Summary of Contents for IPcorder KNR-090 4

  • Page 2 IPCorder User Manual 1.4 Copyright c KOUKAAM a.s. 2011...
  • Page 3: Table Of Contents

    Contents 1 About IPCorder 1.1 System Description ..........
  • Page 4 CONTENTS CONTENTS 4.2 Recordings ..........4.2.1 Video Export .
  • Page 5: About Ipcorder

    IPCorder allows configuration of the system so that it behaves accordingly to reflect the time of the day, or the day of the week. (It is thus possible to configure the system to, for example, record the video signal from cameras in higher resolution than during the day, if it detects motion during night-time and send an additional e-mail, if this occurs on a weekend.)
  • Page 6: System Requirements

    In contrast to traditional methods that required new browser window or an independent programme for each device, the IPCorder is able to display multiple outputs from various devices at once. The user first selects a set of devices (referred to as View), whose outputs he/she wants to display, and then is able to simultaneously view them.
  • Page 7 In case of downloading a bigger number of cameras at once, it is necessary that the IPCorder is connected to the 1GB port of the network switch.
  • Page 8: Functions Overview And Management

    2.2 Network Access this section in the menu Management – Configuration – Network. In the first part – Network Settings – you can configure parameters which define how and where the IPCorder will be available in the local network (figure 2).
  • Page 9 DNS server – Is an IP Address of the Domain Name Server, which the device should use for translation of the DNS names to IP Addresses. In the Domain Settings you can configure under what DNS name should the IPCorder appear within the network: Host Name –...
  • Page 10: E-Mail

    Rescue Mode (if this option is selected bellow) or eventually other system status changes. Send an E-mail when rescue mode activated – Select this option if you want the IPCorder to send an e-mail to the administrator when it reboots into the Rescue Mode.
  • Page 11: Time

    Confirm the changes by clicking the Apply Changes button. The IPCorder automatically switches to and from the DTS time (aka summer time) depending on the selected...
  • Page 12: Storage Space Settings

    2 FUNCTIONS OVERVIEW AND MANAGEME 2 FUNCTIONS OVERVIEW AND MANAGEME 2.5 Storage Space Setti 2.5 Storage Space Sett Figure 4: Time settings time zone. 2.5 Storage Space Settings Page (Settings – Settings – Storage) shows device disk information. (Picture 5). Raid type –...
  • Page 13: Ftp

    2 FUNCTIONS OVERVIEW AND MANAGEMENT 2 FUNCTIONS OVERVIEW AND MANAGEMENT 2.6 FTP 2.6 FTP Figure 5: Storage Figure 6: Rescue mode – Erase disk If for some reason you need to replace a disk, turn the device off first, replace the disk. The device will boot into the rescue mode and unless the disk was already formatted you will need to set up the disk by clicking the Setup disk tool.
  • Page 14: Remote Access

    Purge data older than ... available in the Storage section. 2.7 Remote Access If you want to access the IPCorder and its subordinate devices remotely from other networks (i.e. via Internet), it is necessary to configure the so-called Remote Access. For making this possible, the local network in which the IPCorder is connected must contain a router (Internet Gateway) capable of translating addresses.
  • Page 15 It has to be large enough to allow for two ports for each device and two for IPCorder. The values of From and To are inclusive, and the value set for Preferred web port must lie within this range.
  • Page 16 Asus WL500g, the final configuration should look like in figure 10) and keep them up to date, and in accordance with the IPCorder settings. If you have enabled the remote access, we recommend that you secure the access to cameras with password...
  • Page 17 (only when the user is watching the live camera stream in IPCorder’s viewing applet) and what is more, the assigned ports differ with each access.
  • Page 18: User Account Management

    Views or if need be, allow him to use the remote access (for this setting to function, you first need to configure the remote access to the IPCorder properly in the menu Management –...
  • Page 19: User Settings

    2 FUNCTIONS OVERVIEW AND MANAGEMENT 2 FUNCTIONS OVERVIEW AND MANAGEMENT 2.9 User Settings 2.9 User Settings Figure 12: User Preferences 2.9 User Settings Each user has, apart from his/her password, also a personal set of user preferences. These most importantly include the individual interface language settings and the date, time and decimal numbers format settings.
  • Page 20 2 FUNCTIONS OVERVIEW AND MANAGEME 2 FUNCTIONS OVERVIEW AND MANAGEME 2.9 User Sett 2.9 User Setti Figure 13: Changing the password...
  • Page 21: Device Management

    Figure 14: Automatic discovery of devices To be able to operate a device, the IPCorder first needs to become aware of it. The devices that are switched on and connected in the same segment of the local network should be searchable. Click the appropriate button in the menu Management –...
  • Page 22 The part labelled Activation Settings – Pool of Assigned IP is related to the possibility of automatic assigning of IP Addresses to devices connected to the IPCorder (i.e. cameras). If you select Assign an IP Address in the settings of a subordinate device (i.e. camera or sensor), the IPCorder will automatically assign the address according to the scale specified here.
  • Page 23 The alternative to the automatic detection of the connected devices is the possibility of adding the devices manually (Figure 15) in the menu Management – Devices – Add Manually (for example if the device is in a different network that the IPCorder). Figure 15: Manual device activation...
  • Page 24: Managing Device Settings

    3.2 Managing Device Settings Port numbers it is possible to redefine the ports IPCorder should use for the communication with the device. This can be usefull if the camera’s services run on non-standard ports or if the device is located in a different network –...
  • Page 25 If the camera supports multiple streams, the user can choose which should be displayed. The recording modes can be configured in the section Recording. The IPCorder interface offers the possibility of defining so-called schedules (i.e. various periods of time within a week, for example Monday and Wednesday from 7am to 2pm) and subsequent configuring of different system behaviour for each of them.
  • Page 26: Schedules

    If the camera supports multiple streams, the user can further choose which should be recorded. When deciding which setting to use, the IPCorder goes through the recording mode list from the top to the bottom. The first appropriate item, time of which agrees with the schedule, will be used. All other items are ignored.
  • Page 27 3 DEVICE MANAGEMENT 3 DEVICE MANAGEMENT 3.4 Schedules 3.4 Schedules Figure 17: Setting up recording modes You put the name of the schedule in box Schedule name. Under this name it will be available in other parts of the system. Than you set into Period day in week and hours in that the schedule will be active. The button Add Next can be used to add another period (25 periods is maximum).
  • Page 28: Device Authentication Settings

    (however this is not recommended for security reasons described in the chapter 3.1) can be set. Specify credentials – With this option IPCorder will use an already existing account for view access to the remote device. Generate new credentials – The system automatically replaces the respective account by a new one with...
  • Page 29: Device Removal

    (both about the authentication in general and particular passwords) set on the camera and on the IPCorder (e.g. if a password has been changed directly in the camera’s web interface). In this case, it is necessary to fill in the passwords set on the camera and tick this checkbox before applying the changes.
  • Page 30: Recording Management

    The live stream from devices is available in the menu Live View. The IPCorder viewing applet allows simultaneous viewing of multiple device outputs with no need for separate browser windows for each individual camera. The organization of the layouts of the outputs from multiple cameras on the Live View page (Figure 20) is defined by so-called Views (see bellow).
  • Page 31: Views

    Installation of additional plugins is required for viewing videos in the MPEG4 format. The IPCorder will automatically display a link for downloading the plugins in the lower part of the monitor window when attempting to play video in this format for the first time.
  • Page 32: Status Monitors

    4.1.2 Status Monitors Apart from the live stream from cameras, the IPCorder is also able to display a range of system variables as well as up-to-date values from sensors and cameras (for example frames per second index or temperature from...
  • Page 33 To serve this purpose the IPCorder interface allows the user to define so-called status monitors. All in all, these are lists of variables that are to be displayed. To add a monitor of this type, follow the same instructions as when adding a regular monitor with live camera stream.
  • Page 34: Recordings

    4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.2 Recordings 4.2 Recordings Figure 23: Adding a status monitor Figure 24: List of status monitors 4.2 Recordings The system stores the recorded outputs from devices onto the hard drive (either continually or when triggered by events, as defined in the respective settings of particular devices, see the chapters 3.3 Recording Modes...
  • Page 35 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.2 Recordings 4.2 Recordings and 4.3 Rules chapters). The menu Recordings (Figure 25) serves for browsing and viewing the recorded videos and data. Figure 25: Recordings In the calendar on the left side of the page, choose the period of time in which you want to search. You can either choose one day, a week (by clicking on the arrow on the left side of the dates) or a month (by clicking on its name).
  • Page 36 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.2 Recordings 4.2 Recordings Use the arrows in the label bar above the time axis to navigate in the recording history. Use the left-hand arrow for switching to the previous time period, the right-hand arrow for moving on to the next one and the up arrow to lengthen the displayed period (from an hour to a day, etc.).
  • Page 37: Video Export

    (see the chapter 2.6 FTP). For playing videos exported from the IPCorder on a different computer, the FDDShow codec or equivalent video filter is required. The easiest way for playing the videos is to use the VLC player, a software player that includes all the necessary codecs and filters.
  • Page 38 – motion detected). A rule can also be triggered by a user button in the live view section. In the case of a user button, choose the pair IPCorder and the event you have defined when creating the user button (for example UserEvent1).
  • Page 39 See the Recording Modes. The function argument sets how long, in seconds, the recorded video should be.) Send an e-mail – Displays a form for sending e-mail (addressee, subject, text of the e-mail). The IPCorder supports national character sets, i.e. it is possible to use the diacritic symbols.
  • Page 40: Rule Examples

    4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.3 Rules 4.3 Rules As in the previous case, it is necessary to input the name of the Rule, whether it is active or not and in what schedules it should operate. The Rule Text part then serves for the complete text of the rule, using the identification names of each device (see chapter 3.2), proper event names or variables.
  • Page 41 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.3 Rules 4.3 Rules Figure 30: Rule for turn camera to preset position Before creating such rule, check the settings of the camera in Management – Devices – Manage – Settings – Recording. To make this rule work properly, it is necessary to switch the camera to Recording on trigger mode or to Live view mode with active Monitor events selected.
  • Page 42: System Log

    The rule in Figure 35 sends a cgi command to a camera on motion detect event. 4.4 System Log For detailed log of IPCorder events, it is possible to open the System Log (a complete list of all actions carried out by the system) in the menu Configuration – System – System Log (Figure 36).
  • Page 43: Firmware Upgrade

    To be able to download actual firmware you have to create an account on http://updates.ipcorder.com. If you have more than one IPCorder, you can use one account for all your devices. After creating the account you can login in to Management – System – Firmware Upgrade (Figure 37).
  • Page 44 Figure 33: Reaction on digital impute by switching on digital output If your IPCorder has no access to Internet or you prefer not to use automatic actualization, you can update the firmware manually. Before the first update it is necessary to download the ”key”, which is unique for every IPCorder and update is generated for every key separately.
  • Page 45: Firmware Repair

    In some rare cases an issue related to firmware, the device key or with other upgradable part of the system (e.g. after disk upgrade the device key may change causing incompatibility) may appear. In such case IPCorder automatically reboots to rescue mode. In the rescue mode menu you will see a link to Firmware repair section.
  • Page 46: Factory Reset

    4.6 Factory Reset It is possible to reset IPCorder to its factory defaults in section Settings – System – Factory reset . This can be useful in situations when the device cannot be accessed by other means or when it is sold. The factory reset...
  • Page 47: Power Off/Restart And Led Signalisation

    Factory reset may also be started by pressing the IPCorder hardware button ( see section 4.7). In this case the device will enter the rescue mode as if it was the first time the device was connected to the network.
  • Page 48 It is also possible to use the hardware buttons. KNR-090 has Power a Reset buttons on its back side. Pushing the power button shortly will shut down the IPCorder application running on the device. Holding the power button for more than 5 seconds will power down the whole device including the hardware.
  • Page 49 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.7 Power off/Restart and LED signalisation 4.7 Power off/Restart and LED signalisation Figure 39: Welcome page of the upgrade server button until the device top LED begins to signal the Factory reset in progress by flashing red and blue. You may need to hold it for up to 3 minutes.
  • Page 50 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.7 Power off/Restart and LED signalisation 4.7 Power off/Restart and LED signalisation Figure 40: List of registered devices...
  • Page 51 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.7 Power off/Restart and LED signalisation 4.7 Power off/Restart and LED signalisation Figure 41: Registering a new device...
  • Page 52 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.7 Power off/Restart and LED signalisation 4.7 Power off/Restart and LED signalisation Figure 42: List of the available firmware versions...
  • Page 53 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.7 Power off/Restart and LED signalisation 4.7 Power off/Restart and LED signalisation Figure 43: Firmware upgrade page in rescue mode...
  • Page 54 4 RECORDING MANAGEMENT 4 RECORDING MANAGEMENT 4.7 Power off/Restart and LED signalisation 4.7 Power off/Restart and LED signalisation Figure 44: Page firmware repair in rescue mode Figure 45: Factory Reset page in rescue mode...
  • Page 55: Where To Seek Help

    5 WHERE TO SEEK HELP 5 WHERE TO SEEK HELP 5 Where to Seek Help Should you experience any issues with IPCorder, you can report them at http://issues.ipcorder.com (available in English only). We take all suggestions seriously, and consider all ideas for improvements in our future releases.
