INSTR4200 0304
Installation and
Operating Instructions
For CUNO
New Electronic ICE Ballast
This UV system contains a patented electronic ICE ballast. It is designed to provide constant UV output over a
wide range of input voltages or frequencies.
Warning: The light given off by this unit can cause serious burns to unprotected eyes and skin. Never look
directly at a burning UV lamp. When performing any work on the UV sterilizer always unplug the unit first.
Never operate the UV system while the UV lamp is outside of the UV chamber.
Note: The UV lamp inside of the sterilizer is rated at an effective life of approximately 9,000 hours. To ensure
continuous protection, replace the UV lamp annually.
Food Service CFSUV-5 and CFSUV-5-2
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cuno CFSUV-5
Summary of Contents for Cuno CFSUV-5
- Page 1 INSTR4200 0304 Installation and Operating Instructions For CUNO Food Service CFSUV-5 and CFSUV-5-2 ® New Electronic ICE Ballast This UV system contains a patented electronic ICE ballast. It is designed to provide constant UV output over a wide range of input voltages or frequencies.
-
Page 2: Read And Follow All Safety Instructions
If the water chemistry contains levels in excess of those mentioned above, proper treatment is recommended to correct these water problems prior to the installation of the UV system. Consult a CUNO Food Service Authorized Distributor for pretreatment recommendations. -
Page 3: Installing The Uv System
Installing the UV System CAUTION: • The UV system must be connected to a ground fault interruptor. • The electronic ballast should be mounted either above or beside the reactor chamber. This will prevent moisture caused by condensation from entering the ballast enclosure, a potential for ballast failure and electrical shock hazard. •... -
Page 4: Uv Lamp Replacement
UV Lamp Replacement 1. Disconnect the power. 2. There is no need to disconnect the UV system from the water supply or to drain the water from the reactor chamber, nor do you need to remove the reactor chamber from the UV system. Lamp replacement is a quick and simple procedure requiring only a slotted screwdriver to perform the job. -
Page 5: Specifications
Specifications Model Type CFSUV-5 CFSUV-5-2 Flow Rate 5 gpm (18.9 lpm) 5 gpm (18.9 lpm) Length 35" (88.9 cm) 35" (88.9 cm) Width 2.5" (6.4 cm) 2.5" (6.4 cm) Dimensions Height 2.5" (6.4 cm) 2.5" (6.4 cm) Diameter 2.5" (6.4 cm) 2.5"... -
Page 6: Troubleshooting Guide
Troubleshooting Guide CAUTION: When performing any work on the UV system, unplug the system first and never look directly at the burning UV lamp. Symptom Possible Causes Remedy Replace filter cartridge with appropriate The sediment prefiler 5 micron cartridge. Pressure Drop is clogged NOTE: Check source water supply as fluctuations may occur in source pressure... -
Page 7: Manufacturer's Warranty
Product that is actually defective, malfunctioning, or otherwise in violation of this Warranty. If CUNO, for any reason, cannot repair a Product covered hereby within two (2) weeks after receipt of the original pur- chaser-consumer's notification of a Warranty claim, then CUNO's responsibility shall be, at its option, either to replace the defective Product with a comparable new unit at no charge to the consumer or to refund the full purchase price. - Page 8 If the filter is used on more than one machine, please list below. Equipment Model Manufacturer Would you be interested in an autoship program for filter replacements? CUNO Incorporated 400 Research Parkway Meriden, CT 06450, USA Toll Free: 1-888-218-CUNO Worldwide: 203-237-5541 Fax: 203-238-8701 © 2004 CUNO Incorporated www.cunofoodservice.com • www.cuno.com...
