CX2033/MC560MFP Maintenance Manual 052809B Oki Data CONFIDENTIAL...
Page 2 Oki Data CONFIDENTIAL Document Revision History Corrected items Person in Rev.No. Date charge Page Description of change 2008-11-10 ISSUE MFD1 Y. Shimizu 2008-12-25 Drawing Maintenance EP5 Y. Fujisawa 44158801TH Rev.2...
Page 3 Oki Data CONFIDENTIAL PReface This maintenance manual describes maintenance methods in filed of MC560/CX2033MFP targeting service personnel. Names of components that require procurement, such as printed circuit board, are assigned with numbers. (Example) ABCD-3 Printed circuit board The number is assigned to specify type of the component and is not the manufacturing version of the printed circuit board and so on.
Page 4: Table Of Contents
Oki Data CONFIDENTIAL contents 1. confIGURatIon ....................8 System configuration ......................8 MFP configuration .......................10 Composition of optional items ..................... 11 Specifications ........................12 Interface specifications .......................18 1.5.1 Parallel interface specifications (N/A) ..............18 1.5.2 USB interface specifications ..................18 1.5.2.1 Outline of USB interface .................18 1.5.2.2...
Page 5 Oki Data CONFIDENTIAL Part replacement methods ....................75 4.2.1 Left side cover .......................75 4.2.2 Right side cover .....................76 4.2.3 Detachment methods of the scanner and printer ..........77 4.2.4 Scanner .........................78 4.2.4.1 ADF Unit ....................78 4.2.4.1.1 ASS'Y STOPPER ..............78 4.2.4.1.2 ASS'Y PAPER SUPPORT ...........78 4.2.4.1.3...
Page 6 Setup of CU Serial Number ..............191 6.4.3 Setup of destination .....................192 Updating Scanner Firmware .....................193 6.6.1 Updating with the OKI MFP Network Setup Tool ..........193 6.6.2 Updating by Running the Scanner in Loader Mode..........196 7. PeRIoDIcaL MaIntenance .................198 Recommended replacement parts ..................198 Cleaning ..........................198...
Page 7 Oki Data CONFIDENTIAL 7.6.3 Cleaning a Paper Jam ..................204 7.6.4 Replacing the ADF pad ..................205 8. tRoUBLesHootInG PRoceDURes ............206 Precautions prior to repair ....................206 Items to be checked prior to taking action on abnormal images ........206 Precautions when taking action on abnormal images ............206 Preparations for troubleshooting ..................206...
Page 8: Configuration
Oki Data CONFIDENTIAL CONFIGURATION System configuration MC560/CX2033MFP Printer Connection diagram Figure 1-1-1 represents the system configuration of the printer. Figure 1-1-1 44158801TH Rev.2...
Page 9 Oki Data CONFIDENTIAL MC560/CX2033MFP Scanner Connection Diagram Figure 1-1-2 represents the system configuration of the scanner. Printer I/F Printer Connector USB (5 Pin) Power (4 Pin) Motor 4 Pin Board 34Pin Scanner Main board ADF Board LINE 6 Pin Paper...
Page 10: Mfp Configuration
Oki Data CONFIDENTIAL MFP configuration The internal part of the MC560/CX2033MFP is composed of the following sections: • Electrophotographic processing section • Paper paths • Control sections (CU sect./PU sect.) • Operator panel • Power supply sections (High-voltage sect./low-voltage sect.) Figure 1-2 represents the configuration of the printer.
Page 11: Composition Of Optional Items
Oki Data CONFIDENTIAL Composition of optional items The following optional items are available for the printer: (1) Second tray (2) Duplex Unit DXU-C4D (3) Expansion Memory 256 MB / 512 MB MEM256E MEM512C For long printing, it is recommended to add an expansion memory.
Page 12: Specifications
Oki Data CONFIDENTIAL Specifications Category Item MC560/CX2033MFP Exterior Width 500mm Dimension Depth 600mm Height 575mm Weight about 37kg Width of print Width of print Engine speed Monochrome 32ppm (A4) Color 20ppm Fast print time Monochrome 8sec (A4) Color 11sec Warm-up time...
Page 13 Oki Data CONFIDENTIAL Category Item MC560/CX2033MFP Service life Printer life 420,000 pages, 5 years Max. 50,000 pages / mo. Print duty (M=L/12, A=L/12/5) Average 4,000 pages / mo. MTBF (2.3% duty) Not applicable MPBF 40,000 pages MTTR 20 minutes Toner life Approx.
Page 14 Oki Data CONFIDENTIAL Category Item MC560/CX2033MFP Operator panel 16 characters in 2 line (Roman alphabet/Japanese kana) No paper size indicated LED (Color) (Green x1, dark amber x1) Switch Status Paper out Provided switch/sensor Paper low Not provided Toner low Provided (Y.M.C.K)
Page 15 Oki Data CONFIDENTIAL Category Item MC560/CX2033MFP Life 240,000 scans or more, or 5 years Recommended daily scans Up to 1,000 pages a day Recommended Pad 50,000 scans Replacement Recommended Roller 200,000 scans Replacement Copy Color: 600 x 600dpi Copy Resolution...
Page 16 Oki Data CONFIDENTIAL Category Item MC560/CX2033MFP Scan Scanner Type Flatbed image sensor: Color CCD Scanning Element light source: CCFL Yes (face up) Auto Docu- Simplex 50 sheets ment Feeder (ADF) Duplex Warm-up Time Resolution 4800 x 4800dpi Optical: 600 x 1200dpi...
Page 17 Oki Data CONFIDENTIAL Category Item MC560/CX2033MFP JP11 x 2 (Line/TEL) Connentivity PSTN, PBX Line Compatibility ITU-T G3 (Super G3) Modem Speed 33.6Kbps 3sec./Page Transmission Time Document: ITU-T#1/MMR/Std (200 x 100dpi) Std: 200 x 100dpi, Fine: 200 x 200dpi, Fax Resolution...
Page 18: Interface Specifications
Oki Data CONFIDENTIAL Interface specifications 1.5.1 Parallel interface specifications (N/A) 1.5.2 USB interface specifications 1.5.2.1 Outline of USB interface (1) Basic specifications USB (Hi-Speed USB supported) (2) Transmission mode Full speed (Max. 12Mbps ± 0.25%) High speed (Max.480Mbps ± 0.05%)
Page 19: Network Interface Specifications
Oki Data CONFIDENTIAL 1.5.3 Network interface specifications 1.5.3.1 Outline of network interface 1.5.3.1.1 Basic specifications of network interface Protocol family Network protocol Application TCP/IP TCP, ARP, UDP LPR, RAW, FTP, Telenet SNMPv1 DHCP/BOOTP UPnP SNTP 1.5.3.1.2 Basic specifications of network interface...
Page 20: Network Interface Connectors And Cables
Oki Data CONFIDENTIAL 1.5.3.2 Network interface connectors and cables (1) Connectors 100 BASE-TX / 10 BASE-T (Automatically switched, not usable simultaneously) Connector pin assignment Cables RJ-45 connectorized non-shielded twisted-pair cable (Category 5 recommended) 1.5.3.3 Network interface signals Pin No. Signal name...
Page 21: Explanation Of Operation
Oki Data CONFIDENTIAL EXPLANATION OF OPERATION Electrophotographic processing mechanism (1) Electrophotographic process The electrophotographic process is explained briefly below: 1. Charging A voltage is applied to the CH roller to electrically charge the surface of the OPC drum. 2. Exposure The LED head radiates light onto the charged OPC drum in accordance with the image signal.
Page 22 Oki Data CONFIDENTIAL 2. Exposure The light emitted from the LED head is radiated onto the charged surface of the OPC drum. The charge of the radiated part of the OPC drum attenuates according to the intensity of the light, forming an electrostatic latent image on the OPC drum surface.
Page 23 Oki Data CONFIDENTIAL 4. Transfer A sheet of paper is placed over the OPC drum surface, and an electric charge is given to the paper from its back side by the transfer roller. When a high voltage is applied to the transfer roller from the power source, the charge...
Page 24 Oki Data CONFIDENTIAL 6. Removal of Electricity Electrically charge on the OPC drum surface decveases by exppsing the OPC drum surface after transfer to the light. Charging roller Board for the light of the removal of electricity Light for the...
Page 25 Oki Data CONFIDENTIAL 8. Fuser The toner image which was transferred to the paper is applied heat and pressure as it passes between the heat roller and the backup roller, and it is therefore fused onto the paper. For the sake of safety, a thermostat is provided; it comes on to cut off the voltage supplied to the heater if the heat roller temperature rises above a certain preset temperature.
Page 26: Printing Process
Oki Data CONFIDENTIAL Printing process The paper fed from Tray 1 or Tray 2 is carried by the paper feed roller, register roller L and transport roller. When the paper is fed from the MPT, it is carried by the MPT paper feed roller and register roller U.
Page 27 Oki Data CONFIDENTIAL (1) Paper fed from 1st Tray 1. As illustrated in Figure 2-1, when the solenoid is ON, the register motor rotates (Counterclockwise turn), transporting the paper until the IN1 sensor comes ON. (When the solenoid is ON, the paper feed roller is driven.) 2.
Page 28 Oki Data CONFIDENTIAL (3) Transport belt 1. As the transport belt motor rotates in the direction of the arrow, the transport belt is driven. The belt unit consists of one transport roller placed immediately underneath each color drum, with a transport belt inserted in between them.
Page 29 Oki Data CONFIDENTIAL (4) Up/down-motions of ID units 1. The up/down-motions of the ID units take place driven by the lift-up motor. 2. Figure 2-6 shows the motions of the different ID units when the printer is operated for color print. As the lift-up motor rotates (Clockwise turn), the lift-up link slides to the left, causing the ID units to come down, as can be seen in Figure 2-6.
Page 30 Oki Data CONFIDENTIAL (5) Fuser unit and paper output 1. As illustrated in Figure 2-8, the fuser unit and delivery roller are driven by the DC motor. As the fuser motor rotates (Counterclockwise turn), the heat roller is turned. This roller fixes a toner image by heat and pressure.
Page 31 Oki Data CONFIDENTIAL Outline of color drift correction The color drift correction is implemented reading the correction pattern that is printed on the belt with the sensor located inside the sensor shutter under the belt unit. This sensor is used to detect and correct the pattern.
Page 32 Oki Data CONFIDENTIAL Error checking methods and remedial methods The color drift correction test function among the other self-diagnostic functions is employed to check errors. (Subsection 5.3.2.6) Remedial methods against different errors • CALIBRATION (L or R), DYNAMICRANGE (L or R) Check 1: If the above indication appears, check the connected state of the sensor cable (FFC).
Page 33 Oki Data CONFIDENTIAL Outline of density correction method The density correction is implemented reading the correction pattern that is printed on the belt with the sensor located inside the sensor shutter under the belt unit. Automatic start timing of density correction: •...
Page 34 Oki Data CONFIDENTIAL Error checking methods and remedial methods The density correction test function among the other self-diagnostic functions is employed to check errors. (Subsection 5.3.2.7) Remedial methods against different errors • CALIBRATION ERR, DENS SENSOR ERR Check 1: If the above indication appears, check the connected state of the sensor cable.
Page 35 Oki Data CONFIDENTIAL Principle of toner sensor detection Toner LOW is detected by the toner sensor (Reflection sensor) installed inside the printer. The shielding plate is mounted inside the ID and rotates in synchronization with toner agitation. Moreover, the ID has a shutter fitted. The shutter is synchronized with the operation lever of the toner cartridge, and the toner sensor can detect that the toner cartridge has been loaded properly.
Page 36: Theory Of Operation
Oki Data CONFIDENTIAL Theory of Operation 2.3.1 Introduction Cold Fluorescent Analogu Signal Digital Signal Reflecte Board Imag Processor Scan USB Device Control Print Controller Panel Print Filing FTP HTTP Server RJ-45 Ethernet E-mail SMTP Server Copy USB Host Printer Figure 2.1 Theory of Operation The reflected rays of your original as shown in the above Figure 5.1 pass through the lens and...
Page 37: Main Control Unit
Oki Data CONFIDENTIAL 2.3.2 Main Control Unit 2.3.2.1 System Diagram Figure 2.2 shows the system block diagram. To Printer From Printer Main Board USB 2.0 Host LCD Display & Control Control Panel To PC USB 2.0 Device Keyboard Mac/Phy. To Network...
Page 38: Main Control Circuit
Oki Data CONFIDENTIAL 2.3.2.2 Main Control Circuit This MC560/CX2033MFP is controlled by MIPS CPU. The CPU is configured with a 2.5MB external ROM program area, a 64MB external RAM work area. I/O Address Maps: ROM Area: Flash Layout 29LV040 (Flash 0)
Page 39 Oki Data CONFIDENTIAL • External I/O External I/O I/O Map External Interrupt ISP1581, USB2.0 Device Bank 2 INT1 OA982 Bank 3 INT0 Panel Bank 6 OA982-DMALED Bank 7 • PCI Device Device External Interrupt RTL8100C PCIA, ID=0x11 INT3 VT6212 PCIB, ID=0x12...
Page 40: Video Circuit
Oki Data CONFIDENTIAL 2.3.2.3 Video Circuit: The video circuit of this MC560 includes: 1. CCD driving circuit and motor control signal 2. CCD signal processing circuit. 1. CCD Driving Circuit & Motor Control Signal The CCD driving circuit is used to generate correct signals to the CCD, so that the CCD may generate the correct image data.
Page 41 Oki Data CONFIDENTIAL 2. CCD signal processing circuit Dout CCD Signal Processor The CCD signal processor includes all the necessary circuitry to perform three-channel conditioning and sampling. The signal chain consists of three-channel correlated double sampling (CDS) and programmable gain adjustment of the CCD output (PGA) is a 16 bit analog to digital connector (ADC) quantizes the analog signal.
Page 42: Panel And Lcd Module Circuit
Oki Data CONFIDENTIAL 2.3.2.4 Panel and LCD Module Circuit The circuit for Panel and LCD module controls the function of the entire module including the LCD Display, the push button on the Control Panel, and LED display. Pin assignment of LCD module...
Page 43: Sensor Input
Oki Data CONFIDENTIAL 2.3.2.5 Sensor Input The sensor input includes home position sensor. Home position sensor The home position of the carrier motor is detected by photo sensor. The photo transis- tor transmission to the photo sensor receiver circuit is shown below.
Page 44: Installation
Oki Data CONFIDENTIAL INSTALLATION Cautions, and do's and don'ts • Do not install the MFP at high temperature or near fire. • Do not install the MFP in a location where chemical reaction can take place (laboratory, etc.). • Do not install the MFP in the proximities of inflammable solvents, such as alcohol, paint thin- ner, etc.
Page 45 Oki Data CONFIDENTIAL • Do not install the MFP in a location where its vent hole is blocked. • Do not install the MFP directly on a shaggy carpet or rug. • Do not install the MFP in a sealed room or other location with poor ventilation or permeabil- ity.
Page 46: Unpacking Method
Oki Data CONFIDENTIAL Unpacking method Personal injuries may occur. Make sure to lift up this MFP by two or more persons, since it weighs Approx. 37kg. • Remove the four handles from the sides of the box, as illustrated below, and lift up the corrugated fiberboard box.
Page 47 Oki Data CONFIDENTIAL Moving MFP Note! Do not hold the scanner unit to carry. 47 / 44158801TH Rev.2...
Page 48: Mfp Installation Instructions
Oki Data CONFIDENTIAL MFP Installation Instructions • Install the MFP in a location where the following temperature and humidity are met: Ambient temperature: 10 - 32˚C Ambient humidity: 20 - 80 %RH(Relative humidity) Max. wet-bulb temperature: 25˚C • Use caution to avoid dew condensation.
Page 49: Listing Of Component Units And Accessories
Oki Data CONFIDENTIAL Listing of component units and accessories • Check to make sure that the component units are free from damage, dirt or other zirregulari- ties in the appearance. • Ensure that none of the accessories to the units is missing and that they are free from break- age or other flaw.
Page 50: Assembly Procedure
Oki Data CONFIDENTIAL Assembly Procedure 3.5.1 MFP main body Remove Protective Equipment 1) Remove the protective tape (5 places) and the paper on the front of the printer. Paper Protective Tape Note! Do not remove the transparent sheet on the ADF.
Page 51 Oki Data CONFIDENTIAL 7) Hold down the fuser unit lever (blue) in the direction of the arrow and remove the stopper-release (orange). Fuser unit lever (blue) Stopper-release (orange) Note! The stopper-release is necessary for printer transport. It should be kept.
Page 52 Oki Data CONFIDENTIAL Install the image drum cartridges 1) Gently take out four image drum cartridges with starter toner cartridges installed. Toner cartridge Image drum cartridge Note! • Do not move the blue levers of the starter toner cartridges. • Handle the image drum cartridges (the green cylinder part of them) with enough care because they are damaged very easily.
Page 53 Oki Data CONFIDENTIAL 4) Check the color of the label on each toner cartridge against the label on each image drum cartridge. 5) Gently set four image drum cartridges back into the printer. Image drum cartridge Label Labels 6) Rotate the lever of each toner cartridge fully in the direction of the arrow.
Page 54 Oki Data CONFIDENTIAL Install the parts of the scanner 1) Attach a paper tray, a paper support and a paper stopper. Paper Tray Paper Stopper Paper Support 2) Open the ADF unit to release the lock. ADF unit 54 /...
Page 55 Oki Data CONFIDENTIAL Loading paper in the paper cassette 1) Pull out the paper cassette. Note! Do not peel off the rubber attached to the plate. 2) Set the paper stopper securely, according to the paper size. Paper guide Paper stopper Plate 3) Loosen the paper well and line up its vertical and lateral edges.
Page 56 Oki Data CONFIDENTIAL Loading paper in the multi-purpose tray 1) Open the multi-purpose tray and also the paper supporter. Multi-purpose tray 2) Set the manual feed guide to the paper size. 3) Line up the vertical and lateral edges of the paper.
Page 57 Oki Data CONFIDENTIAL Placing Your Document(s) in the ADF 1) Make sure your document is free of staples, paper clips and is not worn. 2) If you have multiple pages, fan your document(s) to avoid occasional paper jam. The ADF can hold up to 50-page document at one time.
Page 58 Oki Data CONFIDENTIAL Placing Your Document(s) on the Glass 1) Open document(s) cover to reveal the glass. 2) Place your document(s) with the text FACE DOWN on the glass and align the document(s) in the upper-left corner of the glass as illustrated in the following figure.
Page 59: Connection Of Power Cable
Oki Data CONFIDENTIAL 3.5.2 Connection of power cable Power supply conditions • Observe the following conditions: AC: 110~127V±10%/220~240V±10% Power frequency: 50Hz or 60Hz ± 2Hz Approx. 37kg • If the available power is unstable, use a voltage regulator or the like.
Page 60 Oki Data CONFIDENTIAL Connecting the power cord Note! Ensure that the power switch is in OFF (O). 1) Insert the power cord into the MFP. 2) Connect the grounding wire to the ground terminal. 3) Insert the power plug into the power outlet.
Page 61 Oki Data CONFIDENTIAL Checking color copy movement 1) Fan sheets of paper and align edges. 2) Place color document(s) with the text face up in the paper tray of the ADF unit. Paper tray Text face up 3) Press the color copy button.
Page 62 Oki Data CONFIDENTIAL Turning off the power When a hard disk (optional) is not equipped, the power can be turned off as is. Note! Do not turn off the power while the MFP is printing. On the MC560/CX2033MFP equipped with the built-in type hard disk (optional), do not outright turn off the power, but follow the procedure described below.
Page 63: Installation Of Optional Items
+256MB(512MB) MEM512C +512MB(768MB) Note! • Be sure to use genuine Oki Data parts. If any other parts are used, the MFP will not function. • To conduct long print on the MC560/CX2033MFP, it is recommended to add a 256MB expansion memory.
Page 64 Oki Data CONFIDENTIAL (2) Installation of second tray unit This tray is intended to increase the amount of paper that can be loaded in the MFP. It holds 530 sheets of 70kg ream weight paper, allowing to print 930 sheets continuously when com- bined with the standard paper cassette and multi-purpose tray.
Page 65 Oki Data CONFIDENTIAL (3) Installation of duplex unit This unit is used for printing on two sides of paper. Note! For two-sided printing, it is recommended to add an expansion memory. For details, see "Expansion memories". Type: DXU-C4D Turning OFF the MFP power and disconnecting the power cord Note! If an expansion memory is installed with the power switched ON, the MFP may be broken.
Page 66 Oki Data CONFIDENTIAL (4) Installation of built-in type hard disk This is a built-in type hard disk to be added to the MFP. It is used to conduct confirmation print, authentication print, to store print jobs, or to make buffer print, and also when the [ COLLATE FAIL] is indicated in a section-by-section print.
Page 67 Oki Data CONFIDENTIAL Installing the built-in type hard disk 1) Insert part "a" of the built-in type hard disk into hole "b" of the MFP main body, and align the positions of the screw holes. 2) Install the two screws.
Page 68: Confirmation Of Recognition Of Optional Items
Oki Data CONFIDENTIAL 3.5.4 Confirmation of recognition of optional items To check to see whether or not the optional items have been installed properly, execute the Menu Map print by referring to "3.6 Menu Map print. (1) Confirmation of recognition of expansion memory Checking the contents of the Menu Map.
Page 69: Menu Map Print
Oki Data CONFIDENTIAL Menu Map print This print is intended to ensure that the MFP operates normally. 1) Load A4 paper in the tray. 2) Press the "Menu +" switch several times to cause [Information Menu] to be displayed. 3) Press the "Set"...
Page 70: Connection Methods
Oki Data CONFIDENTIAL Connection methods <USB connection> Preparing a USB cable Note! • No MFP cable is supplied with the MFP. Provide one separately. • Prepare a USB type cable separately. • When connection is to be made in "Hi-Speed" mode of USB2.0, use a USB cable conforming to the Hi-Speed specification.
Page 71 Oki Data CONFIDENTIAL <LAN cable connection> Preparing a LAN cable Switching off the MFP and computer 1) Plug the Ethernet cable into the Network interface connector of the MFP. 2) Insert the Ethernet cable into the hub. Network interface connector 71 / 44158801TH Rev.2...
Page 72: Confirmation Of Paper Used By The User
Oki Data CONFIDENTIAL Confirmation of paper used by the user Load the media used by the user in the MFP, make Media Type/Weight settings, execute the Menu Map/Demo print, and check to make sure that the printouts are free from toner flaking.
Page 73: Replacement Of Parts
Oki Data CONFIDENTIAL REPLACEMENT OF PARTS This section explains the field replacement procedures for parts, assemblies and component units. While those replacement procedures refer to the disassembling of parts, follow the same procedures inversely for reassembling them. The part numbers (1, 2, etc.) employed in this manual are different from those assigned in the corresponding configuration diagrams of Disassembly for Maintenance (44158801TL) and RSPL (44158801TR).
Page 74 Oki Data CONFIDENTIAL [Maintenance Tools] Table 4-1-1 indicates the tools necessary to replace printed-circuit boards and component units. Table 4-1-1 Maintenance Tools Service Tools Q' ty Place of use Remarks No. 2-200 Philips 3~5 mm screws screwdriver, Magnetized No. 3-100 screwdriver No.
Page 75: Part Replacement Methods
Oki Data CONFIDENTIAL Part replacement methods This subsection explains the replacement methods for the parts and assemblies illustrated in the disassembly system diagram below. 4.2.1 Left side cover (1) Open the scanner. (2) Open the top cover. (3) Open the feeder unit.
Page 76: Right Side Cover
Oki Data CONFIDENTIAL 4.2.2 Right side cover (1) Open the scanner. (2) Open the top cover. (3) Open the feeder unit. (4) Remove screw , and detach right side cover . (Tool No.1) Scanner Top cover Feeder unit 76 /...
Page 77: Detachment Methods Of The Scanner And Printer
Oki Data CONFIDENTIAL 4.2.3 Detachment methods of the scanner and printer (1) Detach left side cover and right side cover.(See Subsection 4.2.1,4.2.2) (2) Remove the four screws , and detach the scanner . (Tool No.1) Stand-unit-R Top-cover Stand-unit-L Stand-unit-L Stand-unit-R Note! •...
Page 78: Scanner
Oki Data CONFIDENTIAL 4.2.4 Scanner 4.2.4.1 ADF Unit 4.2.4.1.1 ASS'Y STOPPER (1) Slide the ASS'Y STOPPER in the arrow direction and remove it. 4.2.4.1.2 ASS'Y PAPER SUPPORT (1) Pull the ASS'Y PAPER SUPPORT in the arrow direction and remove it.
Page 79: Ass'y Paper Tray
Oki Data CONFIDENTIAL 4.2.4.1.3 ASS'Y PAPER TRAY (1) Hold the both sides of the ASS'Y PAPER TRAY tightly. While keeping the both sides on a level, lift up the ASS'Y PAPER TRAY in the arrow direction and remove it. Hold here.
Page 80: Ass'y Pad
Oki Data CONFIDENTIAL 4.2.4.1.5 ASS'Y PAD (1) Raise the center of the ADF front cover in the arrow direction and open the ADF front cover (2) Pinch the clicks on both sides of the ASS'Y PAD with your fingers. While bending the clicks, pull up the pad.
Page 81: Ass'y Hinge Light/Heavy
Oki Data CONFIDENTIAL 4.2.4.1.6 ASS'Y HINGE LIGHT/HEAVY (1) Remove the screw and remove cover-ADF-wire and detach the ADF-Cable in the ar- row A direction. (2) Open the ADF unit (3) While pulling up the ADF unit , release the lock of the ASS'Y HINGE LIGHT , insert- ing a slot screwdriver into the notch as shown in the figure.
Page 82: Adf Lever Release
Oki Data CONFIDENTIAL 4.2.4.1.7 ADF LEVER RELEASE (1) Remove the two screws and remove the ADF LEVER RELEASE ASSY (2) Remove the screw of the ADF LEVER RELEASE ASSY 82 / 44158801TH Rev.2...
Page 83: Ass'y Adf Document (With Hinge)
Oki Data CONFIDENTIAL 4.2.4.1.8 ASS'Y ADF DOCUMENT (with Hinge) (1) While referring to sections 4.2.4.1.1 to 4.2.4.1.3, remove the ASS'Y STOPPER , the ASS'Y PAPER SUPPORT , the ASS'Y PAPER TRAY ASS'Y ADF DOCUMENT (with Hinge) 83 / 44158801TH Rev.2...
Page 84: Flatbed Unit
Oki Data CONFIDENTIAL 4.2.4.2 Flatbed unit 4.2.4.2.1 ASS'Y CONTROL PANEL (1) Remove the three screws . (Figure 1) (2) Pull the front of the ASS'Y CONTROL PANEL in the direction of arrow A and then slide the ASS’Y in the direction of arrow B to remove it. (Figure 2) (3) Disconnect the cable .
Page 85: Ass'y Main Board, Ass'y Stand-L, R
Oki Data CONFIDENTIAL 4.2.4.2.2 ASS'Y MAIN BOARD, ASS'Y STAND-L, R (1) Detach the scanner. (See Subsection 4.2.3) (2) Remove the screw and remove cover-ADF-wire and detach the ADF-cable in the ar- row A direction. (3) Open the ADF unit (4) While pulling up the ADF unit...
Page 86 Oki Data CONFIDENTIAL (5) Turn over the flatbed unit. (6) Remove the seven screws and open the ASS'Y MAIN BOARD . Disconnect all the connectors and remove the ASS'Y MAIN BOARD . (See 4.4 Precautions for Main Board Replacement) (7) Remove the three screws...
Page 87 Oki Data CONFIDENTIAL (8) Remove the two screws and detach Hinge-Cover-Upper-L/R (9) Remove the core . (10) Remove the four screws and remove the ASS'Y STAND-L (11) Remove the four screws and remove the ASS’Y STAND-R with cable. Cable 87 /...
Page 88: Ass'y Flatbed Unit
Oki Data CONFIDENTIAL 4.2.4.2.3 ASS'Y FLATBED UNIT (1) While referring to sections 4.2.4.2.1 to 4.2.4.2.2, remove the ASS'Y CONTROL PANEL and the ASS'Y MAIN BOARD ASS'Y FLATBED UNIT 88 / 44158801TH Rev.2...
Page 89: Printer
Oki Data CONFIDENTIAL 4.2.5 Printer 4.2.5.1 Face-Up Tray (1) Open face-up tray into the direction of the arrow, free the engagement on either side of it while deflecting the tray, and remove the tray. 89 / 44158801TH Rev.2...
Page 90: Rear Cover
Oki Data CONFIDENTIAL 4.2.5.2 Rear cover (1) Open the face-up tray. (2) Remove two screws (silver) . (Tool No. 1) (3) Insert the flat-tipped screwdriver (Tool No. 3) into hole A, as illustrated in Figure (2), and release two claws A.
Page 91: Led Assy/Led Assy Springs
Oki Data CONFIDENTIAL 4.2.5.3 LED Assy/LED Assy springs (1) Open the top cover. (2) After disconnecting the cable, first free hook part A by applying force in the direction of the ar- row, as illustrated in Figure (2), and then, free hook part B, to finally remove LED Assy...
Page 92: Control Pcb
Oki Data CONFIDENTIAL 4.2.5.4 Control PCB (1) Detach the scanner. (See Subsection 4.2.3.) (2) Remove the two screws , and detach cover-stay(R) (3) Remove the two screws , and detach plate shield drawer (4) Remove the two screws , and detach cable-clamp .
Page 93: Print Engine Controller Pcb
Oki Data CONFIDENTIAL 4.2.5.5 Print engine controller PCB (1) Remove the plate shield Assy. (See Subsection 5.2.5.4 (1) through (3).) (2) Remove all the connectors and two screws (silver) , and disassemble the print engine controller PCB . (Tool No. 1)
Page 94 Oki Data CONFIDENTIAL Figure 4-2-7-1 Cable route diagram of print engine controller PCB SCANNER BELTIDUP HVOLT RELAY OPTION POWER Figure 4-2-7-2 Connection diagram of print engine controller PCB 94 / 44158801TH Rev.2...
Page 95: Top Cover Assembly
Oki Data CONFIDENTIAL 4.2.5.6 Top cover assembly (1) Detach the scanner. (See Subsection 4.2.3) (2) Detach the rear cover. (See Subsection 4.2.5.2) (3) Remove the plate shield assembly, and then, the control PCB. (See Subsection 4.2.5.4) (4) Remove the two screws and detach cover-stay(L), stay-guide-L-Assy.
Page 96: Top Cover
Oki Data CONFIDENTIAL 4.2.5.7 Top cover (1) Detach the top cover assembly. (See Subsection 4.2.5.6.) (2) Detach the Holder-post (3) Detach the Link-A and Link-B (4) Remove ten screws (black) , and detach cable cover and top cover . (Tool No. 1) 96 / 44158801TH Rev.2...
Page 97: Controller Panel Assy
Oki Data CONFIDENTIAL 4.2.5.8 Controller Panel Assy Open the top cover. (2) Open the feeder unit. (3) Detach the right side cover. (See Subsection 4.2.3.) (4) Remove the plate shield assembly. [See Subsection 4.2.5.5 (2).] (5) After unplugging the connector of the control panel assembly, free the hook.
Page 98: Board Prp/ Top Cover Handle
Oki Data CONFIDENTIAL 4.2.5.9 Board PRP/ Top Cover Handle (1) Detach the control panel assembly. (See Subsection 4.2.5.8.) (2) Release two claws A, as illustrated in Figure (2), and remove frame OP , lever lock and spring compression (3) Release two claws B by forcing in the flat-tipped screwdriver (Tool No. 3), and remove the...
Page 99: Low-Voltage Power Supply / Low-Voltage Fan / Hopping Motor / Fuser Motor
Oki Data CONFIDENTIAL 4.2.5.10 Low-Voltage Power Supply / Low-Voltage Fan / Hopping Motor / Fuser Motor Electric shock can occur. When replacing the low voltage power supply, there is a danger of electric shock. Be sure to wear an insulation gloves or do not touch the electrically conduction areas or terminal directly by hand during the part replacement work.
Page 100 Oki Data CONFIDENTIAL Claws C Claws D Claws E PRN PCB Short-circuit plug for CN6 Low-voltage power supply POWER connector Fuser unit I/F connector AC switch Notes! CN6: Switching connector for AC input voltage setting Short-circuit plug to be equipped for 100-V system/Short-circuit plug not to be equipped for...
Page 101: Guide Eject Assy / Color Register Assy / Board-Pry
Oki Data CONFIDENTIAL 4.2.5.11 Guide Eject Assy / Color Register Assy / Board-PRY (1) Detach the left side cover, right side cover, rear cover, and top cover assembly. (See Sub- sections 4.2.1, 4.2.2, 4.2.5.2, and 4.2.5.6.) (2) Remove the print engine controller PCB, control PCB, and low-voltage power supply. (See Subsections 4.2.5.4, 4.2.5.5, and 4.2.5.10 (3).)
Page 102 Oki Data CONFIDENTIAL Heater thermistor & F cut (Black & white) Exit sensor Heater AC (Black & white) Belt thermistor Belt motor Belt thermistor Color registration sensor Color registration sensor Density sensor REPLAY Board-PRY Belt motor (To print engine controller PCB)
Page 103: Fan (Fuser)/ Belt Motor / High-Voltage Power Supply Board / Cover-Open Switch
Oki Data CONFIDENTIAL 4.2.5.12 Fan (Fuser)/ Belt Motor / High-Voltage Power Supply Board / Cover-Open Switch (1) Detach the left side cover. (See Subsection 4.2.1.) (2) Remove screw (silver) , unplug the connector, and disassemble belt motor . (Tool No. 1) (3) Detach rear cover .
Page 104: Mpt Assy
Oki Data CONFIDENTIAL 4.2.5.13 MPT Assy (1) Open MPT Assy (2) Release the two stoppers by opening the two arms of MPT Assy toward the outside, pull the assembly in the direction of the arrow to free the two fulcrums, and detach MPT...
Page 105: Feeder Unit / Board-Rsf/ Mpt Hopping Roller / Frame Assy Separator / Cover Front
Oki Data CONFIDENTIAL 4.2.5.14 Feeder Unit / Board-RSF/ MPT Hopping Roller / Frame Assy Separator / Cover Front (1) Open the top cover. (2) Remove the plate shield, and unplug the connector. (See Subsection 4.2.5.4.) (3) Free the claws of Stay L...
Page 106: Board-Prz Lift-Up Motor/Solenoid/Paper-End Sensor
Oki Data CONFIDENTIAL 4.2.5.15 Board-PRZ Lift-Up Motor/Solenoid/Paper-End Sensor (1) Detach the left side cover, right side cover, rear cover, top cover unit, and feeder unit. (See Subsections 4.2.1, 4.2.2, 4.2.5.2, 4.2.5.6 and 4.2.5.14.) (2) Disassemble the print engine controller PCB and control PCB. (See Subsection 4.2.5.4, 4.2.5.5 and 4.2.5.10 (3).)
Page 107 Oki Data CONFIDENTIAL View A Install aligninig the two position cut as mark figure. Lift-up motor Install aligninig the two position cut as mark figure. Align the motor and connector in position to the arrow. View A Lever-Solenoid 107 /...
Page 108: Feed Roller
Oki Data CONFIDENTIAL 4.2.5.16 Feed Roller (1) Remove the cassette. (2) Release the latch, and remove feed roller Latch 108 / 44158801TH Rev.2...
Page 109: Shaft Eject Assy(Fu) / Shaft Eject Assy(Fd) / Eject Sensor
Oki Data CONFIDENTIAL 4.2.5.17 Shaft Eject Assy(FU) / Shaft Eject Assy(FD) / Eject Sensor (1) Remove the eject Assy. (See Subsection 4.2.5.11.) (2) Free the two claws, and divide the Assy between guide into lower and guide eject up- (3) Remove gear idle eject...
Page 110: Fuser Unit
Oki Data CONFIDENTIAL 4.2.5.18 Fuser Unit (1) Open the scanner. (2) Open the top cover. (3) Lift up the lock levers (2, blue) of the fuser unit in the direction of the arrow, and remove fuser unit Scanner (Blue) Top cover 110 / 44158801TH Rev.2...
Page 111: Belt Unit
Oki Data CONFIDENTIAL 4.2.5.19 Belt Unit (1) Open the scanner. (2) Open the top cover. (3) Remove ID unit (4) Turn the lock levers (2, blue) of belt unit in the direction of the arrow , and hold belt unit by the levers (Blue) to remove it.
Page 112: Lubricating Points
Oki Data CONFIDENTIAL Lubricating points This subsection indicates the lubricating points of the printer. Conversely, it means that any other parts than the specified lubricating points must not be lubricated. There is no need to lubricate in the midst of a disassembling job. However, if lubricating oil has been wiped off, supply the specified oil.
Page 113 Oki Data CONFIDENTIAL 43070301 Plate-Assy.-Base Gear-Z24-50-HP Post EM-30L Class A EM-30L Class A Both sides EM-30L Class A EM-30L Class A Gear-Planet-HP Bearing Cross-Section EM-30L Class C EM-30L Class A EM-30L Class C Stopper-HP Post EM-30L Class A EM-30L Class A...
Page 114 Oki Data CONFIDENTIAL 42049701 Guide-Assy.-Cassette-L Apply a normal amount of Molycoat(EM-30L) to the hatched portions Guide-Casette-L EM-30L Class C 43294901 Guide-Assy.-Cassette-R Apply a normal amount of Molycoat(EM-30L) to the hatched areas Guide-Casette-R EM-30L Class C 114 / 44158801TH Rev.2...
Page 115 Oki Data CONFIDENTIAL 43073201 Gear-Assy.-HP Holder-Gear-A Apply a normal amount of Molycoat(EM-30L) to the hatched areas EM-30L Class C -1 43070501 Plate-Ass.-Side-R Apply a normal amount of Molycoat(EM-30L) to the hatched areas EM-30L Class C Bracket-Inner(Caulking) 115 / 44158801TH Rev.2...
Page 116 Oki Data CONFIDENTIAL -2 43070501 Plate-Ass.-Side-R Gear-LiftUp-Z21Z34 Apply a normal amount of Molycoat(EM-30L) Do not apply grease here to the hatched areas EM-30L Class C Gear-LiftUp-Z21Z34 Apply a normal amount of Molycoat(EM-30L) to the hatched areas EM-30L Class C Apply MOLYKOTE (EM-30L)
Page 117 Oki Data CONFIDENTIAL -4 43070501 Plate-Ass.-Side-R Apply MOLYKOTE (EM-30L) in a small quantity to the hatched parts. EM-30L ClassA Apply MOLYKOTE (EM-30L) in a normal quantity to the gear tooth tip. EM-30L ClassC Gear-LiftupR-Z56 Apply a normal amount MOLYKOTE (EM-30L)
Page 118 Oki Data CONFIDENTIAL 43074901 Plate-Ass.-Side-L Apply MOLYKOTE (EM-30L) in a small quantity to the hatched part. EM-30L Class A Apply MOLYKOTE (EM-30L) in a normal quantity to the gear tooth tips. EM-30L Class C Gear-Liftup-Z56 Link-Liftup-L Post-Gearldle-L Gear-Liftup-Z32 Apply MOLYKOTE (EM-30L) in a small quantity to the hatched part.
Page 119 Oki Data CONFIDENTIAL 42071401 Holder Assy.-Regist-L Apply MOLYKOTE (EM-30L) in a normal Holder-Regist-L quantity to the hatched parts (parts having the rotation shafts inserted). EM-30L Class C 42071901 Holder Assy.-Regist-R Holder-Regist-R Apply MOLYKOTE (EM-30L) in a normal quantity to the hatched parts (parts having the rotation shafts inserted).
Page 120 Oki Data CONFIDENTIAL 43122601 Fuser-Assy Cam-Release Lever-Release Plate-Side-R-Caulking(Fuser) Class C Apply HP-300(normal amount) to hatched area Gear-Fuser-(Z35) Do not apply grease to the boss. Gear-Idle-(Z21) Do not apply grease to the gears. 43070401 Cassette-Assy Assemble after applying MOLYKOTE (EM-30L) to the hatched parts in the illustration below (both right and left).
Page 121 Oki Data CONFIDENTIAL 43301501 Guide-Assy.-Eject-U 43560401~ Guide-Assy.-Eject-U Guide-Eject-Upper Apply MOLYKOTE (EM-30L) in a normal quantity to the gear tooth flanks, shaft surfaces and flanges (6 points). Grease must not stick to the paper paths. EM-30L Class C Shaft-Assy.-Eject(FD) Apply MOLYKOTE (EM-30L) in a normal quantity to the bearings (2 points).
Page 122 Oki Data CONFIDENTIAL 43070201 Frame-Assy.-Base Apply PM in a small quantity to the hatched part. (1) Applying method: Wipe the part with a cloth slightly impregnated with PM. (2) After applying PM, insert and pull out the cassette several times to ensure that no noise is emitted.
Page 123 Oki Data CONFIDENTIAL -1 43070101 Printer-Unit Apply MOLYKOTE (EM-30L) in a normal quantity to the tips of the terminals (4 points). Plate-Ass.-Side-L EM-30L Class C Plate-Driver-PU(Caulking) Apply MOLYKOTE (EM-30L) in a normal quantity to the post. EM-30L Class C Apply MOLYKOTE (EM-30L) in a normal quantity Gear-Idle-Belt to the gear tooth flanks.
Page 124 Oki Data CONFIDENTIAL -2 43070101 Printer-Unit Apply MOLYKOTE (EM-30L) in a normal quantity to the hatched parts. EM-30L Class C Plate-Ass.-Side-R Spring-Torsion-L Apply PM to the slot parts of the solid coiling of this torsion spring using a brush. Spring-Torsion-R...
Page 125 Oki Data CONFIDENTIAL 43079601PA Belt-Unit Apply MOLYKOTE (EM-30L) Apply MOLYKOTE (EM-30L) in a small in a normal quantity to the bearings quantity to the inside of Bearing-TR (both sides). (Belt) (4 points). EM-30L Class C EM-30L Class A Enlarged view...
Page 126 Oki Data CONFIDENTIAL 42626501 Sensor-Assy-Color-Regist Plate-Sensor-C.Regist Shaft-Cover-Sensor Apply MOLYKOTE (EM-30L) in a small quantity to the hatched parts (At both Sides)(8 points). EM-30L Class A MOLYKOTE must not stick to the surfaces of Cover Sensor-C. Regist. Cover-Sensor-C.Regist 126 / 44158801TH Rev.2...
Page 127 Oki Data CONFIDENTIAL 43081301 Roller-Assy.-Idle(FD) Disassembled view Range in which grease must not stick 127 / 44158801TH Rev.2...
Page 128 Oki Data CONFIDENTIAL 43301601 Roller-Assy.-BIAS(FU)C Grease applying method: Range in which grease must not stick 128 / 44158801TH Rev.2...
Page 129 Oki Data CONFIDENTIAL 43585301PA Cover-Assy-Top Grease prohibition to post Holder-Post Apply a normal amount of MOLYKOTE (EM-30L) to post (hatching portions) ClassA 129 / 44158801TH Rev.2...
Page 130 Oki Data CONFIDENTIAL 43613901PA Stay-Guide R Assy (735MFP) Apply a normal amount Apply a normal amount of MOLYKOTE (EM-30L) of MOLYKOTE (EM-30L) to post to hatching portions Class B Class B Apply a normal amount of MOLYKOTE (EM-30L) to post...
Page 131: Precautions For Main Board Replacement
For this reason, to prevent the use’s information from leaking, be sure to delete all the e-mail addresses and server profiles by using the OKI MFP network setup tool before removing a used main board each time.
Page 132 Oki Data CONFIDENTIAL Enter the password and click [Login]. Select all e-mail addresses in the list and then select [Tools] and [Export]. Specify the location to save, type the file name and click [Save]. 132 / 44158801TH Rev.2...
Page 133 Oki Data CONFIDENTIAL Select [Address Book] and [Delete]. Select [Yes]. Look in the operation panel of MC560 to make sure that the address book has become empty. 133 / 44158801TH Rev.2...
Page 134: Steps Of Importing The Exported Data
Oki Data CONFIDENTIAL 4.4.1.2 Steps of importing the exported data Run the OKI MFP network setup tool. Select the relevant device icon and click the “Address Book Edit” icon in the toolbar. Enter the password and click [Login]. 134 /...
Page 135 Oki Data CONFIDENTIAL Select [Tool], [Import] and [File...]. Select the data file saved by step of 4.4.1.1 and click [Open]. Select all e-mail addresses that you want them imported to the new main board, and click [OK]. Look in the operation panel of MC560 to make sure that the data has been imported to theaddress book.
Page 136: Deleting Server Profiles
Oki Data CONFIDENTIAL 4.4.2 Deleting Server Profiles 4.4.2.1 Steps of exporting and deleting data Run the OKIMFP network setup tool. Select the relevant device icon and click the “Scan To Profile Edit” icon in the toolbar. Enter the password and click [Login].
Page 137 Oki Data CONFIDENTIAL Select all profiles in the list and then select [Tool] and [Export...]. Specify the location to save, type the file name and click [Save]. 137 / 44158801TH Rev.2...
Page 138 Oki Data CONFIDENTIAL Select [Profiles] and [Delete]. Select [Yes]. Look in the operation panel of MC560 to make sure that the FTP address book has been empty. 138 / 44158801TH Rev.2...
Page 139: Steps Of Importing The Exported Data
Oki Data CONFIDENTIAL 4.4.2.2 Steps of importing the exported data Run the OKIMFP network setup tool. Select the relevant device icon and click the “Scan To Profile Edit” icon in the toolbar. Enter the password and click [Login]. 139 /...
Page 140 Oki Data CONFIDENTIAL Select [Tool], [Import] and [File...]. Select the data file saved by step of 4.4.2.1 and click [Open]. Select all e-mail addresses that you want them imported to the new main board, and click [OK]. Look in the operation panel of MC560 to make sure that the data has been imported to the FTP address book.
Page 141: Panel Switch Functions
Oki Data CONFIDENTIAL PANEL SWITCH FUNCTIONS Scanner Operator Panel 5.1.1 Layout “Menu” button “Numeric” button “Address book” button “Reset” button “One-touch” buttons “FTP Address” button “Power save” button “Zoom” button Display Zoom display “Power” lamp “Alarm” lamp “Sleep” lamp “Stop” button “Color” button “Copy Scaling selection”...
Page 142 Oki Data CONFIDENTIAL (8) Fax Mode button This button is used to switch the mode of the scanner to Fax mode, lights up when pressed and stays blue. After pressing this button, some settings related to fax functions become available. If the device is not operated in the selected period of time (20 sec. to 180 sec.) to switch to standby mode, Fax mode is switched to standby mode that is set as the default mode.
Page 143: Led/Lcd
Oki Data CONFIDENTIAL 5.1.2 LED/LCD The front panel is equipped with 19 LEDs, two LED buttons, a 2-digit digital display, a 3-digit digital display, and a 24-character × 2-line backlit LCD. (1) LEDs 100%: Lights up when 100% is selected to copy.
Page 144: Control Panel
Oki Data CONFIDENTIAL 5.1.3 Control Panel Part A Part B Part C Part A: Copy Area Scaling Area: Used to reduce document down to 25% or enlarge it up to 400%. 1. Increase scaling in 1% increment up to 400% 2.
Page 145 Oki Data CONFIDENTIAL Part B: LCD-display & Function Keys: Used to display current operation and select working mode. Function Keys and others: (Shown in Europe style) Used to indicate the number of copies. Used to choose the copy mode. (also the default working mode) Used to choose the Send e-mail, or Send Server mode.
Page 146 Oki Data CONFIDENTIAL Part C: Start & Other Keys: (Shown in Europe style) Used to select special requirement or the start key to send or copy your document(s). Used to set up the printer and the scanner. Used to change scanner setting to factory default value.
Page 147: Maintenance Menus
Oki Data CONFIDENTIAL MAINTENANCE MENUS The adjustment of this printer can be implemented using the maintenance utility and also by key input through the operator panel. This printer provides maintenance menus, apart from the normal menus. Select the menu that best suits the purpose of your intended adjustment.
Page 148 Oki Data CONFIDENTIAL Table 6-1 Maintenance menu indication table (2/3) Category Item(1st Line) Value(2nd Line) DF Function CONFIG MENU CODESET TYPE1 This menu is displayed on the printers TYPE2 for all destinations. TYPE1: Does not indicate Russian/ Greek. TYPE2: Indicates Russian/Greek.
Page 149 Oki Data CONFIDENTIAL Table 6-1 Maintenance menu indication table (3/3) Category Item(1st Line) Value(2nd Line) DF Function PERSONALITY IBM PPR III XL ENABLE Changes the default of support PDL DISABLE language for each destination. The PDL language disabled in this...
Page 150: Maintenance Utility
Oki Data CONFIDENTIAL Maintenance utility The maintenance utility is used to perform the adjustments of Table 5-2. Details of the maintenance utility are described below. (1) Maintenance Utility Operation Manual: 42678801FU01 Rev5 or later (Japanese) 42678801FU02 Rev5 or later (English) (2) The maintenance utility programs are indicated below.
Page 151 Oki Data CONFIDENTIAL Table 6-2 Maintenance Utility Adjustment Items (1/3) Operation on Section No. of Operator Panel Item Adjustment the Maintenance (Section No. corresponds to Utility Operation the Maintenance manual) PU (PRF) Board Copying of the EEPROM of PU PCB.
Page 152 Oki Data CONFIDENTIAL Table 6-2 Maintenance Utility Adjustment Items (2/3) Operation on Section No. of Operator Panel Item Adjustment the Maintenance (Section No. corresponds to Utility Operation the Maintenance manual) 12 Setup of sensitivity Setup of the sensitivity correction value of color...
Page 153 Oki Data CONFIDENTIAL Table 6-2 Maintenance Utility Adjustment Items (3/3) Operation on Section No. of Operator Panel Item Adjustment the Maintenance (Section No. corresponds to Utility Operation the Maintenance manual) 28 Counter indication Verification of the counters for consumable Subsect. 2.4.1.5.7 Subsect.
Page 154: Functions Of User's Maintenance Menu
Oki Data CONFIDENTIAL Functions of user's maintenance menu 6.3.1 Maintenance menu (For end users) There is a maintenance menu category among the normal menu categories. (Different from the system maintenance menus) The items that can be set under this menu are indicated below.
Page 155: Self-Diagnostic Mode
Oki Data CONFIDENTIAL 6.3.2 Self-diagnostic mode Individual explanation of LEVEL0 and LEVEL1. 6.3.2.1 Operator panel The explanation of the operations relating to the self-diagnosis presupposes the following operator panel layout. (1) Transition of menu items Self-diagnostic Level transition is possible only when a part is displayed.
Page 156 Oki Data CONFIDENTIAL (1) Switchover of menu items LEVEL0 The transition of xxxxx is activated when [BACK] or [ONLINE] is pressed and held down, or [MENU+] or [MENU-] is pressed briefly. The transition of xxxxx is activated with [MENU+] or [MENU-].
Page 157 Oki Data CONFIDENTIAL 157 / 44158801TH Rev.2...
Page 158: Normal Self-Diagnostic Mode (Level 1)
Oki Data CONFIDENTIAL 6.3.2.2 Normal self-diagnostic mode (Level 1) The menus of the normal self-diagnostic mode are indicated below. Table 6-3 Maintenance Utility Adjustment Items Maintenance Utility Item Self-diagnosis Menu Adjustment ML3100/C3100 ML5200/ML5400 (Without a Panel) (With a Panel) Switch scan test SWITCH SCAN Checking of inlet sensor and switch No.23...
Page 159: Activation Method For Self-Diagnostic Mode (Level 1)
Oki Data CONFIDENTIAL 6.3.2.2.1 Activation method for self-diagnostic mode (Level 1) The system maintenance menu mode is activated when the power is turned on with the MENU+ and MENU- keys held down simultaneously Press the MENU+ or MENU- key several times, until "ENGINE DIAG MODE" is displayed.
Page 160 Oki Data CONFIDENTIAL RFID antenna M RFID antenna K RFID antenna C Toner sensor Y Toner sensor M Toner sensor K Toner sensor C RFID antenna Y Cover-open SW Fuser unit thermistor Upper Write sensor Fuser unit thermistor Upper, compensation...
Page 161 Oki Data CONFIDENTIAL 161 / 44158801TH Rev.2...
Page 162: Motor Clutch Test
Oki Data CONFIDENTIAL 6.3.2.4 Motor clutch test This self-diagnosis is practiced to test motors and clutches. Activate the self-diagnostic mode (Level 1), press and hold down the MENU+ or MENU- key, until "MOTOR & CLUTCH TEST" appears in the upper line of the display section, and then, press the ENTER key.
Page 163 Oki Data CONFIDENTIAL Fuser motor (Registration shutter) ID motor Duplex ID Up/Down motor print solenoid Duplex print clutch Tray 1 Hopping motor (Registration motor, front motor) Duplex Hopping print motor solenoid Tray 2 clutch Belt motor Tray 2 motor Figure 6-2...
Page 164: Test Print
Oki Data CONFIDENTIAL 6.3.2.5 Test print This self-diagnosis is practiced to print test patterns built in PU. Other test patterns are stored in the controller. This print cannot be used to check the print quality. To diagnose abnormal images, follow Section 7.
Page 165 Oki Data CONFIDENTIAL Notes! PAGE setup ---------------------- After shifting the digit of the set value with the MENU+ key or MENU- key, press the ONLINE key. The set value will be incremented. Pressing the CANCEL key decrements it. COLOR setup ------------------- Pressing the ENTER key after selecting ON causes the data indicated below to appear on the panel.
Page 166 Oki Data CONFIDENTIAL Pattern 3 Pattern 4 Pattern 5 Pattern 6 Note! If the solid print (Pattern 7) available among the local print functions is conducted with 100% of each color, offset will take place. To prevent this offset, it will be necessary to make the print setup of each color as specified in 3 of Subsection 6.3.2.5...
Page 167 Oki Data CONFIDENTIAL • When print is executed, the following message is displayed: P: Number of test-print pages (Unit: sheets) W: Print wait time (Unit: seconds) • Pressing the MENU+ key switches over the indication. U: *** = Measured value of upper heater temperature [Unit: ˚C] [###] = Target temperature for print execution [Unit: ˚C]...
Page 168 Oki Data CONFIDENTIAL • Pressing the MENU+ key switches over the indication. KID, YID, MID and CID denote the constant-speed timer values of the respective ID motors (I/ O set values) [Unit: HEX]. • Pressing the MENU+ key switches over the indication.
Page 169: Color Registration Adjustment Test
Oki Data CONFIDENTIAL 6.3.2.6 Color registration adjustment test This self-diagnosis is practiced to conduct testing on the color registration function of the print- er and to locate the cause of color drift. Restore the normal operation of the printer by following the troubleshooting procedure if any error is issued during the color registration test.
Page 170: Print Density Adjustment Test
Oki Data CONFIDENTIAL <<BLT REFLECT RSLT is executed>> The same as the key operation of Item . in the execution of BLT REFLECT TEST. Repeat Items 2 and 3, as needed. Press the [BACK] key to terminate the test. (Status of Item 1 restored)
Page 171 Oki Data CONFIDENTIAL <<DENS ADJ RESULT is executed>> The same as the key operation of Item in the execution of DENS ADJ EXECUTE. <<DENS ADJ PAR-SET is executed>> Indication only, without functionality. <<AUTO CALIBRATION is executed>> Automatic setting of a density sensor sensitivity correction value is made. ([READY] light...
Page 172: Indication Of Consumable Part Counters
Oki Data CONFIDENTIAL 6.3.2.8 Indication of consumable part counters This self-diagnosis is practiced to indicate the consumed states of consumable parts. Activate the normal self-diagnostic mode, and press and hold down the [MENU+] key or [MENU-] key, until "CONSUMABLE STATUS" appears in the display section, and then, press the ENTER key.
Page 173: Indication Of Printed
Oki Data CONFIDENTIAL 6.3.2.9 Indication of printed page counters This self-diagnosis is practiced to indicate the current number of printed pages of the printer. Activate the normal self-diagnostic mode, and press and hold down the [MENU+] key or [MENU-] key, until "PRINTER STATUS" appears in the display section, and then, press the ENTER key.
Page 174: Setup Of Self-Diagnostic Function
Oki Data CONFIDENTIAL Press the [BACK] key to terminate the test. (The status of Item 1 is restored.) Indication Set Value Function FACTORY FACTORY MODE For setting the Factory Work mode (Fuse-cut disabled mode). MODE SHIPPING MODE For canceling the Factory Work mode and enabling the fuse-cut function.
Page 175: Indication Of Led Head Serial Number
Oki Data CONFIDENTIAL Press the [BACK] key (except for the status of Item 4.) to terminate the setup. (Status of Item 1 restored) Indication Set Value Operation of set value Function TONER ENABLE Detects. For enabling/disabling toner sensor operation. SENSOR DISABLE Does not detect.
Page 176: Details Of Panel Indications
Oki Data CONFIDENTIAL 6.3.2.13 Details of panel indications Display LCD (English) Ready Attention Description Level ( means no display in upper line) INITIALIZING It displays, while not having determined the system Initializing display language immediately after turning on a power supply.
Page 177 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) CHECKING SECTORS Displays that a sector of HDD is being checked. Initializing nnn% Check process of the sector is valid to start from "FILE SYS MAINTE2"-"CHK ALL SECTORS"...
Page 178 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) STATUS MODE Displays that normal Online mode starts. Initializing Data (Job) from an external portion is processed even though an error takes place after Online (ready) state once this mode starts.
Page 179 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) CANCELING JOB Blink Varies Indicates a job being cancelled due to no print permit. Normal (USER DENIED) (Related to JobAccount) 1. A job received from a user who is denied printing.
Page 180 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) Varies Toner amount is low. Displayed in a combination of Warning ORDER %COLOR% TONER (Blink) other message in the first line. (Off) In case of MENU "LOW TONER=STOP", ATTENTION LED blinks and the printer shifts to OFF Line.
Page 181 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) Blink Varies Interpreter detects an error due to the following Warning PS3 EMUL ERROR reason. Receive data after this is ignored until the job completion.
Page 182 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) Varies Notifies the life of the drum. This is a warning only. Warning %COLOR% DRUM LIFE This appears when the cover was opened and closed just after the drum life error occurred.
Page 183 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) Varies Varies Density Adjustment ID ERROR 2; smear due to ID Warning %COLOR% IMAGE DRUM SMEAR failure. ERROR PU firmware does not notify this warning to CU firmware at the time of Shipping Mode.
Page 184 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) Varies %TRAY%: The tray is empty. Treated as Warning until Warning %TRAY% EMPTY printing to the empty tray is designated. In this case, Leisus I/F : corresponding bits of both LFTERR and LFTERR2 should be '0'.
Page 185 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) Varies A disk error is occurred, which is other than the file Warning DISK USE FAILED nnn system fill or the disk write protected. Operation that does not involve a disk is available.
Page 186 Oki Data CONFIDENTIAL LCD (English) Ready Attention Description Level ( means no display in upper line) LOAD %MEDIA_SIZE% IN MP Manual paper feed is required. Manually insert the Warning TRAY paper shown by %MEDIA_SIZE%. AND PRESS ONLINE SWITCH The unit of paper size in Custom: The unit specified for MPTray (menu setting) is used if no unit is specified by the driver.
Page 187: Various Types Of Print On The Individual Printer Equipped With Controller
Oki Data CONFIDENTIAL 6.3.3 Various types of print on the individual printer equipped with controller Menu Map Printing Information on the program versions, controller configuration, network settings, etc., is printed. Operation: 1 Press the MENU+ key several times to cause “INFORMATION MENU” to be displayed.
Page 188: Setup After Replacement Of Parts
Oki Data CONFIDENTIAL Setup after replacement of parts This subsection describes the necessary adjustments to be made when parts have been re- placed. Replaced Part Adjustment LED Head Not necessary Image Drum Cartridge Not necessary (Y, M, C, K) Fuser Unit...
Page 189 Oki Data CONFIDENTIAL • To specify a PU Serial Number, enter a 11-digit number prefixed with "0" (single-byte zero). (Notice that, when the PU Serial Number is read, it is a 10-digit number.) On the "PU Serial Number setup" screen, enter the 11-digit number resulting from...
Page 190 Oki Data CONFIDENTIAL Note! When the EEPROM (engine control PCB) has been replaced, the service life information of the belt, toner, IDs, etc., is necessarily cleared. Therefore, be aware that the service life management is likely to suffer errors until the next time units are replaced.
Page 191: Setup Of Eeprom After Replacement Of Tbr Pcb
Oki Data CONFIDENTIAL 6.4.2 Setup of EEPROM after replacement of TBR PCB When the TBR PCB is replaced, it is necessary for the new replacement PCB to take over the user-settings that the user has been using to that point, as well as the font install information.
Page 192: Setup Of Destination
Oki Data CONFIDENTIAL • To specify the CU Serial Number, enter a number within 12 digits (Notice that, when the CU Serial Number is read, it is also a number within 12 digits.) Enter 12-digit Serial Number. Enter "4AEL4011702K." Ser.NO. 4AEL4011702K Lot.NO.
Page 193: Updating Scanner Firmware
Oki Data CONFIDENTIAL Updating Scanner Firmware There are two ways to update scanner firmware: one is by using an OKI network setup tool and the other is by running a scanner in loader mode. The followings are the steps to update.
Page 194 Oki Data CONFIDENTIAL An icon of MC560 is added. Choose the icon of MC560 and then select “Update Firmware” from the “Tools” menu. After the [Firmware File Selection] window appears, proceed to the folder where firmware files (*.spf) are stored, and select the relevant firmware file (*.spf).
Page 195 Oki Data CONFIDENTIAL When the display of the scanner changes to the standby screen, hold down the “Reset” button for five seconds to reset the scanner to the factory default settings. With this operation, update completes. When all the above is done, print a menu map of the scanner or go to Menu, Information, Firmware Version in the scanner operation panel, and make sure that the version of the irmware has been updated.
Page 196: Updating By Running The Scanner In Loader Mode
The flow of update is as follows: start the scanner in Loader mode first and then update only he system firmware with an “upload” tool. After that, update every firmware with an OKI network setup tool described in section 6.6.1 above.
Page 197 Note! Do not turn off the power during update. The scanner reboots. When the display of the scanner changes to the standby screen, continue operation to update the firmware as described in section 7.5.1 Updating with the OKI MFP Network Setup Tool. 197 /...
Page 198: Periodical Maintenance
Oki Data CONFIDENTIAL PERIODICAL MAINTENANCE Recommended replacement parts Oki Data recommends that heavy users only replace the following parts. (If those parts are not replaced, the print quality is not guaranteed, and malfunctions may even result.) Parts Name Friction Pad Assy 42088801 Roller Assy.
Page 199 Oki Data CONFIDENTIAL Cleaning the LED head Execute this cleaning if an output shows a light fuzzy print or white stripes, or characters are blurred. (1) Turn OFF the power of the printer. (2) Open the top cover by pressing the OPEN button.
Page 200: Cleaning Of Pickup Rollers
Oki Data CONFIDENTIAL Cleaning of pickup rollers If vertical stripes are observed in the print face, clean the pickup rollers. Note! For cleaning, use a soft piece of cloth to avoid scratching the roller surface. Cleaning the feed rollers and pad Execute this cleaning if [391 Paper Jam] is issued frequently.
Page 201: Internal Cleaning Of Printer
Oki Data CONFIDENTIAL Internal cleaning of printer Cleaning the interior of the printer. Depending on the print pattern, toner may adhere to the metal shaft located between the fuser unit and the cyan image drum cartridge. Execute this cleaning if the metal shaft has an adher- ence of toner.
Page 202 Oki Data CONFIDENTIAL (4) Take out the fuser unit. Personal injuries may occur. The fuser unit is extremely hot. Be careful not to touch it. If the fuser unit is hot, do not try yourself to clear paper but wait until the fuser unit becomes cool.
Page 203: Preventive Maintenance
Oki Data CONFIDENTIAL Preventive Maintenance This MFP is designed to be free of maintenance. However, it is suggested to perform preventa- tive maintenance in the shorter term either every 6 months or every 60,000 sheets scanning to ensure a consistently optimum performance.
Page 204: Cleaning The Adf
Oki Data CONFIDENTIAL 7.6.2 Cleaning the ADF From time to time the pad assembly and feeding rollers may become contaminated with ink, toner particles or paper dust. In this case, the machine may not feed documents smoothly. If this occurs please follow the cleaning procedures to return your machine to its original state.
Page 205: Replacing The Adf Pad
Oki Data CONFIDENTIAL 7.6.4 Replacing the ADF pad After scanning approximately 100,000 pages through the ADF, the pad module may be worn out and you may experience problems with document feeding. In this case, it is highly recommended to replace the pad module with a new one. For ordering the pad module, please consult your nearest dealer and follow the procedure below to replace it.
Page 206: Troubleshooting Procedures
Oki Data CONFIDENTIAL TROUBLESHOOTING PROCEDURES Precautions prior to repair (1) Confirm the basic check items indicated in the User's Manual. (2) Through hearing from the user, obtain information, as far in detail as possible, on the situation concerning the fault. (3) Inspect the printer in a condition close to the actual situation in which the fault occurred.
Page 207: Lcd Message List
Oki Data CONFIDENTIAL 8.5.1 LCD Message List When the printer detects an irrecoverable error, it displays a service call error in the LCD like the one given below: Service call nnn: error Note! "nnn" is an error code. When a service call error is issued, an error code is displayed in the lower line of the LCD, accompanied by the relevant error information.
Page 208 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (2/9) Code Ready Attention Display on Operator Panel Description LOAD %MEDIA_SIZE%/ Blink The size of paper or media type in the tray does not Error %MEDIA_TYPE% AND PRESS match the print data. ONLINE SWITCH...
Page 209 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (3/9) Code Ready Attention Display on Operator Panel Description LOAD %MEDIA_SIZE% Blink Printing request is issued to an empty tray. Error %ERRCODE%:%TRAY% EMPTY Load paper. (It takes a while until the status disappears after you have closed the tray and the lever lifted.)
Page 210 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (4/9) Code Ready Attention Display on Operator Panel Description PROTEC PAPER Blink Density of the destination image for a woven pattern Error %ERRCODE%:ERROR is greater than that of the woven pattern. A user...
Page 211 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (5/9) Code Ready Attention Display on Operator Panel Description REPLACE TONER Blink Toner ends. Error %ERRCODE%:%COLOR% TONER Error 410 : Y Error 411 : M EMPTY Error 412 : C Error 413 : K Warning status takes effect at Cover Open/Close.
Page 212 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (6/9) Code Ready Attention Display on Operator Panel Description CHECK TONER CARTRIDGE Blink Something is wrong with the toner sensor. Error %ERRCODE%:%COLOR% TONER This status is indicated in Shipping Mode only. SENSOR ERROR If the same error is detected in FACTORY Mode, it is indicated as service call of 163.
Page 213 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (7/9) Code Ready Attention Display on Operator Panel Description REPLACE IMAGE DRUM Blink The toner empty error is occurred after the image Error %ERRCODE%:%COLOR% DRUM drum reached its life. LIFE Error 560 : Y...
Page 214 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (8/9) Code Ready Attention Display on Operator Panel Description CLOSE COVER Blink The cover is open. Error %ERRCODE%:DUPLEX COVER Error 316 : Duplex Unit OPEN WAIT A MOMENT Blink The printer is receiving the download data.
Page 215 Oki Data CONFIDENTIAL Table 8-1-1 Operator Alarm (9/9) Code Ready Attention Display on Operator Panel Description PLEASE POW OFF It is shown that the printer completed shutdown pro- Error SHUTDOWN COMP cessing. (The backlight of LCD puts out the light) Printer will be restarted if a SHUTDOWN/RESTART button is pressed.
Page 216 Oki Data CONFIDENTIAL Table 8-1-2 Service Call Error (1/7) Message Cause Error Description Solution Service call Machine Check Replace TBR PCB. 001:Error Exception Hardware fault detected. (Board defectiveness or Shortage of power supply volume) Power off/on CPU Exception If RAM DIMM is installed,...
Page 217 Oki Data CONFIDENTIAL Table 8-1-2 Service Call Error (2/7) Message Cause Error Description Solution Service call Flash File System Access to the Flash ROM directly Flash File System Error 042:Error Error mounted on the CU PCB failed. Access to the Flash ROM...
Page 218 Oki Data CONFIDENTIAL Table 8-1-2 Service Call Error (3/7) Message Cause Error Description Solution Service call An error detected Does error reoccur? Power OFF/ON 105:Error by checking, at Replace PU PCB (PRF) printer's power- om, EEPROM installation. Service call Abnormal engine...
Page 219 Oki Data CONFIDENTIAL Table 8-1-2 Service Call Error (4/7) Message Cause Error Description Solution Service call LED head fault Is LED head properly set? Install the LED head unit 131:Error detected. (131 = Y, properly. 132 = M, 133 = C, Is the LED head fuse blown out? Check the LED head fuse.
Page 220 Oki Data CONFIDENTIAL Table 8-1-2 Service Call Error (5/7) Message Cause Error Description Solution Service call Short circuit in Turn power ON again. 170:Error fuser thermistor or Does error reoccur? Replace fuser unit. 171:Error open detected. note) Service call Abnormal Turn power ON again.
Page 221 Oki Data CONFIDENTIAL Table 8-1-2 Service Call Error (6/7) Message Cause Error Description Solution Service call False setting of Take off the HDD or replaced? Reset original HDD. 220:Error a record medium detected by a print statistics. Service call RFID Reader not...
Page 222 Oki Data CONFIDENTIAL Table 8-1-2 Service Call Error (7/7) Message Cause Error Description Solution Service call Fuser MotorLock The fuser unit does not rotate Check to see if the fuser 928:Error Error properly. unit is properly installed. Does the error reoccur after power Replace the fuser unit.
Page 223: Preparing For Troubleshooting
Oki Data CONFIDENTIAL 8.5.2 Preparing for troubleshooting (1) LCD Display Malfunction ....................225 (1-1) Nothing is displayed in LCD ................226 (1-2) The first line is black display in LCD ..............227 (1-3) PLEASE WAIT (The display changes to “COMMUNICATION ERROR” if you leave them as they are) ................227 (1-4) An error message related to the operation panel is displayed.
Page 224 Oki Data CONFIDENTIAL (11) Motor Fan Error(Error 120,127,051) ................254 (11-1) Low voltage power unit fan or CU fan does not rotate right after turning on the power .......................254 (11-2) ID cooling fan does not rotate in printing ............254 (11-3) DUPLEX fan does not rotate in DUPLEX printing ..........254 (12) Print Speed is Slow (Low Performance) .................255...
Page 225: Lcd Display Malfunction
Oki Data CONFIDENTIAL 8.5.2.(1) LCD Display Malfunction (1-1) Nothing is displayed in LCD Confirmation Items Confirmation Tasks Action at NG (1-1-1) Confirm fuse F5 (fuse) of PU PCB (PRF Check to see if F5 is blown out. Replace F5 or PRF PCB) PCB.
Page 226: The First Line Is Black Display In Lcd
Oki Data CONFIDENTIAL (1-2) The first line is black display in LCD Confirmation Items Confirmation Tasks Action at NG (1-2-1) Check of connections Connection between low- Check to see if the cord from the lower-voltage power Redo the insertion voltage power supply unit supply is connected properly to the POWER connector of the cord properly.
Page 227: Please Wait
Oki Data CONFIDENTIAL (1-3) PLEASE WAIT (The display changes to “COMMUNICATION ERROR” if you leave them as they are) Confirmation Items Confirmation Tasks Action at NG (1-3-1) Check of installed state of PCB Connected state between Check the engagement between the CUIF connector...
Page 228: Irregular Operation Of The Device After Turning On The Power
Oki Data CONFIDENTIAL 8.5.2.(2) Irregular Operation of the device after turning on the power (2-1) No operation Confirmation Items Confirmation Tasks Action at NG (2-1-1) Check of parts related to power supply AC power supplied to the Check the supply voltage of the AC power.
Page 229: Abnormal Sound
Oki Data CONFIDENTIAL (2-2) Abnormal sound Confirmation Items Confirmation Tasks Action at NG (2-2-1) Check for motor step-out (Abnormal driver) Operating state of motors Use the self-diagnostic mode to check to see if the Replace the PU motors are operating normally.
Page 230: Abnormal Odor
Oki Data CONFIDENTIAL (2-3) Abnormal odor Confirmation Items Confirmation Tasks Action at NG (2-3-1) Location of source of foul smell Fuser unit Take out the fuser unit, and check for the smell. Conduct (2-3-2). Low voltage power supply Take out the lower-voltage power supply unit, and check...
Page 231 Oki Data CONFIDENTIAL (3) Error number and jam location at paper jam Error No. Name Reference Corresponding Sensor Jam Release Method Duplex reversal DUP-IN, DUP-R Jam release method Duplex input DUP-F, DUP-R Jam release method Feed error at Duplex Jam release method...
Page 232 Oki Data CONFIDENTIAL JAM RELEASE METHOD Removing the jammed paper Front cover section (Codes: 372, 380, 390, 391, 400) Open the front cover, and if the leading end or trailing end of the jammed paper is visible, pull out the paper slowly. If code 400 is issued, the paper may be unloaded automatically. If that is the case, opening and closing of the cover will clear the error.
Page 233 Oki Data CONFIDENTIAL JAM RELEASE METHOD FUSER unit section (Codes: 381, 382, 383,385) Possible to get burned. The fuser unit can be very hot. Be careful not to touch it. If the unit remains hot, do not hasten to work, but wait, until after the unit has cooled down a little, and then remove the paper.
Page 234 Oki Data CONFIDENTIAL (4) Hold the fuser unit again by the handle and put it gently back in the printer. (5) Push the lock levers (2, blue) of the fuser unit toward the rear, and fasten the unit Fuser unit...
Page 235 Oki Data CONFIDENTIAL (2) Take out the image drum cartridges (4), and place them on a flat table. (3) Cover the image drum cartridges thus taken out with a black sheet of paper. Note! • The image drums (green tubular parts) are extremely vulnerable. Use good caution in handling them.
Page 236 Oki Data CONFIDENTIAL When neither the leading end nor the trailing end is visible First slide the jammed paper into the direction of the arrow, and then, pull it out slowly. Fuser unit Paper When the trailing end of the paper is visible While pushing the lever of the fuser unit into the direction of the arrow, pull out the jammed paper slowly.
Page 237 Oki Data CONFIDENTIAL JAM RELEASE METHOD Two-sided print unit section (Optional)(Codes: 370, 371, 373) (1) Open the two-sided print unit cover by pushing the jam releasing lever of the two-sided print unit section. Duplex unit cover Jam release lever (2) Take out the jammed paper.
Page 238: Paper Feed Jam(Error 391:1St Tray)
Oki Data CONFIDENTIAL 8.5.2.(3) Paper Feed Jam(Error 391:1st Tray) (3-1) Paper feed jam occurs right after turning on the power (1st Tray) Confirmation Items Confirmation Tasks Action at NG (3-1-1) Check of state of running route Paper running route in front...
Page 239 Oki Data CONFIDENTIAL Confirmation Items Confirmation Tasks Action at NG (3-2-4) Check of connections Feed motor drive cord Check the connected state of the cord. Redo the connection Check for incomplete connection or skew insertion, and properly. check the cord visually to see if it has any assembling Replace the cord problem.
Page 240: Paper Feed Jam (Error 390:Multi-Purpose Tray)
Oki Data CONFIDENTIAL 8.5.2.(4) Paper Feed Jam (Error 390:Multi-purpose Tray) (4-1) Paper feed jam occurs right after turning on the power (Multi-purpose Tray) Confirmation Items Confirmation Tasks Action at NG (4-1-1) Check of state of running route Paper running route in front...
Page 241: Paper Feed Jam Occurs Right After Paper Feeding Starts (Multi-Purpose Tray)
Oki Data CONFIDENTIAL (4-2) Paper feed jam occurs right after paper feeding starts (Multi-purpose Tray) Confirmation Items Confirmation Tasks Action at NG (4-2-1) Check of state of running route Paper running route in Check to see if there is paper jammed on the running...
Page 242: Paper Path Jam(Error 381)
Oki Data CONFIDENTIAL 8.5.2.(5) Paper Path Jam(Error 381) (5-1) Paper path jam occurs right after turning on the power Confirmation Items Confirmation Tasks Action at NG (5-1-1) Check of state of running route Paper running route in front Check to see if there is paper jammed on the running...
Page 243: Paper Path Jam Occurs Right After Feeding Paper
Oki Data CONFIDENTIAL (5-2) Paper path jam occurs right after feeding paper Confirmation Items Confirmation Tasks Action at NG (5-2-1) Check of state of running route Paper running route on the Remove the ID unit, and check to see if there is paper...
Page 244 Oki Data CONFIDENTIAL Confirmation Items Confirmation Tasks Action at NG (5-2-4) Check of connections Feed motor drive cord, Check the connected states of the cords. Correct the ID motor drive cord, belt Check for any incomplete connection or skew insertion connection properly.
Page 245: Paper Path Jam Occurs In A Path Route
Oki Data CONFIDENTIAL (5-3) Paper path jam occurs in a path route Confirmation Items Confirmation Tasks Action at NG (5-3-1) Check of operating state of motors Feed motor, belt motor, ID Conduct the Motor and Clutch Test of the self-diagnostic...
Page 246: Paper Path Jam Occurs Right After Reaching The Fuser Unit
Oki Data CONFIDENTIAL (5-4) Paper path jam occurs right after reaching the fuser unit Confirmation Items Confirmation Tasks Action at NG (5-4-1) Check of operating state of motors Fuser motor Conduct the Motor and Clutch Test of the self-diagnostic Replace the PU mode, and check to see if the fuser motor operates PCB (PRF PCB).
Page 247: Paper Exit Jam(Error 382)
Oki Data CONFIDENTIAL 8.5.2.(6) Paper Exit Jam(Error 382) (6-1) Paper exit jam occurs right after turning on the power Confirmation Items Confirmation Tasks Action at NG (6-1-1) Check of state of running route Paper running route in Check to see if there is paper jammed on the running...
Page 248: Paper Exit Jam Occurs Right After Feeding Paper
Oki Data CONFIDENTIAL (6-2) Paper exit jam occurs right after feeding paper Confirmation Items Confirmation Tasks Action at NG (6-2-1) Check of state of running route Face-up stacker cover Check to see if the cover is completely open or closed.
Page 249: Duplex Print Jam(Error 370,371,372,373,383)
Oki Data CONFIDENTIAL 8.5.2.(7) Duplex Print Jam(Error 370,371,372,373,383) (7-1) Duplex print jam occurs right after turning on the power Confirmation Items Confirmation Tasks Action at NG (7-1-1) Check of state of running route Paper running route in Check to see if there is paper jammed on the running route.
Page 250: Duplex Print Jam Occurs In Reverse Of The Paper
Oki Data CONFIDENTIAL Confirmation Items Confirmation Tasks Action at NG (7-2-4) Check of operating state of motor Duplex motor Conduct the Motor and Clutch Test of the self-diagnostic Replace the V7Y mode, and check the operation of the duplex motor.
Page 251: Paper Size Error (Error 400)
Oki Data CONFIDENTIAL 8.5.2.(8) Paper Size Error (Error 400) (8-1) Paper jam occurs when the end of paper is near IN1 sensor. Confirmation Items Confirmation Tasks Action at NG (8-1-1) Check of state of paper feed Multiple feed of paper...
Page 252: Id Unit Up-Down Error(Service Call 140-143)
Oki Data CONFIDENTIAL 8.5.2.(9) ID Unit Up-Down Error(Service Call 140-143) (9-1) An error occurs in the operation of ID Unit Up Confirmation Items Confirmation Tasks Action at NG (9-1-1) Check for load in the ascent Load in installing/removing Check to see if any abnormal load is felt in installing or...
Page 253: Fuser Unit Error(Error 170-177)
Oki Data CONFIDENTIAL 8.5.2.(10) Fuser Unit Error(Error 170-177) (10-1) An error occurs right after turning on the power Confirmation Items Confirmation Tasks Action at NG (10-1-1) Malfunction of thermistors Upper thermistor, lower Check to see if the thermistors are short-circuited or...
Page 254: Motor Fan Error(Error 120,127,051)
Oki Data CONFIDENTIAL 8.5.2.(11) Motor Fan Error(Error 120,127,051) (11-1) Low voltage power unit fan or CU fan does not rotate right after turning on the power Confirmation Items Confirmation Tasks Action at NG (11-1-1) Connections and laying of cords Connections and laying of Check to see if the connectors are properly connected.
Page 255: Print Speed Is Slow (Low Performance)
Oki Data CONFIDENTIAL 8.5.2.(12) Print Speed is Slow (Low Performance) (12-1) Print speed decreases up to 2ppm Confirmation Items Confirmation Tasks Action at NG (12-1-1) Environmental temperature Environmental temperature Check to see if the printer is located in such a small...
Page 256: Option Unit Is Not Recognized
Oki Data CONFIDENTIAL 8.5.2.(13) Option unit is not recognized (13-1) Duplex unit is not recognized Confirmation Items Confirmation Tasks Action at NG (13-1-1) Duplex PCB Duplex unit Check to see if the duplex unit in use conforms to the Replace the Duplex MC560 specification (A unit conforming to the C3200/ unit.
Page 257: Led Head Is Not Recognized(Error 131,132,133,134)
Oki Data CONFIDENTIAL 8.5.2.(14) LED head is not recognized(Error 131,132,133,134) (14-1) Service Call 131-134(LED HEAD Missing) Confirmation Items Confirmation Tasks Action at NG (14-1-1) Check of connections Connected state between Check visually the connected state of the FFC. Redo the connection CU PCB connector and properly.
Page 258: Toner Cartridge Is Not Recognized(Error 540,541,542,543)
Oki Data CONFIDENTIAL 8.5.2.(15) Toner cartridge is not recognized(Error 540,541,542,543) (15-1) Errors caused by consumables Confirmation Items Confirmation Tasks Action at NG (15-1-1) Installed state of consumables ID units and toner Are the ID units installed in the right positions? Check to...
Page 259: Errors Caused By Machine Defects
Oki Data CONFIDENTIAL (15-3) Errors caused by machine defects Confirmation Items Confirmation Tasks Action at NG (15-3-1) Loading on ID unit ID Unit Is a heavy load imposed on the ID unit, for example, Replace the ID unit. because the waste toner belt was ruptured?
Page 260: Dew Condensation Errors (Error 123)
Oki Data CONFIDENTIAL 8.5.2.(17) Dew Condensation Errors (Error 123) (17-1) Dew Condensation Confirmation Items Confirmation Tasks Action at NG (17-1-1) Check of connections Connection between PU Check to see if the 13-pin FFC is properly plugged into Correct the insertion PCB (PRF PCB) and high- the HVOLT connector of the PU PCB (PRF PCB).
Page 261: Image Problem Troubleshooting
Oki Data CONFIDENTIAL 8.5.3 Image Problem Troubleshooting (1) Color is totally pale (Fig.8.2 A ) ..................262 (1-1) Color is pale ......................262 (2) Background is dirty (Fig.8.2 B ) ..................263 (2-1) Background is dirty (partly) .................263 (2-2) Background is dirty (totally).................263 (3) Blank Print (Fig.8.2 C ) ....................264...
Page 262: Color Is Totally Pale (Fig.8.2 A )
Oki Data CONFIDENTIAL Color is totally pale (Fig.8.2 A ) 8.5.3.(1) (1-1) Color is pale Confirmation Items Confirmation Tasks Action at NG (1-1-1) Toner Remaining quantity of toner Check to see if "ORDER TONER" or "REPLACE Replace the toner TONER" appears on the operator panel.
Page 263: Background Is Dirty (Fig.8.2 B )
Oki Data CONFIDENTIAL Background is dirty (Fig.8.2 B ) 8.5.3.(2) (2-1) Background is dirty (partly) Confirmation Items Confirmation Tasks Action at NG (2-1-1) ID unit Drum exposed to light Check to see if the ID unit has been left in an Replace the ID unit.
Page 264: Blank Print (Fig.8.2 C )
Oki Data CONFIDENTIAL Blank Print (Fig.8.2 C ) 8.5.3.(3) (3-1) Blank on the whole page Confirmation Items Confirmation Tasks Action at NG (3-1-1) State of toner Remaining quantity of toner Check to see if a sufficient quantity of toner remains in Replace the toner the toner cartridge.
Page 265: Vertical Lines Are Printed
Oki Data CONFIDENTIAL 8.5.3.(4) Vertical lines are printed (4-1) Thin vertical lines (with color) (See Fig.8.2 D ) Confirmation Items Confirmation Tasks Action at NG (4-1-1) State of ID unit Filming of ID unit Check to see if the print was conducted in the absence Replace the toner of toner.
Page 266: Color Registration Is Wide
Oki Data CONFIDENTIAL 8.5.3.(6) Color registration is wide. (6-1) "IN ADJUSTING COLOR REGISTRATION" is shown only a short time Confirmation Items Confirmation Tasks Action at NG (6-1-1) Color registration result Color registration time Execute REG ADJ UST TEST in the self-diagnostic Replace the sensor (Approx.
Page 267: Solid Black Print
Oki Data CONFIDENTIAL 8.5.3.(7) Solid Black Print (7-1) Solid black on a full page Confirmation Items Confirmation Tasks Action at NG (7-1-1) High-voltage contact state CH terminal Check visually from above to see if the terminal Replace the terminal extending from the printer is properly in contact with the of the printer side.
Page 268: Actions After Forced Initialization Of Hdd/Flash
Oki Data CONFIDENTIAL 8.5.4 Actions after forced initialization of HDD/Flash This subsection explains the actions to be taken after a troubled HDD or Flash has been sub- jected to forced initialization. Action after forced initialization of HDD If the HDD is forcibly initialized, the following data is deleted. There is no way to recover it.
Page 269: Network Troubleshooting
Oki Data CONFIDENTIAL 8.5.5 Network Troubleshooting (1) Cannot print from Utility. Confirmation Items Confirmation Tasks Action at NG (1) Check of LINK light Check of LINK light Check to see if the LINK light (green) is on. Redo the connection Check to see if the HUB and the printer are properly of the network cable.
Page 270: Check Of Fuses
Oki Data CONFIDENTIAL Check of fuses If any of the following errors is issued, check the corresponding fuse on the CU control PCB (TBR PCB), PU control PCB (PRF PCB) or high-voltage power supply PCB. (See Table 8-6.) Table 8-6 Fuse Error...
Page 271: Troubleshooting
Oki Data CONFIDENTIAL Troubleshooting This section is given to locate and resolve the causes of troubles so as the MFP is always in good working condition. The trouble modes, relevant units and maintenance methods are described below. When a problem occurs, troubleshoot the problem according to the symptoms it shows.
Page 272: Copy Operation
Oki Data CONFIDENTIAL 8.7.1.2 Copy operation Copier online troubleshooting Mono/Copy Button press? Check Printer See Table 8.7.2 online ? Scanning See Table 8.7.3 performed Printing See Table 8.7.4 completed Image See Table 8.7.5 not clear Noises See Table 8.7.6 generated Figure 8.7.2 Copy operation flow...
Page 273: Email Operation
Oki Data CONFIDENTIAL 8.7.1.3 Email operation Email online troubleshooting Mono/Copy press? Connect SMTP See Table 8.7.8, Table 8.7.9 Server? Scanning See Table 8.7.3 performed? Transferring See Table 8.7.8, Table 8.7.9 compleat? Figure 8.7.3 Email operation flow 273 / 44158801TH Rev.2...
Page 274: Control Panel Operation
Oki Data CONFIDENTIAL 8.7.1.4 Control panel operation Copier online troubleshooting Wait for key pressing? LCD shows See Table 8.7.7 message? Value setting Figure 8.7.4 Control panel operation 274 / 44158801TH Rev.2...
Page 275: Tables
Oki Data CONFIDENTIAL 8.7.2 Tables The following tables provide detailed troubleshooting information. Table 8.7.1 The LCD does not display. Table 8.7.2 Printer does not react. Table 8.7.3 Optical path dirty or hardware problem. Table 8.7.4 Printer does not print. Table 8.7.5 Image not clear.
Page 276: Lcd Does Not Display
Oki Data CONFIDENTIAL 8.7.2.1 LCD does not display Table 8.7.1 Cause Relevant Unit Check Method Maintenance Method Unplugged from None Visual check Insert the AC plug into the outlet outlet DC power un- None Visual check Insert the DC power adapter...
Page 277: Printer Does Not Print
Oki Data CONFIDENTIAL 8.7.2.4 Printer does not print Table 8.7.4 Cause Relevant Unit Check Method Maintenance Method Printer select Printer Visual check Make sure the printer informa- wrong tion on the LCD display is cor- rect. Paper size incor- Paper tray...
Page 278: C5550Mfp Is Not Connected To The Network
Oki Data CONFIDENTIAL 8.7.2.8 C5550MFP is not connected to the network Table 8.7.8 Cause Maintenance Method RJ-45 connector is not Plug the connector in plugged in Network cable is damaged Replace a good one IP address is invalid Ask MIS for a valid address...
Page 279: Error Message
Oki Data CONFIDENTIAL 8.7.2.10 Error message 8.7.2.10.1 Error message during initializing Error Message Meaning Hardware Error Hardware Error Check Scanner Lamp Error Lamp Error Check Scanner Home Sensor/Lock Error Home Sensor or Lock Error Check Scanner Release the Lock ADF Paper Jam...
Page 280: Error Message During Printing And Copying
Oki Data CONFIDENTIAL 8.7.2.10.2 Error message during printing and copying Error Message Meaning Printer is off-line Shows off-line status Check The Printer Press ONLINE button of printer 10007 Check The Printer Check The Printer Optimizing Temperature Because the drum temperature is high, printing is tempo- Check The Printer rarily suspended.
Page 281 Oki Data CONFIDENTIAL Error Message Meaning K Drum Life If a drum life error occurs and a user opens/closes the Replace K Drum cover or reboots the printer, this phenomenon happens. When the printer printed 500 pages, the error occurs Y Drum Life again.
Page 282 Oki Data CONFIDENTIAL Error Message Meaning 10982 Job cancelled because of no permission for printing (Related Check The Printer to JobAccount) Cleared by pressing ON-LINE switch. 30114 Invalid data was received. Press the On-line switch and Check The Printer eliminate the warning.
Page 283 Oki Data CONFIDENTIAL Error Message Meaning Paper Jam-MP Tray JAM has occurred. Open Front Cover MP Tray Paper Jam-Tray1 JAM has occurred. Open Front Cover Tray1 Paper Jam-Feed JAM has occurred. Open Front Cover Feed Paper Jam-Transport JAM has occurred in paper path.
Page 284 Oki Data CONFIDENTIAL Error Message Meaning 30027 A network error is occurring. Check The Printer 40057 Service Calls. Check The Printer Copy is Unusable Color & Mono copy are unusable. Color Copy is Unusable Mono copy only Setting Failed Setup isn’t changed Setup isn’t changed...
Page 285: Information Codes During Networking
Oki Data CONFIDENTIAL 8.7.2.10.3 Information codes during networking Error Message Meaning Connection failed The connection failed. Check network settings Address is invalid The destination address is invalid. Check network settings Network is down Network is down. Check network settings Network is unreachable Network is unreachable.
Page 286: Error Message During E-Mailing
Oki Data CONFIDENTIAL 8.7.2.10.4 Error message during E-mailing Error Message Meaning Device internal failure Device internal failure Reboot the scanner Fail to connect Fail to connect Mail server Mail server Contact network administrator Fail to get Fail to get Mail server response...
Page 287 Oki Data CONFIDENTIAL Error Message Meaning Authentication required Authentication required: Contact network Mail server requires authentication in order to perform the administrator requested action. Action not taken Requested action not taken: mailbox name not allowed. Check "To" address User not local User not local: please try again.
Page 288: Error Message During Filing
Oki Data CONFIDENTIAL 8.7.2.10.5 Error message during filing Error Message Meaning Fail to connect Fail to connect FTP server FTP server Contact server administrator Unpredicted error Unpredicted error Contact server administrator FTP Login error FTP Login name error Check Login name...
Page 289 Oki Data CONFIDENTIAL Error Message Meaning CIFS send data error CIFS send data error CIFS fail to access file CIFS fail to access file attribute attribute Make sure you have full control privilege HTTP fail to connect HTTP fail to connect Check IP &...
Page 290: Error Message On Fax
Oki Data CONFIDENTIAL 8.7.2.10.6 Error message on fax Error Dode Error Message Meaning NO_STATUS = FAX_ERR_BASE, NO_DIALTONE_ERROR, NO_COMMON_MODULATION_ERROR NO_FAX_RESPONSE, NUMBER_BUSY, OPERATOR_CANCELLED, V8_ANSWER_ERROR, COMMAND_REPEAT_ERROR, NO_DIS_DTC_RECEIVED, NO_OR_LOST_FAX_CONNECTION, V34_CC_RETRAIN_TIMEOUT, CFR_RESEND_ERROR, COMMAND_REPEAT_ERROR1, REMOTE_CANNOT_RX_OR_POLL_ER POLL_FAILED_NO_PAPER_IN_ADF, POLLING_DISABLED, CONFIDENTIAL_POLLING_FAILED, CONFIDENTIAL_TX_FAILED, CIG_DID_NOT_MATCH, CIG_NOT_RECEIVED, POLL_PASSWORD_DID_NOT_MATCH, PWDP_NOT_RECEIVED, ANSWER_NON_V34_MODE_ERROR, V34_NOT_SUPPORTED_IN_JM, PRI_ERROR_EOR,...
Page 291: Scanner Shipment Setting List
Oki Data CONFIDENTIAL Scanner Shipment Setting List 8.8.1 The outline of Menu structure Each Function Push Menu Key Information Printer Menu Network Settings Mail Server FAX Setting Report Print Management 8.8.2 Scanner operation panel “2” key is used for standing up of scanner with Fax Service mode=ON.
Page 292 Oki Data CONFIDENTIAL Each Function Push Menu Key Information Model Device Name Scanner MAC Address Printer Serial No. F/W Version : Combine Printer F/W ver. with Scanner F/W ver. After the following setup is finished, returned to this class. Printer Menu...
Page 293 Oki Data CONFIDENTIAL Def. Subject : Enter subject. Def. From : Enter from address. Scan Size Limit After the following setup is finished, returned to this class. FAX Setting Phone Book Select Input Admin. Password Add Speed Dial! Add Group Dial!
Page 294 Oki Data CONFIDENTIAL Pulse Send Test Tone Send Test Modem Sinal Send Test Tone/Pulse Report Print Menu Map : Menu settings printing Printer Demo Page : Printer Demo Page printing MFP Usage Report : Scan count & Print count printing...
Page 295: Menu Settings
Oki Data CONFIDENTIAL 8.8.3 Menu Settings Menu Settings Europe Informa- • Model MC560 /CX2033 MFP MC560 /ES5460 MFP tion • Device (This is only information and Optional strings Optional strings Name can not be changed here.) (Initial strings : "OL" + (Initial strings : "OL"...
Page 296 Oki Data CONFIDENTIAL Menu Settings Phone • Edit Speed Dial! Settings Book • Edit Group Dial! • Delete Speed Dial! • Delete Group Dial! • Delete All! • Append Phone # Reports • Activity Report • Transmission Report • Transmission Report •...
Page 297 Oki Data CONFIDENTIAL Menu Settings Manage- LDAP • MaxEntries ment Settings • BaseDN BLANK BLANK • Search Field1 • Search Field2 • Search Field3 givenname givenname • Email mail mail • LDAP Auth Method simple simple 297 / 44158801TH Rev.2...
Page 298: Additional Settings
Oki Data CONFIDENTIAL 8.8.4 Additional Settings Additional Settings (FAX) Europe Quality Fine Fine Denisty Doc.Size Letter Delayed Time Current Time Current Time Ex). 06/27/2007 20:02 Ex). 27/06/2007 20:02 Manual Feed Poll to Receive Overseas Mode Additional Settings (Copy) Europe Denisty...
Page 299: Fax Service Mode
Oki Data CONFIDENTIAL Send to Function Europe BLANK BLANK Subject BLANK BLANK BLANK BLANK BLANK BLANK Fax Function 43611501 43611502 - 43611506 Fax [Time00:00] Current Time Current Time Fax[20:02] Fax[20:02] 8.8.5 Fax Service Mode Menu Setting Europe Activity Report ENABLE...
Page 300: Connection Diagrams
Oki Data CONFIDENTIAL CONNECTION DIAGRAMS Check of resistance values 300 / 44158801TH Rev.2...
Page 301 Oki Data CONFIDENTIAL 301 / 44158801TH Rev.2...
Page 302 Oki Data CONFIDENTIAL Unit 302 / 44158801TH Rev.2...
Page 303 Oki Data CONFIDENTIAL 303 / 44158801TH Rev.2...
Page 304: Component Layout
Oki Data CONFIDENTIAL Component layout (1) Print engine controller PCB (PRF PCB) Component side DEBUG R8 R5 OSC1 R10 R17 R14 R20 R15 R21 ARMORED R25 R27 COHP OPAMP3 SCANNER BELTIDUP HVOLT OPTION POWER RELAY 304 / 44158801TH Rev.2...
Page 305 Oki Data CONFIDENTIAL Solder side R501 R502 R503 R504 R506 R507 C501 R505 R512 C564 R616 C563 R615 C510 C509 C508 C507 C562 R614 C561 R613 R513 IC501 C520 C521 C527 C526 R520 Q502 Q501 R519 C524 C523 C528 C525...
Page 306 Oki Data CONFIDENTIAL (2) Main controller (TBR PCB) Component side PU735 R111 RM75 RM77 R112 RM76 RM78 DMMBS R129 R130 RM2 RM4 RM6 RM8 FET1 RM1 RM3 RM5 RM7 CP11 C79 1.2V MPUZA2 R101 R102 AACK DBWO RM9 RM11 RM13 RM15 2.5V_1...
Page 307 Oki Data CONFIDENTIAL Solder side 307 / 44158801TH Rev.2...
Page 308 Oki Data CONFIDENTIAL (3) Junction PCB (PRY PCB) Component side FUSER DENS Solder side BFUSE BFUCUT 308 / 44158801TH Rev.2...
Page 309 Oki Data CONFIDENTIAL (4) Duplex print control PCB (V7Y PCB) Component side SNS03 SNS12 SNS4 FLASH Solder side R561 R568 R569 R565 R564 R560 R562 C523 R551 C522 FET501 IC503 R578 R530 D508 R527 IC502 R570 C501 R504 TR501 R505...
Page 310 Oki Data CONFIDENTIAL (5) Second tray control PCB (V7Y PCB) Component side SNS03 SNS12 FLASH Solder side R561 R568 R569 R565 R564 R560 R562 C523 R551 C522 IC503 R578 R530 D508 R527 IC502 R504 R502 J524 R520 J523 J518 R580...
Page 311 Oki Data CONFIDENTIAL (6)-1 Control panel PCB (PRP PCB) Component side Solder side (7) Toner-Low sensor PCB (PRZ PCB) KTNR YTNR MTNR CTNR 311 / 44158801TH Rev.2...
Page 312 Oki Data CONFIDENTIAL (8) Inlet sensor PCB (RSF PCB) (9) Color adjustment sensor PCB (PRC PCB) (10) High-voltage power supply PCB TR-K TR-Y TR-M TR-C (11) Low-voltage power supply PCB Short-circuit plug for CN6 To PRN PCB POWER connector To fuser unit I/F connector...
Page 313 Oki Data CONFIDENTIAL (12) ID unit ID unit (For consumables) Contacts Fuse Toner-Low sensor PCB (PRZ PCB) Contacts ID unit (13) Transfer belt unit Transfer belt unit (For consumables) Contacts Fuse Driver junction PCB (PRY PCB) Contacts Transfer belt unit...

Oki c5550 Maintenance Manual

Table of Contents

Preparing for Troubleshooting

Image Problem Troubleshooting

Quick Links

Maintenance Manual

Chapters

Troubleshooting

Related Manuals for Oki c5550

Summary of Contents for Oki c5550
