- Page 1 Smart Glass Door Lock (SGDL) G1/GW1/M1/MW1 Installation User Manual...
- Page 2 The Biggest Leader Of Smart Glass Door Lock In China...
-
Page 3: Installation Notice
The Biggest Leader Of Smart Glass Door Lock In China Installation Notice SGDL is a high technology product, please read this Instruction carefully before installation, and also install this SGDL strictly according to this Instruction. ZKS don’t take any responsibility because of wrong installation. Installation Environment 1. - Page 4 The Biggest Leader Of Smart Glass Door Lock In China We suggest you to install the SGDL 1.3-1.5meters from the ground. Don’t install this SGDL on the glass door with frame. The SGDL have right hand and left hand, please select the right lock for your glass door. When you install this SGDL to the single door, please notice the depth of the hole should be deeper than 30mm, the diameter of the hole should be more than 12mm.
- Page 5 The Biggest Leader Of Smart Glass Door Lock In China SGDL Introduction Now let’s introduce this SGDL structure and its components （such as picture） main back plate side back plate vice shell Main Part Side Part Outside Door Mechanism battery cover PIC 1 Preparations 1.
- Page 6 The Biggest Leader Of Smart Glass Door Lock In China Installation Steps 1 (Double Door) 1． Fix the installation position for the SGDL (suggest 1.3m-1.5m distance from the ground). Paste main back plate board. Tear off the red plastic-sheet, then paste back plate board on the glass door inside, and make 2 L types aline with glass door side.
- Page 7 The Biggest Leader Of Smart Glass Door Lock In China Please make the SGDL main part to clamp the glass door along with door edge until the main part can aline glass door edge. 6. Install Side Part Please use the same method to install side back plate board, after installation, please tear off the red film on the side of the door, then use 3 PCS 3*6mm screws to fix, such as above picture, then use side back shell to join it, and use 2.5*8mm screws to fix.
- Page 8 The Biggest Leader Of Smart Glass Door Lock In China Installation Steps 2（Single Door） 1．Fix the main part position, then tear off the red film at the back of main back plate board, and paste it on the glass door to make 2 PCS L crosses paste on the glass door edge. 2.
- Page 9 The Biggest Leader Of Smart Glass Door Lock In China After fix it, please open the door, and draw the outside door mechanism shape on the door frame. Remove the orientation chart, and put the torn chart and red dotted line parts on the outside door mechanism shape, and fix the lock hole and screw holes position.
- Page 10 The Biggest Leader Of Smart Glass Door Lock In China this may cause the lock tongue not to stretch. 4. When make a hole on the door frame, you should measure the holes distance from door frame according to the lock distance from door frame and lock tongue length. 5.
- Page 11 The Biggest Leader Of Smart Glass Door Lock In China...
- Page 12 The Biggest Leader Of Smart Glass Door Lock In China Guangzhou Rhombus Electronic Ltd. Co., China Service Hotline: +86-13809774752 Email:godzhong@hotmail.com...
