Reverb knob to 10- Fig. 15. Reset. Scope to 50mV/div. Line out (J5) looks like Fig. 14 (different scale). Scope to 5V/div. Headphone outs look like Fig. 8. FOOTSWITCH TEST With a stereo cord, connect RF2 to footswitch jack on front panel. Engage Channel Switch and Lead 2 switch to the front panel.
Page 24
BACKLINE 100 INDENTED BILL OF MATERIALS 11/24/99-SW NOTE: Level 1 refers to main assembly/ combo parts. Level 2 refers to board level components. Main assembly numbers are in bold face, while commonly needed parts are italicized. PART# DESCRIPTION QTY REF. DESIG.
