UM10237
LPC24XX User manual
Rev. 02 — 19 December 2008
Document information
Info
Content
Keywords
LPC2400, LPC2458, LPC2420, LPC2460, LPC2468, LPC2470, LPC2478,
ARM, ARM7, 32-bit, Single-chip, External memory interface, USB 2.0,
Device, Host, OTG, Ethernet, CAN, I2S, I2C, SPI, UART, PWM, IRC,
Microcontroller
Abstract
LPC24XX User manual release
User manual
Advertisement
Chapters
Table of Contents
Related Manuals for NXP Semiconductors LPC24XX UM10237
Summary of Contents for NXP Semiconductors LPC24XX UM10237
-
Page 1: Chapter 17: Lpc24Xx Universal Asynchronous Receiver/Transmitter (Uart)
UM10237 LPC24XX User manual Rev. 02 — 19 December 2008 Document information Info Content Keywords LPC2400, LPC2458, LPC2420, LPC2460, LPC2468, LPC2470, LPC2478, ARM, ARM7, 32-bit, Single-chip, External memory interface, USB 2.0, Device, Host, OTG, Ethernet, CAN, I2S, I2C, SPI, UART, PWM, IRC, Microcontroller Abstract LPC24XX User manual release... -
