Summary of Contents for TaoTronics TT-CD05
-
Page 1: User Manual
TaoTronics Car DVR User Manual Model NO.: TT-CD05... -
Page 2: Table Of Contents
Table of Contents About Car DVR ..............5 Cautions ................5 Key Functions ................ 5 Loop Recording ................. 5 G-Sensor ..................... 5 Motion Detection ................6 Auto Power On/Off with Ignition ............. 6 Package Content ..............6 Product Diagram ..............7 DVR ....................... - Page 3 Camera Mode ................14 Camera Mode ................... 14 Camera Setting ................. 15 a. Camera resolution ..............15 b. Capture Mode ..............15 c. Sequence ................16 d. Image Quality ............... 16 e. Sharpness ................16 Color ..................16 g. Quick Preview ............... 17 h.
- Page 4 Thank you for choosing TaoTronics TT-CD05 Car DVR. Please read this manual carefully and keep it for future reference. If you need any assistance, please contact TaoTronics support by email at support@taotronics.com.
-
Page 5: About Car Dvr
About Car DVR TaoTronics Car DVR integrates video recording, picture taking and external storage into a multi-function high-resolution digital recorder with HDMI and media output. It is widely used for providing recorded footage for purposes of accident compensation / insurance, but can also be used to record driving for fun and leisure. -
Page 6: Motion Detection
DVR at home for anti-theft purpose when away or on-holiday. Auto Power On/Off with Ignition When connected with the car charger (provided), TaoTronics DVR will automatically power on with car ignition. After turning off the car, the DVR will also save current recording and turn off. -
Page 7: Product Diagram
USB Cable TF Card User manual Product Diagram 1. Camera 2. Screen 3. Power Button 4. Up Button 5. Menu Button 6. OK/Confirm Button 7. Mode Button 8. Down Button 9. TF Card Slot 10. HDMI Connector 11. Microphone... -
Page 8: Mounting Bracket
12. Speaker 13. Reset Button 14. GPS (GPS Module is optional) 15. AV-OUT 16. Mount 17. USB Mounting Bracket Release Tab Suction Cup Locking Lever Adjusting knob... -
Page 9: Control Functions
Control Functions POWER Press and hold to turn On / Off Press to enter menu. In recoding mode, press to activate MENU SOS file protection Switch between different modes, short press to take photo MODE when video recording Up/Previous/Zoom In Down/Next/Zoom out, short press to mute when video DOWN recording... -
Page 10: Power On/Off
Power On/Off Battery Powered - Press and hold the POWER button to turn the DVR On/Off; Auto Power On/Off with Ignition – If powered by the car charger, the DVR will automatically turn on when you start your car. When turning off your car, the DVR will automatically turn off after the preset delay time (change in setting) Note: when not connected to any power source and battery level is low,... -
Page 11: Video Mode Setting
3. Motion Detection 4. WDR 5. G-Sensor 6. Exposure 7. TF-Card 8. Date / Time Stamp 9. Charging 10. Sound Recording 11. Recording time 12. Resolution Note: Icons in the diagram will vary according to settings Video Mode Setting Press the MENU button inside video mode to enter video setting. If the DVR is recording, please press OK button first to pause recording and press MENU button to enter Video Mode Setting page. -
Page 12: Resolution
a. Resolution Press Up/Down Button in video mode to select resolution. Press OK button to enter the setting page and press Up/Down button to select resolution, and then press OK button to confirm. Press Menu or Mode button to exit the setting. This setting is to set video resolution, the higher the resolution, the better the video quality. -
Page 13: Power Off Delay
manually activated at the restart of the DVR. Keep this feature on during normal driving. f． Power Off Delay Press Up/Down Button in video mode to set power OFF delay. Press OK button to enter the setting page and Up/Down button to enable/disable this function, and then press OK button to confirm. -
Page 14: Collision Sensor Sensitivity Setting
Press OK button to enter the setting page and Up/Down button to enable/disable this function, and then press OK button to confirm. Press Menu or Mode button to exit the setting. Set the sensitivity of collision sensor: Off/Low/Medium/High accordingly. Camera Mode Camera Mode In video standby mode, press mode button to enter camera mode and press OK button to take camera shots. -
Page 15: Camera Setting
Camera Setting Press the MENU button inside camera mode to enter Camera Setting Function Description Set camera resolution： Image Size 3M/2MHD/VGA/1.3M/12M/10M/8M/5M Set capture mode：single shot / 2 sec timer / 5 sec Capture Mode timer / 10 sec timer Sequence Take 3 consecutive shots: enable / disable Quality Set picture quality: Fine / Normal / Economy... -
Page 16: Sequence
shot. If single shot is selected, the camera will take one photo every time OK button is pressed. If delayed shot is selected, the camera will wait for 2/5/10 seconds depending on setting before taking the shot. c． Sequence Press Up/Down Button in camera mode to set burst mode. Press OK button to enter the setting page and press Up/Down button to enable or disable the function and then press OK button to confirm. -
Page 17: Quick Preview
button to enter the setting page and press Up/Down button to enable/disable quick preview, and then press OK button to confirm. Press Menu or Mode button to exit the setting. This setting sets the preview time of picture taken. If it is turned off, the camera will return to camera mode instantly every time a photo is taken. -
Page 18: System Setting
System Setting In Camera / Video Mode, press the MENU button twice to go into System Settings Function Description Date / Time Set system date / time Show vehicle number plate on recorded Plate Number on Video videos Time Zone Setting Set your local time zone Automatically power off in standby mode: Auto Power Off... -
Page 19: Plate Number On Video
On Date/Time setting page, there are three rows as in date, time and date format. Set date first by pressing Up/Down button. Press OK after done and move the cursor to the next spot on the right. Adjust date and hour/minute/second from top to bottom. -
Page 20: Auto Power Off
confirm and exit setting. Press menu or mode button to exist system setting. When previewed on computer, plate number will be shown on the bottom right corner of the recorded video footage. Having a plate number on your video recording can help identify the source of recording. -
Page 21: Screen Saver
button to choose between 50Hz/60Hz, and then press OK button to confirm. Press Menu or Mode button to exit the page. 8. Screen Saver Press Up/Down button in system setting to choose Screen Saver. Press OK button to enter Screen Saver page and press Up/Down button to choose and then press OK button to confirm. -
Page 22: Version
In default setting, all user information set before will be cleared. When you encounter any problem with the DVR, you can try to fix it by restore back to default setting. 13. Version Press Up/Down button in system setting to choose Version setting. Press OK button to check Version No. - Page 23 Removal Pull up the locking lever and pull the release tab to detach the mount from windshield Unlock the mount from camera by pushing the mount in the direction of the arrow, as shown by the following diagram...
-
Page 24: Cable Layout
Cable Layout Please refer to the following diagram for DVR optimal installation position. 1. Position the DVR behind the rear-view mirror. Make sure it does not block your driving view. 2. Lay the cable as indicated by the following diagram 3. -
Page 25: Specifications
Power 5V/1.5A Warranty TaoTronics provides 12 months limited warranty for this product from the date of its original purchase. Warranty is only valid for purchase from TaoTronics or TaoTronics authorized dealers and retailers. If the product becomes defective, please contact TaoTronics by email at support@taotronics.com. - Page 26 NORTH AMERICA E-mail : support@taotronics.com(US) support.ca@taotronics.com(CA) Tel : 1-888-456-8468 (Monday-Friday: 9:00 – 17:00 PST) Address: 2228 Junction Ave, San Jose, CA 95131 EUROPE E-mail: support.uk@taotronics.com(UK) support.de@taotronics.com(DE) support.fr@taotronics.com(FR) support.es@taotronics.com(ES) support.it@taotronics.com(IT) EU Importer: ZBT International Trading GmbH, Lederstr 21a, 22525 Hamburg, Deutschland ASIA PACIFIC E-mail : support.jp@taotronics.com(JP)
