5.2.3
OUTPUT Section
The MAIN OUT on the rear of the Z1
The Z1's
MAIN OUT
section on the rear panel is where you can connect your amplification sys-
tem. The output level is controlled by the
MAIN OUT
▪ Unbalanced RCA: The RCA output allows simple connectivity for an amplification system.
5.2.4
Kensington Lock Port
The Kensington lock port on the rear panel.
This metal-reinforced hole provides an additional security option whereby a bespoke cable and
lock can be applied.
MAIN
knob on the top panel.
TRAKTOR KONTROL Z1 Hardware Reference
TRAKTOR KONTROL Z1 - Manual - 22
Rear Panel
