Summary of Contents for Linksys MAX-STREAM EA7400
- Page 1 User Guide MAX-STREAM™ AC1750 MU-MIMO GIGABIT ROUTER Model # EA7400...
-
Page 2: Table Of Contents
Cannot access your router message ....................17 After setup ..............................18 The Internet appears to be unavailable ....................18 Linksys Smart Wi-Fi does not open in your web browser .............. 19 Specifications ......................20 Linksys EA7400 ............................20 Environmental ............................... 20... -
Page 3: Product Overview
Product Overview Top view Illuminated Linksys logo—The Linksys logo stays on steadily while connected to the Internet. It flashes or pulses slowly during startup, self-testing and firmware upgrades. It flashes quickly when indicating connection errors. -
Page 4: Back View
Back view — (1) Adjustable antennas For best performance, position the antennas vertically as shown in the drawing. (2) USB 3.0 port—Connect and share a USB drive or USB printer on your network or on the Internet. (3) Internet port—Connect an Ethernet cable to this yellow gigabit (10/100/1000) port, and to a broadband Internet cable/DSL or fiber modem. - Page 5 (8) Reset button—Press and hold for until the power LED starts flashing to reset the router to factory settings. You can also restore the factory settings using Linksys Smart Wi-Fi on the Internet or mobile app. (9) Power switch—Press | (on) to turn on the router.
-
Page 6: Setting Up: Basics
• forums) • Linksys Smart Wi-Fi help (connect to Linksys Smart Wi-Fi, then click Help at the top of the screen) Note—Licenses and notices for third party software used in this product may be viewed on http://support.linksys.com/en-us/license. Please contact http://support.linksys.com/en- us/gplcodecenter for questions or GPL source code requests. - Page 7 At the end of setup, follow the on-screen instructions to set up your Linksys Smart Wi-Fi account. Use Linksys Smart Wi-Fi to configure your router from any computer with an Internet connection.
- Page 8 2.4 GHz Network Name Network Password 5 GHz Network Name Network Password Router Password Guest Network Name Guest Network Password Linksys Smart Wi-Fi Username Linksys Smart Wi-Fi Password...
-
Page 9: How To Use Linksys Smart Wi-Fi
How to Use Linksys Smart Wi-Fi You can configure your router from anywhere in the world by using Linksys Smart Wi-Fi, but you can also configure your router directly from your home network. Linksys Smart Wi-Fi may be available for your mobile device, as well. -
Page 10: Network Map
Network Map Lets you display and manage all network devices connected to your router. You can view devices on your main network and your guest network, or display information about each device. Guest Access Lets you configure and monitor a network that guests can use without accessing all of your network resources. -
Page 11: Parental Controls
Parental Controls Lets you block web sites and set Internet access times. Media Prioritization Lets you set which devices and applications have top priority for your network traffic. -
Page 12: Speed Test
Speed Test Lets you test your network’s Internet connection speed. External Storage Lets you access an attached USB drive (not included) and set up file sharing, a media server, and FTP access. -
Page 13: Connectivity
Connectivity Lets you configure basic and advanced network settings. Troubleshooting Lets you diagnose problems with your router and check the status of the network. -
Page 14: Wireless
Wireless Lets you configure your router’s wireless network. You can change the security mode, password, MAC filtering, and connect devices using Wi-Fi Protected Setup™. Security Lets you configure your router’s wireless security. You can set up the firewall, VPN settings, and make custom settings for applications and games. -
Page 15: Troubleshooting
You can find more help from our award-winning customer support at Linksys.com/support/EA7400. Your router was not successfully set up If Linksys Smart Wi-Fi did not complete the setup, you can try the following: • Press and hold the Reset button on your router with a paperclip or pin until the LED starts blinking (about 10 seconds). -
Page 16: Your Internet Cable Is Not Plugged In Message
Your Internet cable is not plugged in message If you get a “Your Internet cable is not plugged in” message when trying to set up your router, follow these troubleshooting steps. Make sure that an Ethernet or Internet cable (or a cable like the one supplied with your router) •... -
Page 17: Cannot Access Your Router Message
The wireless network name of the Linksys EA7400 router, Damaged_Beez2.4 in this example, is shown selected. 3. If you are prompted to enter a network security key, type your password (security key) into the... -
Page 18: After Setup
The wireless network name of the Linksys EA7400 router, Damaged_Beez2.4 in this example, is shown selected. 3. Click the wireless network name of your Linksys EA7400 router (Damaged_Beez2.4 in the example). 4. Type your wireless network password (Security Key) into the Password field. Click OK. -
Page 19: Linksys Smart Wi-Fi Does Not Open In Your Web Browser
4. Wait until the power indicator stops blinking. Wait two minutes before trying to connect to the Internet from a computer. To reboot your router using Linksys Smart Wi-Fi, do the following: 1. Log in to Linksys Smart Wi-Fi. (See “How to connect to Linksys Smart Wi-Fi” on page 9.) Router Settings Troubleshooting 2. -
Page 20: Specifications
Specifications Linksys EA7400 Model Name Linksys Max-Stream AC 1750 MU-MIMO Gigabit Router Model Number EA7400 Switch Port Speed 10/100/1000 Mbps (Gigabit Ethernet) Radio Frequency 2.4 GHz and 5 GHz # of Antennas 3 detachable external adjustable antennas Ports Power, USB 2.0, USB 3.0, Internet, Ethernet (1-... - Page 21 BELKIN, LINKSYS and many product names and logos are trademarks of the Belkin group of companies. Third-party trademarks mentioned are the property of their respective owners. Licenses and notices for third party software used in this product may be viewed here: http://support.linksys.com/en-us/license.
