Summary of Contents for SkyBell SB100NS
- Page 1 Installation Guide...
- Page 2 SkyBell Components Contents SkyBell Mounting Wedge Mount Doorbell Device Plate (Sold Separately) Special Locking Tool Wall Screws (2) Screw Anchors (2) Wire Connectors (4) (2 extra) Set Screw (Extra) Tools You May Need for Installation: • Pliers Crimpers • Outdoor Adhesive •...
-
Page 3: Pre-Installation Checklist
Welcome! PRE-INSTALLATION CHECKLIST Thank you for becoming a member of the SkyBell family. Please take a minute to carefully review these 1. Doorbell Chime - SkyBell is compatible with mechanical instructions so you can enjoy your SkyBell experience. and digital door chimes. Wireless door chimes are not supported. -
Page 4: Power Configurations
SSIDs for the 2.4 and 5 GHz bands. Prior to initiating the syncing process, make sure your mobile device is connected to Prior to installing your SkyBell, make sure your home is the 2.4GHz SSID. compatible with one of the power configurations listed. -
Page 5: Installation Instructions
* For wedge mount installation instructions, turn to page 13 Low-voltage transformer (10-36 VAC 10 VA); and 10 Ohm/10 Watt resistor inserted between one wire from the SkyBell and one wire from the power source Remove your traditional doorbell and carefully detach... - Page 6 If you do not use a door chime, you must use a 10 Ohm / 10 Watt With a pair of pliers, clamp down on the wire connector and resistor with one connection between SkyBell and the power crimp the wires together.
- Page 7 SkyBell into place. Be sure that the screw is not exposed beyond the bottom of the device. Your SkyBell is now properly installed. Before starting the syncing process, please give SkyBell 10 minutes to charge the battery.
- Page 8 Align the holes in the mounting plate with the holes in the wedge mount. Use the two wall screws included with your The wedge mount allows you SkyBell to secure the mounting plate and wedge mount to the to angle SkyBell in the direction of desired wall.
- Page 9 Secure the mounting plate and the door frame adapter to the door frame with the two screws included with your device. This accessory allows you to install your SkyBell onto a door frame. Follow the rest of the installation instructions on page 8. Note: your door frame should be For more support documentation, visit: 2.5 inches thick and a flat surface.
- Page 10 SYNCING PROCESS Download the app from the iTunes App Store® or the Google Play Store®. Search “SkyBell” and select our free app. This section will provide step-by-step instructions for syncing On the home screen of the app, tap “Register” and create an your SkyBell to your Wi-Fi router and smartphone.
- Page 11 From the home screen in the app, tap the link that says, “Add Tap “Cancel” in the app or click “OK” to the pop-up message. device” or “Add SkyBell”. Follow the screens that will guide you Restart the syncing process from the beginning and make sure through the syncing process.
- Page 12 Red (Single Blink) = Device is in syncing mode Red (Double Blink) = Device is charging Green (Solid) = Device has power, Wi-Fi and server connection (normal) Green (Blinking Slow) = Device has power and Wi-Fi but is not connecting to SkyBell’s server...
- Page 13 ELECTRICAL SHOCK HAZARD DO NOT ATTEMPT TO POWER YOUR SKYBELL WITH AN IMPROPER POWER Turn off power to the area where you will install the SkyBell at the circuit breaker or fuse CONFIGURATION. INFORMATION REGARDING ALL SUPPORTED POWER CONFIGURA- TIONS CAN BE FOUND AT WWW.SKYBELL.COM/SUPPORT (POWER CONFIGURATION box before beginning installation.
- Page 14 Full retail price shall be equal to the sale price on our website “AS AVAILABLE”. SBT DOES NOT REPRESENT, WARRANT, OR GUARANTEE THAT (www.skybell.com) not including sales, promotions or other discounts. PRODUCT INFORMATION WILL BE AVAILABLE, ACCURATE, OR RELIABLE.
- Page 15 OTHERWISE, SHALL BE LIMITED TO THE DIRECT DAMAGES RECOVERABLE UNDER LAW, BUT thermal or environmental conditions or a rapid change in such conditions, corrosion, NOT TO EXCEED THE PURCHASE PRICE FOR THE SKYBELL PRODUCT. YOU HEREBY oxidation, unauthorized modifications or connections, unauthorized opening or repair,...
- Page 16 Reseller Limitations This Warranty only applies to devices purchased from SkyBell or an Authorized Reseller. A list of Authorized Resellers can be found on www.skybell.com/legal. Devices purchased from unauthorized dealers and/or individuals reselling new or used devices, are not eligible to receive Warranty service or a refund of any kind.
- Page 17 W W W . S K Y B E L L . C O M USAv022015...
