code. Most milk and similar prod - ucts are sold in date-coded cartons that indicate Milk 1-2 Weeks Not recommended a products’...
  • Page 27 Foods Refrigerator Freezer Storage Tips FISH AND SHELLFISH Fish Fatty Fish (mack - 1-2 Days 2-3 Months Keep in original wrapper and store in coldest part of erel, trout, salmon) refrigerator. Package in vapor-proof and moisture Lean Fish (cod, proof wrap for freezer. Freeze at 0ºF(-18°C ). Thaw 1-2 Days 6 Months flounder, etc)

  • Page 28: Troubleshooting

    Troubleshooting PROBLEM SOLUTION The refrigerator Check if the power plug is properly connected. does not work at Check if the set temperature on the digital display is warmer than the freezer or fridge all or it does not inner temperature. If it is, set the refrigerator colder. chill sufficiently.
  • Page 29 Samsung authorized service center. Samsung will repair or replace any part found to be defective, at our option and at no charge as stipulated herein, with new or reconditioned parts during the limited warranty period specified above. All replaced parts and products become the property of Samsung and must be returned to Samsung.
  • Page 30 In case the need for servicing arises Do not hesitate to call any Samsung Authorized Service Center nearby giving them your name, address and telephone number when your product is not functioning properly. Warranty Information ( CANADA ) Limited Warranty for Original Purchaser This Samsung product is warranted by Samsung Electronics Canada, Inc.
  • Page 31 Memo...
  • Page 32 * Requires reader to be installed on your smartphone QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT WRITE 800-SAMSUNG Samsung Electronics America, Inc. www.samsung.com (800-726-7864) 85 Challenger Road Ridgefield Park, NJ 07660 Samsung Electronics Canada Inc. 800-SAMSUNG CANADA www.samsung.com/ca...

This manual is also suitable for:

Rf263be series
