CPU Cards

CEGA Series

PICMG 1.3 Single-Board Computers

Featuring VGA, SATA, RAID, Dual Gb

LAN & IrDA Modules

CEGA PD-32-X: 3.2GHz Pentium D CPU

CEGA PD-36-X: 3.6GHz Pentium D CPU

CEGA C2-24-X: 2.4GHz Core 2 Duo CPU

USER'S MANUAL

VER. 1.2C • SEP 2007

No part of this manual may be reproduced without permission

CyberResearch

, Inc.

www.cyberresearch.com

25 Business Park Dr., Branford, CT 06405 USA

203-483-8815 (9am to 5pm EST) FAX: 203-483-9024

Table of Contents

Need help?

Do you have a question about the CEGA PD-32-X and is the answer not in the manual?

Questions and answers

Summary of Contents for CyberResearch CEGA PD-32-X

Page 1 CEGA Series PICMG 1.3 Single-Board Computers Featuring VGA, SATA, RAID, Dual Gb LAN & IrDA Modules CEGA PD-32-X: 3.2GHz Pentium D CPU CEGA PD-36-X: 3.6GHz Pentium D CPU CEGA C2-24-X: 2.4GHz Core 2 Duo CPU USER’S MANUAL VER. 1.2C • SEP 2007 No part of this manual may be reproduced without permission ®...
Page 3 CyberResearch, Inc. In no event will CyberResearch, Inc. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of or inability to use the product or documentation, even if advised of the possibility of such damages.
Page 4: Revision History
® CEGA Series CyberResearch CPU Cards Revision History Title CyRAQ 06SB Series Revision # Description Date of Issue Initial Release May 10 2007 Revision – update USB 1.2C September 7 2007 Functionality/Connectivity ©Copyright 2007 CyberResearch, Inc.
Page 5: Packing List
Packing List If any of the components listed in the checklist below are missing, please do not proceed with the installation. Contact CyberResearch, Inc. technical support. Call 203-483-8815 and ask for technical support, fax 203-483-9024 attn: tech support, or e-mail techsupport@cyberresearch.com.
Page 6: Table Of Contents
® 2.6.2 Intel ICH7R Audio Codec ’97 Controller ............20 ® 2.6.3 Intel ICH7R IDE Interface................20 ® 2.6.4 Intel ICH7R Low Pin Count (LPC) Interface ..........22 ® 2.6.5 Intel ICH7R PCI Interface ................22 ©Copyright 2007 CyberResearch, Inc...
Page 7 ..............35 ERIPHERAL NTERFACE ONNECTORS 4.1.1 CEGA Layout ....................35 4.1.2 Peripheral Interface Connectors ..............35 4.1.3 External Peripheral Interface Panel Connectors ..........36 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 8 5.3.2 DIMM Installation ................... 67 5.4 J ....................68 UMPER ETTINGS 5.4.1 Clear CMOS Jumper ..................69 5.5 C .................... 70 HASSIS NSTALLATION 5.5.1 Airflow......................70 5.5.2 Backplane Installation ..................71 5.5.3 CPU Card Installation ..................71 ©Copyright 2007 CyberResearch, Inc viii...
Page 9 6.3.7 APM Configuration..................103 6.3.8 Remote Access Configuration ................ 105 6.3.9 USB Configuration..................106 6.3.9.1 USB Mass Storage Device Configuration..........108 6.4 PCI/P P........................110 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 10 WATCHDOG TIMER ..................172 ADDRESS MAPPING..................175 C.1 IO A ....................176 DDRESS C.2 1 MB M ................176 EMORY DDRESS C.3 IRQ M .................... 177 APPING ABLE C.4 DMA C ................177 HANNEL SSIGNMENTS DIO INTERFACE....................179 ©Copyright 2007 CyberResearch, Inc...
Page 11 F.4.2 Deleting a RAID Volume ................196 F.4.3 Resetting a Disk to Non-RAID ............... 199 F.4.4 Exiting the Matrix Storage Manager ............. 201 INDEX..........................203 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 12 Figure 5-1: Intel LGA775 ......................64 Figure 5-2: Remove the CPU Socket Protective Shield............64 Figure 5-3: Open the CPU Socket Load Plate................65 Figure 5-4: Insert the LGA775 CPU....................66 Figure 5-5: Installing a DIMM......................67 Figure 5-6: Jumper ........................68 ©Copyright 2007 CyberResearch, Inc...
Page 13 Figure 7-20: Search for Suitable Driver...................145 Figure 7-21: Locate Driver Files....................145 Figure 7-22: Location Browsing Window................146 Figure 7-23: Select the Audio CODEC..................147 Figure 7-24: Locate the Setup Program Icon................148 CyberResearch, Inc. xiii 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 14 Figure 7-41: Double Click the System Icon................162 Figure 7-42: Double Click the Device Manager Tab...............163 Figure 7-43: Device Manager List ....................164 Figure 7-44: Search for Suitable Driver...................165 Figure 7-45: Locate Driver Files....................165 Figure 7-46: Location Browsing Window................166 ©Copyright 2007 CyberResearch, Inc...
Page 15 Table 4-20: USB Connector Pinouts..................57 Table 4-21: VGA Connector Pinouts..................58 Table 5-1: Jumpers........................68 Table 5-2: Clear CMOS Jumper Settings...................69 Table 5-3: Cables Provided with CEGA..................72 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 17 BIOS Menu 20: Security ......................121 BIOS Menu 21: Chipset ......................122 BIOS Menu 22:NorthBridge Chipset Configuration ...............123 BIOS Menu 23: SouthBridge Chipset Configuration .............125 BIOS Menu 24:Exit........................127 CyberResearch, Inc. xvii 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 18 Flexible File Input/Output FIFO First In/First Out Front Side Bus IrDA Infrared Data Association Hard Disk Drive Integrated Data Electronics Input/Output ICH7R I/O Controller Hub 7 L1 Cache Level 1 Cache L2 Cache Level 2 Cache ©Copyright 2007 CyberResearch, Inc xviii...
Page 19 Serial Presence Detect S/PDI Sony/Philips Digital Interface SDRAM Synchronous Dynamic Random Access Memory Serial Infrared UART Universal Asynchronous Receiver-transmitter Universal Serial Bus Video Graphics Adapter CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 21: Introduction
® CyberResearch CEGA Series CPU Cards Chapter Introduction CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 22: Cega Overview
1 via external connector (backplate) Up to four additional via PCI Express x 16 signaling (with compatible backplanes) Support PCIe x 16 Graphic Card, Four PCIe x 1 and four PCI expansion Optional 5.1 and 7.1 channel audio kits supported ©Copyright 2007 CyberResearch, Inc...
Page 23: Cega Overview
A labeled photo of the peripheral connectors is shown in Figure 1-1. Figure 1-1: CEGA Overview CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 24: Cega Peripheral Connectors And Jumpers
The CEGA has the following external peripheral interface connectors on the board rear panel: 1 x PS/2 keyboard/mouse connector 2 x Ethernet connectors 1 x USB 2.0 connector 1 x VGA connector The CEGA has the following on-board jumper: Clear CMOS ©Copyright 2007 CyberResearch, Inc...
Page 25: Technical Specifications
FSB (CPU Front Side Bus Speed) 800MHz 1066MHz Chipset Manufacturer Intel Chipset Intel 945G / ICH7 Memory Memory Maximum System Memory 4 x 240-pin DDR2 Memory Sockets DIMMs CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 26 2 x Gigabit Channels (10/100/1000Base-T) On-Board LAN Gigabit LAN Ethernet Filter Config Ethernet Dual LAN Dual Gigabit LAN 2 x RJ-45 Connector(s) 2 LEDs indicate LAN access and link status Wake-on-LAN Serial Ports UART/Controller Type 16550-compatible ©Copyright 2007 CyberResearch, Inc...
Page 27 ECP (Extended Capability Port, bidirectional) EPP (Enhanced Parallel Parallel Ports Parallel Port Modes Supported Port, bidirectional) SPP (Standard Parallel Port) Connector Type 26-pin male header on CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 28 IrDA Types Supported ASKIR (amplitude shift IrDA (infrared) keyed infrared) Port Header for IrDA (infrared) IrDA Connector port Number of I/O Lines 4 inputs Configuration Digital I/O 4 outputs DIO lines via 10-pin Features 2.0mm header on card ©Copyright 2007 CyberResearch, Inc...
Page 29 930mA LGA775-based card requires an ATX12V-rated Power Supply Notes power supply to ensure sufficient +12V power Cooling Fan for Processor (CPU Fan) 1 included CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 30 CPU Cards Environmental Specifications Operating Temperature 32°F..140°F (0°C..60°C) Relative Humidity, noncondensing 5%..95% Dimensions CPU Card Length 13.32" (338.44mm) CPU Card Height 4.97" (126.21mm) Card Thickness (w/o CPU or RAM) 1.56" (39.73mm) Weight Weight 1.16lbs (526.17g ) ©Copyright 2007 CyberResearch, Inc...
Page 31: Detailed Specifications
® CyberResearch CEGA Series CPU Cards Chapter Detailed Specifications CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 32: Overview
This chapter describes the specifications and on-board features of the CEGA in detail. 2.2 Dimensions 2.2.1 Board Dimensions The dimensions of the board are listed below and shown in Figure 2-1. Length: 338.58mm Width: 126.39mm Figure 2-1: CEGA Dimensions (mm) ©Copyright 2007 CyberResearch, Inc...
Page 33: External Interface Panel Dimensions
CPU Cards 2.2.2 External Interface Panel Dimensions External peripheral interface connector panel dimensions are shown in Figure 2-2. Figure 2-2: External Interface Panel Dimensions (mm) CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 34: Data Flow
2.3 Data Flow Figure 2-3 shows the data flow between the two on-board chipsets and other components installed on the backplane and described in the following sections of this chapter. Figure 2-3: Data Flow Block Diagram ©Copyright 2007 CyberResearch, Inc...
Page 35: Compatible Processors
90 nm 1 MB LGA 775 570J 3.80 GHz 800 MHz 90 nm 1 MB LGA 775 Table 2-2: Supported Intel® Pentium® 4 Processors CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 36: Supported Intel® Pentium® D Processors
DMI integrates priority based servicing that allows for concurrent traffic and ® true isochronous transfer capabilities. Some of the features of the Intel 945G are listed below. Support 533/800/1066MHz FSB Supports four, 1GB, 400/533/667MHz dual channel DDR SDRAM DIMMs ©Copyright 2007 CyberResearch, Inc...
Page 37: Intel 945G Memory Support
Flat panels up to 2048x1536 @ 60 Hz or digital CRT/HDTV at 1920x1080 @ 85Hz Dual independent display options with digital display Multiplexed digital display channels (Supported with ADD2 Card). CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 38: Intel ® 945G Integrated Graphics Media Accelerator 950
Two Serial Digital Video Out (SDVO) ports for flat-panel monitors via ADD2 cards Multiple display types (LVDS, DVI-I, DVI-D, CRT) Dual screen support via ADD2 digital video devices HDTV 720p and 1080i display resolution support Interlaced Display output support High Quality Media Support ©Copyright 2007 CyberResearch, Inc...
Page 39: Intel ® Ich7R Southbridge Chipset
Serial Peripheral Interface (SPI) for Serial and Shared Flash 1.05 V Core Voltage Intel® High Definition Audio Interface Intel® Active Management Technology Intel® Quick Resume Technology Support CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 40: Intel ® Ich7R Audio Codec '97 Controller
0 – 4 0 – 4 PIO Max Transfer Rate 16.6 MB/s 16.6 MB/s 16.6 MB/s DMA/UDMA designation UDMA 3 - 4 UDMA 3 – 4 UDMA 2 DMA/UDMA Max Transfer 100MB/s 66MB/s 33MB/s Controller Interface ©Copyright 2007 CyberResearch, Inc...
Page 41: Table 2-5: Supported Hdd Specifications
® CyberResearch CEGA Series CPU Cards Specification Ultra ATA/100 Ultra ATA/66 Ultra ATA/33 Table 2-5: Supported HDD Specifications CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 42: Intel ® Ich7R Low Pin Count (Lpc) Interface
PCI slot connector on the bottom of the CPU card Broadcom PCI Express GbE interface Winbond PCI-to-ISA bridge interface The remaining four PCI bus masters are reserved for four PCI expansion boards that can be installed on the backplane. ©Copyright 2007 CyberResearch, Inc...
Page 43: Ich7R Real Time Clock
PCI Express slot connector on the bottom of the CPU card Broadcom PCI Express GbE interface Winbond PCI-to-ISA bridge interface 2.7.2 PCI Express (PCIe) Slot Connector CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 44: Broadcom Pcie Gbe Interface
Automatic MDI crossover function PCIe v1.0a 10/100/1000BASE-T full/half-duplex MAC Wake on LAN support meeting the ACPI requirements Statistics for SNMP MIB II, Ethernet-like MIB, and Ethernet MIB (802.3z, clause 30) Serial EEPROM or serial flash support JTAG support ©Copyright 2007 CyberResearch, Inc...
Page 45: Lpc Bus Components
The Winbond W83627THG Super I/O chipset is connected to the ICH7R southbridge through the LPC bus. Some of the features of the Winbond W83627THG chipset are listed below. LPC Interface PC98/2001, ACPI and LANDesk Compliant CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 46: Super I/O Lpc Interface
The Super I/O fan speed controller enables the system to monitor the speed of the fan. One of the pins on the fan connector is reserved for fan speed detection and interfaced to the fan speed controller on the Super I/O. The fan speed is then reported in the BIOS. ©Copyright 2007 CyberResearch, Inc...
Page 47: Super I/O Floppy Disk Controller
Supports mouse double-click and/or mouse move power on events 2.9 Environmental and Power Specifications 2.9.1 System Monitoring Three thermal inputs on the CEGA Super I/O Hardware Monitor the following temperatures: CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 48: Operating Temperature And Temperature Control
CPU. Heat sinks are also mounted on the northbridge and southbridge chipsets to ensure the operating temperature of these chips remain low. ©Copyright 2007 CyberResearch, Inc...
Page 49: Power Consumption
Pentium D processor with a 1066MHz FSB and 4GB of 667MHz DDR2 memory. Voltage Current +3.3V 6.3A 2.6A 5VSB 0.93A -12V 0.1A +12V Table 2-6: Power Consumption CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 51: Anti-Static Precautions
Make sure all the components shown in Section 3.3 are present. 3.3 Unpacking Checklist NOTE: If any of the components listed in the checklist below are missing, please proceed with installation. Contact CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 52: Package Contents
® CEGA Series CyberResearch CPU Cards CYBERRESEARCH, INC. technical support. Call 203-483-8815 and ask for technical support, fax 203-483-9024 attn: tech support, or e-mail techsupport@cyberresearch.com. 3.3.1 Package Contents The CEGA is shipped with the following components: Quantity Item and Part Number...
Page 53: Table 3-1: Package List Contents
® CyberResearch CEGA Series CPU Cards Quantity Item and Part Number Image FDD cable LPT cable Utility CD Table 3-1: Package List Contents CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 55: Peripheral Interface Connectors
Floppy disk drive connector 34-pin box header FDD1 Front panel connector 12-pin header IDE Interface connector 40-pin box header IDE1 Infrared connector 5-pin header CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 56: External Peripheral Interface Panel Connectors
4.2 Internal Peripheral Connectors Internal peripheral connectors are found on the backplane and are only accessible when the backplane is outside of the chassis. This section has complete descriptions of all the internal, peripheral connectors on the CEGA. ©Copyright 2007 CyberResearch, Inc...
Page 57: Atx Power Supply Connector
The 4-pin +12V ATX power supply connector is connected to a +12V ATX power supply. Figure 4-2: +12V ATX Power Connector Location DESCRIPTION +12V +12V Table 4-3: +12V ATX Power Connector Pinouts CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 58: Audio Connector (10-Pin)
The 10-pin audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system. Figure 4-3: Audio Connector Location (10-pin) DESCRIPTION DESCRIPTION AC_SYNC AC_CLK AC_SDOUT PC_BEEP AC_SDIN AC_RST# PWR (+5V) PWR (+12V) ©Copyright 2007 CyberResearch, Inc...
Page 59: Digital Input/Output (Dio) Connector
Figure 4-4: DIO Connector Locations DESCRIPTION DESCRIPTION PWR (+5V) XOUT0 XOUT1 XOUT3 XOUT4 XIN0 XIN1 XIN2 XIN3 Table 4-5: DIO Connector Pinouts CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 60: Fan Connectors
The connector has a "rotation" pin to get rotation signals from the fan and notify the system so the system BIOS can recognize the fan speed. Please note that only certain fans can issue the rotation signals. FAN1 CPU_FAN Figure 4-5: Fan Connectors Locations ©Copyright 2007 CyberResearch, Inc...
Page 61: Floppy Disk Connector (34-Pin)
See Figure 4-6 CN Pinouts: See Table 4-7 The floppy disk connector is connected to a floppy disk drive. Figure 4-6: 34-pin FDD Connector Location CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 62: Table 4-7: 34-Pin Fdd Connector Pinouts
INDEX# MOTOR ENABLE A# DRIVE SELECT B# DRIVE SELECT A# MOTOR ENABLE B# DIRECTION# STEP# WRITE DATA# WRITE GATE# TRACK 0# WRITE PROTECT# READ DATA# SIDE 1 SELECT# DISK CHANGE# Table 4-7: 34-pin FDD Connector Pinouts ©Copyright 2007 CyberResearch, Inc...
Page 63: Front Panel Connector (12-Pin)
PWR ON+ PWR ON- PWR (+5V) HDD LED+ Reset+ HDD LED- Reset- Table 4-8: Front Panel Connector Pinouts 4.2.7 IDE Connector (40-pin) CN Label: IDE1 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 64: Figure 4-8: Ide Device Connector Locations
DESCRIPTION DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 ©Copyright 2007 CyberResearch, Inc...
Page 65: Infrared Interface Connector (5-Pin)
See Figure 4-9 CN Pinouts: See Table 4-10 The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift Key Infrared (ASKIR) interfaces. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 66: Keyboard Connector
5-pin header (1x5) CN Location: See Figure 4-10 CN Pinouts: See Table 4-11 The keyboard connector can be connected to a standard PS/2 cable or PS/2 cable to add keyboard and mouse functionality to the system. ©Copyright 2007 CyberResearch, Inc...
Page 67: Parallel Port Connector
See Table 4-11 The 26-pin parallel port connector connects to a parallel port connector interface or some other parallel port device such as a printer. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 68: Figure 4-11: Parallel Port Connector Location
DESCRIPTION STROBE# DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 ACKNOWLEDGE BUSY PAPER EMPTY PRINTER SELECT AUTO FORM FEED # ERROR# INITIALIZE PRINTER SELECT LN# GROUND GROUND GROUND ©Copyright 2007 CyberResearch, Inc...
Page 69: Sata Drive Connectors
The SATA drive connectors are connected to SATA 3Gb/s disk drives that transfer data at speeds as high as 3.0Gb/s. The SATA drives can be configured in a RAID configuration. Figure 4-12: SATA Drive Connector Locations DESCRIPTION CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 71: Serial Port Connector (Com1 And Com2)
RS-232 serial port devices. COM2 COM1 Figure 4-13: Serial Port Connector Pinout Locations DESCRIPTION DESCRIPTION DCD- DSR- RTS- SOUT CTS- DTR- Table 4-14: Serial Port Connector Pinouts CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 72: Usb Connectors (Internal)
One additional external USB port is found on the backplate. The CEGA Series supports up to four more (7 total) via PCI Express x 16 signaling and a compatible backplane. See our website or call our sales engineers for more detail. Figure 4-14: USB Connector Pinout Locations ©Copyright 2007 CyberResearch, Inc...
Page 73: External Peripheral Interface Connectors
4.3.1 Keyboard/Mouse Connector CN Label: KB/MS CN Type: PS/2 CN Location: See Figure 4-15 (labeled 1) CN Pinouts: See Figure 4-16, Table 4-16 and Table 4-17 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 74: Figure 4-16: Ps/2 Pinout And Configuration
The CEGA keyboard and mouse connector is a standard PS/2 connector. Figure 4-16: PS/2 Pinout and Configuration DESCRIPTION KB DATA KB CLOCK Table 4-16: Keyboard Connector Pinouts DESCRIPTION MS DATA MS CLOCK Table 4-17: Mouse Connector Pinouts ©Copyright 2007 CyberResearch, Inc...
Page 75: Ethernet Connector
MDX2- MDX0- MDX1- MDX1+ MDX3+ MDX2+ MDX3- TX+ (or MDX0+) N/C (or MDX2-) TX- (or MDX0-) RX- (or MDX1-) Table 4-18: Ethernet Connector Pinouts CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 76: Usb Connector
4.3.3 USB Connector CN Label: USB_C0 CN Type: USB port CN Location: See Figure 4-15 (labeled 4) CN Pinouts: See Table 4-20 USB devices connect directly to the USB connector on the external peripheral connector panel. ©Copyright 2007 CyberResearch, Inc...
Page 77: Vga Connector
See Figure 4-18 and Table 4-21 The standard HD-D-sub 15 female connector connects to a CRT or LCD monitor. Figure 4-18: VGA Connector Description Description GREEN BLUE CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 78: On-Board Jumpers
® CEGA Series CyberResearch CPU Cards DDC DAT HSYNC VSYNC DDC CLK Table 4-21: VGA Connector Pinouts 4.4 On-board Jumpers The CEGA has fifteen on-board jumpers. Refer to Section 5.4 for jumper configuration settings. ©Copyright 2007 CyberResearch, Inc...
Page 79: Installation
® CyberResearch CEGA Series CPU Cards Chapter Installation CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 80: Anti-Static Precautions
Use an anti-static pad: When configuring the CEGA, place it on an antic-static pad. This reduces the possibility of ESD damage. Only handle the edges of the PCB: When handling the PCB, hold it by its edges. ©Copyright 2007 CyberResearch, Inc...
Page 81: Installation Considerations
Remove any of the stickers on the PCB board. These stickers are required for warranty validation. Use the product before verifying all the cables and power connectors are CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 82: Installation Checklist
System front panel connector Audio kit Power supply USB cable Serial port cable Parallel port cable Keyboard/mouse cable COM port cables The following external peripheral devices are properly connected to the chassis: VGA screen Keyboard Mouse USB device ©Copyright 2007 CyberResearch, Inc...
Page 83: Cpu, Cpu Cooling Kit And Dimm Installation
CPU please be careful not to damage it in anyway. Make sure the CPU is installed properly and ensure the correct cooling kit is properly installed. The LGA775 is shown in Figure 5-1. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 84: Figure 5-1: Intel Lga775
Open the socket. Disengage the load lever by pressing the lever down and slightly outward to clear the retention tab. Rotate the load lever to a fully open position. Then rotate the load plate towards the opposite direction. See Figure 5-3. ©Copyright 2007 CyberResearch, Inc...
Page 85: Figure 5-3: Open The Cpu Socket Load Plate
Insert the CPU. Gently insert the CPU into the socket. If the CPU pins are properly aligned, the CPU should slide into the CPU socket smoothly. See Figure 5-4. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 86: Figure 5-4: Insert The Lga775 Cpu
Secure the load lever under the retention tab on the side of CPU socket. Step 10: Connect the CPU 12V cable to the 12After the cooling kit is installed connect the CPU cable to the CPU 12V power connectorStep 0: ©Copyright 2007 CyberResearch, Inc...
Page 87: Dimm Installation
DIMM aligns with the bridge in the socket. See Figure 5-5. Step 3: Insert the DIMM. Once properly aligned, the DIMM can be inserted into the CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 88: Jumper Settings
Before the CEGA is installed in the system, the jumpers must be set in accordance with the desired configuration. The jumpers on the CEGA are listed in Table 5-1. Description Label Type Clear CMOS 3-pin header Table 5-1: Jumpers ©Copyright 2007 CyberResearch, Inc...
Page 89: Clear Cmos Jumper
Short 2 – 3 Clear CMOS Setup Table 5-2: Clear CMOS Jumper Settings The location of the clear CMOS jumper is shown in Figure 5-7 below. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 90: Chassis Installation
NOTE CYBERRESEARCH, INC. has a wide range of chassis available. Please contact a CYBERRESEARCH, INC. applications engineer by calling 203-483-8815, Faxing 203-483-9024 attn: sales, or e-mailing sales@cyberresearch.com...
Page 91: Backplane Installation
Please refer to the installation instructions that came with the backplane and the chassis. NOTE: CYBERRESEARCH, INC. has a wide range of backplanes available. Please contact a CYBERRESEARCH, INC. applications engineer by calling 203-483-8815, Faxing 203-483-9024 attn: sales, or e-mailing sales@cyberresearch.com...
Page 92: Ata Flat Cable Connection
Connect the cable to an IDE device. Connect the two connectors on the other side of the cable to one or two IDE devices. Make sure that pin 1 on the cable corresponds to pin 1 on the connectorStep 0: ©Copyright 2007 CyberResearch, Inc...
Page 93: Keyboard/Mouse Y-Cable Connector
Once the cable connector is properly aligned with the keyboard/mouse connector on the CEGA, connect the cable connector to the onboard connectors. See Figure 5-9. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 94: Single Rs-232 Cable Connection
Step 2: Insert the cable connector. Insert the connector into the serial port box header. See Figure 5-10. A key on the front of the cable connector ensures the connector can only be installed in one direction. ©Copyright 2007 CyberResearch, Inc...
Page 95: Sata Drive Connection
Insert the cable connector. Press the clip on the connector at the end of the SATA cable and insert the cable connector into the onboard SATA drive connector. See Figure 5-11. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 96: Figure 5-11: Sata Drive Cable Connection
SATA drive. See Figure 5-12. Step 4: Connect the SATA power cable. Connect the SATA power connector to the back of the SATA drive. See Figure 5-12. Step 0: ©Copyright 2007 CyberResearch, Inc...
Page 97: Usb Cable Connectors
Insert the cable connectors. Once the cable connectors are properly aligned with the USB connectors on the CEGA, connect the cable connectors to the CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 98: External Peripheral Interface Connection
0: 5.7 External Peripheral Interface Connection The following external peripheral devices can be connected to the external peripheral interface connectors. Mouse and keyboard RJ-45 Ethernet cable connectors USB devices VGA monitors ©Copyright 2007 CyberResearch, Inc...
Page 99: Ps/2 Y Cable Connection
Once the connectors are properly aligned, insert the PS/2 Y cable connector into the PS/2 cable connector on the CEGA. See Figure 5-14.Step 0: CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 100: Ethernet Connection
CyberResearch CPU Cards Figure 5-14: PS/2 Connector 5.7.2 RJ-45 Ethernet Connection The CEGA RJ-45 Ethernet connector on the external peripheral interface panel is connected to a LAN cable RJ-45 connector (Figure 5-15). Figure 5-15: RJ-45 Connector ©Copyright 2007 CyberResearch, Inc...
Page 101: Usb Connection
DB-15 connector on the external peripheral interface. Step 3: Insert the VGA connector. Once the connectors are properly aligned, insert the CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 102: Figure 5-17: Vga Connector
Figure 5-17: VGA Connector Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA monitor to the external interface by tightening the two retention screws on either side of the connector. Step 0: ©Copyright 2007 CyberResearch, Inc...
Page 103: Ami Bios
® CyberResearch CEGA Series CPU Cards Chapter AMI BIOS CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 104: Introduction
Exit current page and return to Main Menu Page Up key Increase the numeric value or make changes Page Dn key Decrease the numeric value or make changes F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu ©Copyright 2007 CyberResearch, Inc...
Page 105: Getting Help
Selects exit options and loads default settings The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 106: Main
System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. ©Copyright 2007 CyberResearch, Inc...
Page 107: Advanced
Hardware Health Configuration (see Section 6.3.5) ACPI Configuration (see Section 6.3.6) AMP Configuration (see Section 6.3.7) Remote Access Configuration (see Section 6.3.8) USB Configuration (see Section 6.3.9) CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 108: Cpu Configuration
Ratio Actual Value: Displays the ratio at which the CPU is actually operating 6.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system. ©Copyright 2007 CyberResearch, Inc...
Page 109 Legacy IDE Channels [PATA Pri, SATA Sec] Use the Legacy IDE Channels option to determine how SATA channels and PATA channels are ordered. SATA Only Enables SATA channels only. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 110: Ide Master, Ide Slave
BIOS configuration options are selected, the IDE configuration options shown in Section 6.3.2.1 appear. 6.3.2.1 IDE Master, IDE Slave Use the IDE Master and IDE Slave configuration menu to view both primary and secondary IDE device details and configure the IDE devices connected to the system. ©Copyright 2007 CyberResearch, Inc...
Page 111 The CD/DVD option specifies that an IDE CD-ROM drive is attached to the specified IDE channel. The BIOS does not attempt to search for other types of CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 112 Auto BIOS auto detects Multi-Sector Transfer support on the EFAULT drive on the specified channel. If supported the data transfer to and from the device occurs multiple sectors at a time. ©Copyright 2007 CyberResearch, Inc...
Page 113 Single Word DMA mode 1 selected with a maximum data transfer rate of 4.2MBps SWDMA2 Single Word DMA mode 2 selected with a maximum data CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 114 Use the S.M.A.R.T option to auto-detect, disable or enable Self-Monitoring Analysis and Reporting Technology (SMART) on the drive on the specified channel. S.M.A.R.T predicts impending drive failures. The S.M.A.R.T BIOS option enables or disables this function. ©Copyright 2007 CyberResearch, Inc...
Page 115: Floppy Configuration
BIOS Menu 6: IDE Master and IDE Slave Configuration Floppy A/B Use the Floppy A/B option to configure the floppy disk drive. Options are listed below: CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 117: Super Io Configuration
Serial Port 1 I/O port address is 3F8 and the interrupt EFAULT address is IRQ4 3E8/IRQ4 Serial Port 1 I/O port address is 3E8 and the interrupt address is IRQ4 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 118 Disabled No base address is assigned to the Parallel Port EFAULT Parallel Port I/O port address is 378 Parallel Port I/O port address is 278 Parallel Port I/O port address is 3BC Parallel Port Mode [Normal] ©Copyright 2007 CyberResearch, Inc...
Page 119: Hardware Health Configuration
IRQ7 is assigned as the parallel port interrupt address EFAULT 6.3.5 Hardware Health Configuration The Hardware Health Configuration menu (BIOS Menu 8) shows the operating temperature, fan speeds and system voltages. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 120 CPU Fan Target Temperature [Disabled] Use the CPU Fan Target Temperature to specify a CPU operating temperature threshold that, when reached, generates a warning signal. Configuration options are listed below. Disabled EFAULT 40°C/104°F 50°C/122°F 60°C/140°F 70°C/158°F ©Copyright 2007 CyberResearch, Inc...
Page 121: Acpi Configuration
The ACPI Configuration menu (BIOS Menu 9) configures the Advanced Configuration and Power Interface (ACPI) and Power Management (APM) options. BIOS Menu 9: ACPI Configuration ACPI Aware O/S [Yes] CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 122: General Acpi Configuration
Use the Suspend Mode option to specify the sleep state the system enters when it is not being used. S1 (POS) The system enters S1(POS) sleep state. The system EFAULT appears off. The CPU is stopped; RAM is refreshed; the system is running in a low power mode. ©Copyright 2007 CyberResearch, Inc...
Page 123: Apm Configuration
If this option is disabled, the only other option on the screen is the Power Button Mode. Disabled Disables the Advanced Power Management (APM) feature Enabled Enables the APM feature EFAULT CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 124 The Resume on Lan BIOS option specifies if the system is roused from a suspended or standby state when there is activity on the LAN. Disabled Wake event not generated by LAN activity EFAULT Enabled Wake event generated by LAN activity Resume On RTC Alarm [Disabled] ©Copyright 2007 CyberResearch, Inc...
Page 125: Remote Access Configuration
BIOS Menu 12: Remote Access Configuration Remote Access [Disabled] Use the Remote Access option to enable or disable access to the remote functionalities of the system. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 126: Usb Configuration
VT-UTF8 Combo Key Support These configuration options are discussed below. 6.3.9 USB Configuration Use the USB Configuration menu (BIOS Menu 13) to read USB configuration information and configure the USB settings. BIOS Menu 13: USB Configuration ©Copyright 2007 CyberResearch, Inc...
Page 127 USB driver loaded onto the system. Disabled Legacy USB support disabled Enabled Legacy USB support enabled EFAULT CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 128: Usb Mass Storage Device Configuration
Use the USB Mass Storage Reset Delay option to set the number of seconds POST waits for the USB mass storage device after the start unit command. 10 Sec POST waits 10 seconds for the USB mass storage device after the start unit command. ©Copyright 2007 CyberResearch, Inc...
Page 129 The USB device will be emulated as a floppy drive. The device can be either A: or B: responding to INT13h calls that return DL = 0 or DL = 1 respectively. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 130: Pci/Pnp
6.4 PCI/PnP Use the PCI/PnP menu (BIOS Menu 15) to configure advanced PCI and PnP settings. WARNING: Setting wrong values for the BIOS selections in the PCIPnP BIOS menu may cause the system to malfunction. ©Copyright 2007 CyberResearch, Inc...
Page 131 BIOS. If the operating system does not meet the Plug and Play EFAULT specifications, this option allows the BIOS to configure all the CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 132 Unless the VGA card manufacturer requires palette EFAULT snooping to be enabled, this option should be disabled. Enabled PCI devices are informed that an ISA based Graphics device is installed in the system so the ISA based ©Copyright 2007 CyberResearch, Inc...
Page 133 PCI Slot 3 is selected as the location of the OffBoard PCI IDE adapter card. Only select this slot if the adapter card is installed in PCI Slot 3. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 134 Available IRQ addresses are: IRQ3 IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device. ©Copyright 2007 CyberResearch, Inc...
Page 135: Boot
32KB reserved for legacy ISA devices 54KB reserved for legacy ISA devices 6.5 Boot Use the Boot menu (BIOS Menu 16) to configure system boot options. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 136: Boot Settings Configuration
® CEGA Series CyberResearch CPU Cards BIOS Menu 16: Boot 6.5.1 Boot Settings Configuration Use the Boot Settings Configuration menu (BIOS Menu 17) to configure advanced system boot options. BIOS Menu 17: Boot Settings Configuration ©Copyright 2007 CyberResearch, Inc...
Page 137 Does not enable the keyboard Number Lock automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 138: Boot Device Priority
Can be booted from a remote system through the 6.5.2 Boot Device Priority Use the Boot Device Priority menu (BIOS Menu 18) to specify the boot sequence from the available devices. Possible boot devices may include: FLOPPY DRIVE CD/DVD ©Copyright 2007 CyberResearch, Inc...
Page 139 ® CyberResearch CEGA Series CPU Cards BIOS Menu 18: Boot Device Priority Settings CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 140: Removable Drives
The boot sequence from the available devices is selected. If the “1st Drive” option is selected a list of available FDDs is shown. Select the first FDD the system boots from. If the “1st Drive” is not used for booting this option may be disabled. BIOS Menu 19: Removable Drives ©Copyright 2007 CyberResearch, Inc...
Page 141: Security
Boot Sector Virus Protection [Disabled] Use the Boot Sector Virus Protection to enable or disable boot sector protection. Disables the boot sector virus protection Disabled EFAULT CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 142: Chipset
Use the Chipset menu (BIOS Menu 21) to access the NorthBridge and SouthBridge configuration menus. WARNING: Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. BIOS Menu 21: Chipset ©Copyright 2007 CyberResearch, Inc...
Page 143: Northbridge Configuration
Internal graphics device. Disable Enable, 1MB 1MB of memory used by internal graphics device Enable, 8MB 8MB of memory used by internal graphics device EFAULT CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 144 Use the PEG Force x1 option to convert a PCI express X16 slot into a PCI express X1 slot. PCI express X16 slot runs in normal mode Disabled EFAULT Enabled PCI express X16 slot runs in PCI express X1 mode ©Copyright 2007 CyberResearch, Inc...
Page 145: Southbridge Chipset Configuration
The ASF controller is activated and allowed to communicate with a remote management server. Onboard LAN1 Controller [Enabled] The Onboard LAN1 Controller option enables or disables the on-board LAN1. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 146 EMI. This benefit may in some cases be outweighed by problems with timing-critical devices, such as a clock-sensitive SCSI device. Disabled EMI not reduced EFAULT EMI reduced Enabled ©Copyright 2007 CyberResearch, Inc...
Page 147: Exit
Use the Load Optimal Defaults option to load the optimal default values for each of the parameters on the Setup menus. The F9 key can be used for this operation. Load Failsafe Defaults CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 148 ® CEGA Series CyberResearch CPU Cards Use the Load Failsafe Defaults option to load failsafe default values for each of the parameters on the Setup menus. The F8 key can be used for this operation. ©Copyright 2007 CyberResearch, Inc...
Page 149: Driver Installation
® CyberResearch CEGA Series CPU Cards Chapter Driver Installation CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 150: Available Software Drivers
NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the CyberResearch website or contact technical support for the latest updates. The following drivers can be installed on the system.
Page 151: Chipset Driver Installation
Select “CEGA Drivers” shown in (Figure 7-2). Figure 7-2: Driver Installation 7.3 Chipset Driver Installation Step 1: To install the chipset driver, please follow the steps below. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 152: Figure 7-3: Chipset Driver Installation Program
CyberResearch CPU Cards Step 2: Select your operating system form the Chipset section of the GUI Step 3: A new window opens (Figure 7-3). Figure 7-3: Chipset Driver Installation Program Step 4: Double-click the infinst_Autol.exe icon. ©Copyright 2007 CyberResearch, Inc...
Page 153: Figure 7-4: Chipset Driver Installation Welcome Screen
Step 7: The license agreement in Figure 7-5 appears. Figure 7-5: Chipset Driver Installation License Agreement Step 8: Click Y to continue the setup. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 154: Figure 7-6: Chipset Driver Readme File Information
® CEGA Series CyberResearch CPU Cards Step 9: The Readme file in Figure 7-6 appears. Figure 7-6: Chipset Driver Readme File Information Step 10: Click N to start the driver installation. ©Copyright 2007 CyberResearch, Inc...
Page 155: Figure 7-7: Chipset Driver Installation Complete
After the driver installation process is complete, a confirmation screen (Figure 7-7) appears. Step 12: Click F to start the driver installation. INISH Figure 7-7: Chipset Driver Installation Complete CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 156: Intel Graphics Media Accelerator Driver
To install the Intel Graphics Media Accelerator driver, please follow the steps below: Step 1: Select your operating system form the VGA section of the GUI Step 2: A new window opens (Figure 7-8). Figure 7-8: Select the Operating System Step 3: Double-click the appropriate operating system folder. ©Copyright 2007 CyberResearch, Inc...
Page 157: Figure 7-9: Vga Driver
Double-click the installation program icon to continue the installation process. Step 6: The Readme information file shown in Figure 7-10 appears. Figure 7-10: Intel® Graphics Media Accelerator InstallShield Wizard CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 158: Figure 7-11: Installshield Wizard Extracting Files
® CEGA Series CyberResearch CPU Cards Step 7: Read the Readme file information and click N to begin extracting files (Figure 7-11). Figure 7-11: InstallShield Wizard Extracting Files ©Copyright 2007 CyberResearch, Inc...
Page 159: Figure 7-12: Intel® Graphics Media Accelerator Driver Welcome Screen
Figure 7-12: Intel® Graphics Media Accelerator Driver Welcome Screen Step 9: Click N and a license agreement appears (Figure 7-13). Figure 7-13: Intel® Graphics Media Accelerator Driver License Agreement CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 160: Figure 7-14: Intel® Graphics Media Accelerator Driver Installing Notice
Figure 7-15: Intel® Graphics Media Accelerator Installation Complete Step 12: The confirmation screen offers the option of restarting the computer now or later. For the settings to take effect, the computer must be restarted. Click F INISH restart the computer. Step 0: ©Copyright 2007 CyberResearch, Inc...
Page 161: Broadcom Lan Driver (For Gbe Lan) Installation
To install the Broadcom LAN driver, please follow the steps below. Step 1: Open Windows Control Panel (Figure 7-16). Figure 7-16: Windows Control Panel Step 2: Double-click the System icon (Figure 7-17). CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 163: Figure 7-18: Device Manager Tab
® CyberResearch CEGA Series CPU Cards Figure 7-18: Device Manager Tab Step 4: A list of system hardware devices appears (Figure 7-19). CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 164: Figure 7-19: Device Manager List
CPU Cards Figure 7-19: Device Manager List Step 5: Double-click the listed device that has question marks next to it (this means Windows does not recognize the device). Step 6: The Device Driver Wizard appears (Figure 7-20). ©Copyright 2007 CyberResearch, Inc...
Page 165: Figure 7-20: Search For Suitable Driver
Step 8: Select “Specify a Location” in the Locate Driver Files window (Figure 7-21). Figure 7-21: Locate Driver Files Step 9: Click N to continue. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 166: Realtek Ac`97 Audio Driver (Alc665) Installation
Go to the Southbridge Configuration menu. Set the Audio Controller option to [AC`97]. Step 3: Press F10 to save the changes and exit the BIOS setup. The system reboots. Step 0: 7.6.2 Driver Installation To install the audio driver please follow the steps below. ©Copyright 2007 CyberResearch, Inc...
Page 167: Figure 7-23: Select The Audio Codec
A new window opens (Figure 7-23). Figure 7-23: Select the Audio CODEC Step 3: Double-click the ALC665 folder. Step 4: Double-click the Setup.exe program icon in Figure 7-24. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 168: Figure 7-24: Locate The Setup Program Icon
Step 5: The InstallShield Wizard is prepared to guide the user through the rest of the process (Figure 7-25). Figure 7-25: Preparing Setup Screen Step 6: Once initialized, the InstallShield Wizard welcome screen appears (Figure 7-26). ©Copyright 2007 CyberResearch, Inc...
Page 169: Figure 7-26: Installshield Wizard Welcome Screen
The install shield starts to install the new software as shown in Figure 7-27. Figure 7-27: Audio Driver Software Configuration Step 9: At this stage the Digital Signature Not Found screen shown in Figure 7-28 appears. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 170: Figure 7-28: Audio Driver Digital Signal
Click Y to continue the installation process. The driver installation begins as shown in Figure 7-29. Figure 7-29: Audio Driver Installation Step 11: After the driver installation process is complete, a confirmation screen appears (Figure 7-30). ©Copyright 2007 CyberResearch, Inc...
Page 171: Realtek Hd Audio Driver (Alc883) Installation
Go to the Southbridge Configuration menu. Set the Audio Controller option to [Azalia]. Step 3: Press F10 to save the changes and exit the BIOS setup. The system reboots. Step 0: CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 172: Driver Installation
Driver (ALC665) installation. Refer to Section 7.6.2 for installation details. 7.8 SATA RAID Driver To install the Intel® Matrix Storage Manager driver, please follow the steps below: Step 1: Select your operating system form the SATA section of the GUI ©Copyright 2007 CyberResearch, Inc...
Page 173: Figure 7-31: Sata Raid Driver Installation Program
A new window opens (Figure 7-31). Figure 7-31: SATA RAID Driver Installation Program Step 3: Double-click the INTEL folder. Step 4: Double-click the iata62_cd.exe program icon in Figure 7-32. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 175: Figure 7-33: Installshield Wizard Setup Screen
Step 5: Figure 7-33 shows the InstallShield Wizard preparing to guide the user through the rest of the process. Figure 7-33: InstallShield Wizard Setup Screen CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 176: Figure 7-34: Matrix Storage Manager Setup Screen
® CEGA Series CyberResearch CPU Cards Step 6: Figure 7-34 shows the Matrix Storage Manager software configuring the installation process. Figure 7-34: Matrix Storage Manager Setup Screen ©Copyright 2007 CyberResearch, Inc...
Page 177: Figure 7-35: Matrix Storage Manager Welcome Screen
(Figure 7-36). Read the warning carefully and decide whether or not to continue the installation process. Figure 7-36: Matrix Storage Manager Warning Screen CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 178: Figure 7-37: Matrix Storage Manager License Agreement
® CEGA Series CyberResearch CPU Cards Step 9: Click N and a license agreement appears (Figure 7-37). Figure 7-37: Matrix Storage Manager License Agreement ©Copyright 2007 CyberResearch, Inc...
Page 179: Figure 7-38: Matrix Storage Manager Readme File
Readme information file shown in Figure 7-38 appears. Figure 7-38: Matrix Storage Manager Readme File Step 11: Read the Readme file information and click N CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 180: Figure 7-39: Matrix Storage Manager Setup Complete
Figure 7-39: Matrix Storage Manager Setup Complete Step 13: The confirmation screen offers the option of restarting the computer now or later. For the settings to take effect, the computer must be restarted. Click F INISH restart the computer. Step 0: ©Copyright 2007 CyberResearch, Inc...
Page 181: Ide Controller Installation
To install the IDE controller, please follow the steps below. Step 1: Open Windows Control Panel (Figure 7-40). Figure 7-40: Access Windows Control Panel CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 182: Figure 7-41: Double Click The System Icon
® CEGA Series CyberResearch CPU Cards Step 2: Double-click the System icon (Figure 7-41). Figure 7-41: Double Click the System Icon ©Copyright 2007 CyberResearch, Inc...
Page 183: Figure 7-42: Double Click The Device Manager Tab
® CyberResearch CEGA Series CPU Cards Step 3: Double-click the Device Manager tab (Figure 7-42). Figure 7-42: Double Click the Device Manager Tab CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 184: Figure 7-43: Device Manager List
Step 4: A list of system hardware devices appears (Figure 7-43). Figure 7-43: Device Manager List Step 5: Double-click the listed device that has question marks next to it. (This means Windows does not recognize the device). ©Copyright 2007 CyberResearch, Inc...
Page 185: Figure 7-44: Search For Suitable Driver
Figure 7-44: Search for Suitable Driver Step 7: Select “Specify a Location” in the Locate Driver Files window (Figure 7-45). Click to continue. Figure 7-45: Locate Driver Files CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 186: Figure 7-46: Location Browsing Window
(Figure 7-46) in the location browsing window, where “X:\” is the system CD drive. Figure 7-46: Location Browsing Window Step 9: Click OK to continue. A driver files location menu window appears. Click N continue. The driver is installed.Step 0: ©Copyright 2007 CyberResearch, Inc...
Page 187 ® CyberResearch CEGA Series CPU Cards CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 189: Bios Configuration Options
Restore on AC Power Loss [Last State]............104 Power Button Mode [On/Off] ................104 Resume on Ring [Disabled] ................104 Resume on Lan [Disabled]................. 104 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 190 Quick Boot [Enabled] ..................117 Quiet Boot [Disabled] ..................117 AddOn ROM Display Mode [Force BIOS] ............117 Bootup Num-Lock [On] ..................117 PS/2 Mouse Support [Enabled] ................. 118 Boot From LAN Support [Disabled] ..............118 Change Supervisor Password................121 ©Copyright 2007 CyberResearch, Inc...
Page 191 Spread Spectrum Mode [Disabled] ..............126 Save Changes and Exit ..................127 Discard Changes and Exit ................. 127 Discard Changes....................127 Load Optimal Defaults..................127 Load Failsafe Defaults..................127 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 193 NOTE: The following discussion applies to the DOS environment. Contact CYBERRESEARCH, INC. support or visit the CYBERRESEARCH, INC. website for specific drivers for more sophisticated operating systems, e.g., Windows. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
Page 194: Example Program
;setting the time-out value BL, 30 ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over? W_LOOP ;No, restart the application AX, 6F02H ;disable Watchdog Timer BL, 0 ; EXIT ; ©Copyright 2007 CyberResearch, Inc...
Page 195: Caddress Mapping
® CyberResearch CEGA Series CPU Cards Appendix Address Mapping CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 196: Io Address Map
Serial Port 1 (COM1) Table C-1: IO Address Map C.2 1st MB Memory Address Map Memory address Description 00000-9FFFF System memory A0000-BFFFF VGA buffer F0000-FFFFF System BIOS 1000000- Extended BIOS Table C-2: 1 MB Memory Address Map ©Copyright 2007 CyberResearch, Inc...
Page 197: Irq Mapping Table
C.4 DMA Channel Assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available Table C-4: DMA Channel Assignments CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 199: Ddio Interface
® CyberResearch CEGA Series CPU Cards Appendix DIO Interface CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 200: Dio Interface Introduction
General purpose I/O port 1 bit 0. Input 1 GP11 General purpose I/O port 1 bit 1 Input 2 GP12 General purpose I/O port 1 bit 2 Input 3 GP13 General purpose I/O port 1 bit 3 ©Copyright 2007 CyberResearch, Inc...
Page 201: Assembly Language Samples
The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O output functions is listed below. AX, 6F09H Sets the digital port as output BL, 09H Initiates the INT 15H BIOS call CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 203: Eexternal Ac'97 Audio Codec
® CyberResearch CEGA Series CPU Cards Appendix External AC’97 Audio CODEC CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 204: Introduction
The driver installation has been described in Section 7.6. After rebooting, the sound effect configuration utility appears in the Windows Control Panel (Figure E-1). If the peripheral speakers are properly connected, sound effects should be heard. ©Copyright 2007 CyberResearch, Inc...
Page 205: Sound Effect Configuration
Click the Sound Effect Manager icon in the system task bar (Figure E-2). Figure E-2: Sound Effect Manager Icon [Task Bar] Step 3: The sound effect manager appears (Figure E-3). CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 206: Sound Effect Manager Configuration Options
The Sound Effects Manager enables configuration of the items listed below. To configure these items click the corresponding menu tab in the Sound Effects Manager (Figure E-3). NOTE: The Karaoke Mode is configured in the Sound Effect menu. To access Karaoke ©Copyright 2007 CyberResearch, Inc...
Page 207 Configurable options include: Headphone Channel mode for stereo speaker output Channel mode for 4 speaker output Channel mode for 5.1 speaker output CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 208 HRTF Demo - Adjust HRTF (Head Related Transfer Functions) 3D positional audio here before running 3D applications. Microphone Effect - Microphone noise suppression is enabled in this menu. General - General information about the installed AC’97 audio configuration utility is listed here. ©Copyright 2007 CyberResearch, Inc...
Page 209: Intel Matrix Storage Manager
® CyberResearch CEGA Series CPU Cards Appendix ® Intel Matrix Storage Manager CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 210: Introduction
If a drive member of a RAID array should fail, the failed drive can then be correctly identified. CAUTION! Do not accidentally disconnect the SATA drive cables. Carefully route the cables within the chassis to avoid system down time. F.2 Features and Benefits ©Copyright 2007 CyberResearch, Inc...
Page 211: Accessing The Intel Matrix Storage Manager
Enable SATA drives in BIOS. Start the computer and access the BIOS setup program. Enable SATA support for all IDE devices. Refer to the applicable BIOS configuration section in this user manual. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 212: Raid Configuration
RAID array, make sure the data has been moved or backed up before creating a RAID array out of the disk drives. Step 1: Select “Create RAID Volume.” Use the arrow keys to highlight Create RAID ©Copyright 2007 CyberResearch, Inc...
Page 213 Figure F-2. Figure F-2: Create RAID Volume Name Step 3: Choose the RAID level. Select a RAID level from the list. RAID levels include CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 214 RAID 10 level requires a minimum of four hard drives. RAID5 level requires a minimum of three hard drives. Figure F-3: Choose the Raid Level Step 4: Select the Stripe Size. Select a stripe size from the list. See Figure F-4. ©Copyright 2007 CyberResearch, Inc...
Page 215 See Figure F-5. Figure F-5: Enter the Volume Capacity Step 6: Create the RAID Volume. Press E to create the RAID volume as specified. NTER CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 216: Deleting A Raid Volume
Create RAID Volume Verification. After reading the warning, press Y to create the RAID volume as specified, or N to return to the Create RAID Volume menu. See Figure F-7. Step 0: Figure F-7: Create RAID Volume Verification F.4.2 Deleting a RAID Volume ©Copyright 2007 CyberResearch, Inc...
Page 217 Select RAID Volume to be Deleted. Use the arrow keys to highlight the RAID volume to be deleted and press E . See Figure F-9. NTER CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA...
Page 218 RAID volume, or N to return to the Delete Volume menu. See Figure F-10. Figure F-10: Delete Volume Verification Step 4: Non-RAID Disks. After deleting the RAID volume, the disks belonging to the volume will be shown as non-RAID disks. See Figure F-11. Step 0: ©Copyright 2007 CyberResearch, Inc...
Page 219: Resetting A Disk To Non-Raid
Step 1: Select “Reset Disk to Non-RAID.” Use the arrow keys to highlight Reset Disk to Non-RAID and press E . See Figure F-12. NTER CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 220 . See Figure F-13. NTER Figure F-13: Select Disk to Reset Step 3: Reset Disk Verification. After reading the warning, press Y to reset the selected disks as non-RAID, or N to return to the Reset RAID Data menu. ©Copyright 2007 CyberResearch, Inc...
Page 221: Exiting The Matrix Storage Manager
Figure F-15: Disk Drive and RAID Volume Status F.4.4 Exiting the Matrix Storage Manager Step 1: Select “Exit.” Use the arrow keys to highlight Exit and press E NTER CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 222 See Figure F-16. Figure F-16: Exit Menu Step 2: Exit Verification. Press Y to exit the Matrix Storage Manager, or N to return to the Main menu. See Figure F-17. Step 0: Figure F-17: Exit Verification ©Copyright 2007 CyberResearch, Inc...
Page 223: Index
® CyberResearch CEGA Series CPU Cards Index CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 224 CMOS ............69 Boot Device Priority......118 clear CMOS jumper .......69 Boot Settings Device Configuration..116 codec ............20 CPU Configuration ........88 AC’97.............20 Floppy Configuration ......95 connectors, pinouts and location General ACPI Configuration ....102 +12V ATX power supply ......37 ©Copyright 2007 CyberResearch, Inc...
Page 225 .........41 DIMM ............67 location and pinouts.......41 installation..........67 floppy disk controller ........27 specifcations..........67 floppy disk drive .........41 DIO Interface ...........179 front panel connector .........43 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 226 LPC interface ........22, 26 infrared interface........45 Amplitude Shift Key Infrared....45 ASKIR............45 memory module installation .......67 Serial Infrared........45 memory support .........17 SIR............45 infrared interface connector.......45 location and pinouts ......45 installation checklist ........62 northbridge chipset ........16 ® Intel Matrix Storage Manager....189 ©Copyright 2007 CyberResearch, Inc...
Page 227 Deleting a RAID Volume......196 Super I/O chipset ........25 Exiting the Matrix Storage Manager..201 System Monitoring ........27 ® Intel Matrix Storage Manager ....189 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...
Page 228 USB connector, internal ......52 location and pinouts.......52 unpacking ..........31 unpacking checklist .......31 unpacking precautions ......31 VGA monitor..........81 connection ..........81 connection ..........81 USB .............52, 77 cable ............77 cable connection ........77 warranty validation ........61 connectors..........77 Watchdog Timer........172 controller..........23 ©Copyright 2007 CyberResearch, Inc...
Page 229: Product Service
Signal connections and programming are the two most common sources of difficulty. CyberResearch support personnel can help you solve these problems, especially if you are prepared for the call.
Page 231 CyberResearch, Inc. will, at its option, repair or replace the defective item under the terms of this warranty, subject to the provisions and specific exclusions listed herein.
Page 234 CyberResearch, Inc. 25 Business Park Drive Branford, CT 06405 USA P: (203) 483-8815; F: (203) 483-9024 www.cyberresearch.com...

This manual is also suitable for:

Cega pd-24-x Cega pd-36-x

CyberResearch CEGA PD-32-X User Manual

1 Introduction

Figure 1-1: CEGA Overview

2 Detailed Specifications

Figure 2-1: CEGA Dimensions (MM)

Figure 2-2: External Interface Panel Dimensions (MM)

Figure 2-3: Data Flow Block Diagram

Table 2-1: Supported Intel® Core™ 2 Duo Processors

Table 2-2: Supported Intel® Pentium® 4 Processors

Celeron ® D Processors

Table 2-3: Supported Intel® Pentium® D Processors

Table 2-4: Supported Intel

3 Unpacking

Table 3-1: Package List Contents

4 Connector Pinouts

Figure 4-1: Connector and Jumper Locations

Table 4-1: Peripheral Interface Connectors

Table 4-5: DIO Connector Pinouts

Figure 4-5: Fan Connectors Locations

Table 4-7: 34-Pin FDD Connector Pinouts

Table 4-15: USB Port Connector Pinouts

Figure 4-15: CEGA External Peripheral Connector Panel

Table 4-17: Mouse Connector Pinouts

Table 4-21: VGA Connector Pinouts

5 Installation

Figure 5-1: Intel LGA775

Figure 5-4: Insert the LGA775 CPU

Figure 5-16: USB Connector

Figure 5-17: VGA Connector

6 Ami Bios

7 Driver Installation

Figure 7-1: Introduction Screen

Figure 7-2: Driver Installation

Figure 7-5: Chipset Driver Installation License Agreement

Figure 7-27: Audio Driver Software Configuration

Figure 7-10: Intel® Graphics Media Accelerator Installshield Wizard

Figure 7-9: VGA Driver

Figure 7-16: Windows Control Panel

Figure 7-17: System Icon

Figure 7-18: Device Manager Tab

Figure 7-19: Device Manager List

Figure 7-21: Locate Driver Files

Figure 7-20: Search for Suitable Driver

Figure 7-11: Installshield Wizard Extracting Files

Figure 7-13: Intel® Graphics Media Accelerator Driver License Agreement

Figure 7-12: Intel® Graphics Media Accelerator Driver Welcome Screen

Figure 7-15: Intel® Graphics Media Accelerator Installation Complete

Figure 7-14: Intel® Graphics Media Accelerator Driver Installing Notice

Figure 7-31: SATA RAID Driver Installation Program

Figure 7-32: SATA RAID Setup Program Icon

Figure 7-33: Installshield Wizard Setup Screen

Figure 7-34: Matrix Storage Manager Setup Screen

Figure 7-36: Matrix Storage Manager Warning Screen

Figure 7-35: Matrix Storage Manager Welcome Screen

Figure 7-37: Matrix Storage Manager License Agreement

Figure 7-38: Matrix Storage Manager Readme File

Figure 7-39: Matrix Storage Manager Setup Complete

Figure 7-40: Access Windows Control Panel

Figure 7-41: Double Click the System Icon

Figure 7-42: Double Click the Device Manager Tab

Figure 7-43: Device Manager List

Figure 7-44: Search for Suitable Driver

Figure 7-45: Locate Driver Files

Figure 7-46: Location Browsing Window

Abios Menu Options

Bwatchdog Timer

Caddress Mapping

Ddio Interface

Eexternal Ac'97 Audio Codec

Quick Links

Need help?

Questions and answers

Related Manuals for CyberResearch CEGA PD-32-X

Summary of Contents for CyberResearch CEGA PD-32-X
