Summary of Contents for DIGIWEB Fritz!Box 7430
- Page 1 Quick Start Guide Fritz!Box 7430...
-
Page 2: Table Of Contents
Step 7: Wi-Fi Network Security Key / Password Page Step 8: Broadband Talk VoIP Phone Setup Page Internet Connection Status Page Manual Configuration Settings Page Troubleshooting Page Factory Reset Page User Manuals / Parental Controls Page Digiweb Contact Details Page... -
Page 3: Step 1: Unpack Contents
Fritz!Box 7430 Quick Start Guide Welcome to your Fritz!Box 7430 Quick Start Quide. We would like to thank you for choosing Digiweb Broadband. We really appreciate your custom. Step 1: Unpack Contents You will find the following items included in your new Broadband Pack. -
Page 4: Step 2: Connect The 12V 2A Dc Power Supply Unit (Psu)
Step 2: Connect the 12V 2A DC Power Supply Unit (PSU) • Connect the PSU (C) to the Fritz!Box (B) as per above diagram. • Connect the PSU (C) to the nearest power socket. -
Page 5: Step 3: Connect The Dsl Phone Cable
Fibre data socket as shown on left below. • Wait up to 5 mins for the Power/DSL light on your Fritz!Box to go steady green. The VoIP “Internet” light will only activate if you have opted for a Digiweb Broadband Talk VoIP package. • If the Power/DSL light on your Fritz!Box fails to go steady green, please check your cable connections are firmly connected and ensure that you are connected to the correct dedicated Fibre data socket. -
Page 6: Step 4: Enable Wi-Fi Connection
Step 4: Enable Wi-Fi Connection For Windows PC / Laptop: • Click the windows button typically placed in the bottom left hand corner of your desktop. • Choose “Control Panel” • Choose “Network and Internet” • Choose “Network and Sharing” or “Network and Sharing Centre” • Choose “Change adapter settings” • Right click “ Wireless Network Connection” • Select “Enable”. DO NOT select “Disable” if adapter is already enabled. Note: Your computer setup and screen may differ from the above. For Tablet / Smartphone: • Go to settings > Wi-Fi > Ensure switch is on per Android and Apple iOS screenshots above. -
Page 7: Step 5: Activate Wireless Connection
Step 5: Activate Wireless Connection • Ensure that the WLAN LED is ON steady green as per above. • If WLAN LED is off press WLAN button once - (do not hold down) to activate WLAN. For Windows PC / Laptop: • Right click on the “Wireless Network Connection” • Select “Connect / Disconnect” For Tablet / Smartphone: • No additional steps required at this point. -
Page 8: Step 6: Choose Your Wireless Network
Step 6: Choose your Wireless Network For Windows PC / Laptop: • On the base of your Fritz!Box modem you will find the network name for example “FRITZ!Box 7430 ON” • Select “FRITZ!Box 7430 ON” SSID from the list currently appearing on your screen from Step 5. • Select the “Connect automatically” option so that your computer remembers the Wi-Fi network and automatically connects every time you turn on your computer. • Click “Connect” For Tablet / Smartphone: • Select “FRITZ!Box 7430 ON” SSID... -
Page 9: Step 7: Wi-Fi Network Security Key / Password
“password” field on your device screen from Step 6. You can locate your unique “WLAN Network Key” on the sticker attached to the base of the Fritz!Box. • Click connect. All done. You should now be connected. Enjoy your Digiweb broadband. Please note: • The WLAN Network Key “12345678987654321234” shown in the example above is for illustration purposes only. -
Page 10: Step 8: Broadband Talk Voip Phone Setup
If you have opted for Digiweb’s Broadband Talk VoIP telephone service, please connect your telephone to the “FON 1” port on the back of the Fritz!Box to start using your VoIP telephone service. The VoIP Internet light circled above will be steady green when Digiweb Broadband Talk VoIP is active. For more details on VoIP visit: http://www.digiweb.ie/support/phone-setup/ If you have opted for Digiweb’s fixed line telephone service, please connect your telephone to the telephone socket as installed by the telecoms engineer... -
Page 11: Internet Connection Status
WLAN Network (SSID) FRITZ!Box 7430 ON WLAN Network Key (WPA2) 1234 5678 9876 5432 1234 FRITZ!Box password zigzag5481 Internet Connection Status • Open your Browser (Internet Explorer, Firefox, Chrome, etc) • Type 192.168.178.1 or http://fritz.box into the address bar of your selected browser • Enter the Fritz!Box password as shown on the sticker attached to the base of your Fritz!Box. The Fritz!Box password “zigzag5481” shown in the example above is for illustration purposes only. It is NOT your Wi-Fi password / key. -
Page 12: Manual Configuration Settings
Manual Configuration Settings Please note that the Fritz!Box is pre-configured with the correct Digiweb settings. You should not be required to change these settings. A factory reset of the Fritz!Box as per page 14 will return the preconfigured settings at any point. However if configuring an alternate 3rd party VDSL modem, the following settings are required: FIBRE VDSL SETTINGS: • Encapsulation = PPPoE LLC • ATM Settings = Detect automatically (recommended setting) • Username... -
Page 13: Troubleshooting
Flashing: Configuring / Configurable e.g. firmware update. DO NOT POWER OFF when this LED is flashing! Info Red: Configuration error – please power off and on the Fritz!Box. Contact Digiweb Technical Support if powering off and on does not fix this. -
Page 14: Factory Reset
Dial #991*15901590* and press the call button (lift receiver). o Hang up again after about 3 seconds. o Allow up to 5mins before the Fritz!Box can be accessed again. o This method will not back up your Fritz!Box phonebook and user specific configurations • If you are a Digiweb Broadband Talk VOIP customer, please contact Digiweb Technical Support to reactivate your VOIP phone settings. -
